PFE300SA-48

Download Datasheet Request Quote

Note : Your request will be directed to TDK Corporation.

PFE300SA-48 Image

The PFE300SA-48 from TDK Corporation is a AC to DC Converter with AC Input Voltage 85 to 265 V, AC Input Current 1.6 to 3.1 A, DC Output Voltage 48 V, DC Output Current 6.3 A, DC Output Power 302 W. Tags: Module. More details for PFE300SA-48 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PFE300SA-48
  • Manufacturer
    TDK Corporation
  • Description
    85 to 265 V, 6.3 A, 302 W, AC to DC Converter

General

  • Types of Converter
    Uncontrolled Rectifier View all
  • Number of Output
    Single View all
  • AC Input Voltage
    85 to 265 V
  • AC Input Current
    1.6 to 3.1 A
  • DC Output Voltage
    48 V
  • DC Output Current
    6.3 A
  • DC Output Power
    302 W
  • Switching Frequency
    180 kHz
  • Temperature operating range
    -40 to 100 Degree C
  • RoHS Compliant
    Yes View all
  • Industry
    Industrial, Commercial
  • Dimensions
    116.8 x 61 x 12.7 mm
  • Package Type
    Module View all
  • Note
    Weight :- 200 g
