FMF6K0393K02L

Download Datasheet Request Quote

Note : Your request will be directed to Kyocera AVX.

FMF6K0393K02L Image

The FMF6K0393K02L from Kyocera AVX is a Power Capacitor with Capacitance 0.039 uF, Voltage Rating 1000 V, Peak Current 124.8 A, Operating Temperature -40 to 105 Degree C. Tags: Through Hole, Film Capacitor. More details for FMF6K0393K02L can be seen below.

Product Specifications

Product Details

  • Part Number
    FMF6K0393K02L
  • Manufacturer
    Kyocera AVX
  • Description
    0.039 uF, ±10%, 1000 V, Power Film Capacitor

General

  • Type
    Film Capacitor View all
  • Phase Configuration
    Three Phase View all
  • Capacitance
    0.039 uF
  • Tolerance
    ±10%
  • Voltage Rating
    1000 V
  • Peak Current
    124.8 A
  • Operating Temperature
    -40 to 105 Degree C
  • RoHS Compliant
    Yes View all
  • Dimension
    18.0 x 13.5 x 7.5 mm ( W x H x T )
  • Application
    High reliability at high current stress, Self-healing properties, Flame retardant plastic case and epoxy resin, Low losses, high dv/dt capability, High moisture resistance, High stability of capacitance and long life
  • Package Type
    Through Hole View all
  • Note
    Dielectric :- Polypropylene, (Irms) :- 5.6 A
