BYV32E-150

Download Datasheet Request Quote

Note : Your request will be directed to WeEN Semiconductors.

BYV32E-150 Image

The BYV32E-150 from WeEN Semiconductors is a Power Diode with Forward Current 20 A, Forward Voltage 0.72 V, Reverse Current 30 µA, Reverse Voltage 150 V, Repetitive Peak Reverse Voltage 150 V. Tags: Through Hole. More details for BYV32E-150 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    BYV32E-150
  • Manufacturer
    WeEN Semiconductors
  • Description
    150 V Hyperfast Recovery Power Diode

General

  • Types of Diode
    Fast Recovery Diode View all
  • Configuration of Diode
    Dual Diode View all
  • Forward Current
    20 A
  • Forward Voltage
    0.72 V
  • Reverse Current
    30 µA
  • Reverse Voltage
    150 V
  • Repetitive Peak Reverse Voltage
    150 V
  • Non-Repetitive Peak Forward Current
    125 A
  • RoHS Compliant
    Yes View all
  • Applications
    Output rectifiers in high frequency switched-mode power supplies, Discontinuous Current Mode (DCM) Power Factor Correction (PFC)
  • Package Type
    Through Hole View all
  • Package
    TO-220AB
