CSBX0650-4R7M

Download Datasheet Request Quote

Note : Your request will be directed to Codaca Electronic.

CSBX0650-4R7M Image

The CSBX0650-4R7M from Codaca Electronic is a Power Inductor with Inductance 5.60 µH, Inductance Tolerance ±20 %, DCR 19.2 to 22.1 milli-ohm, Saturation Current 11.4 A, Temperature Operating Range -55 to 150 Degree C. Tags: Surface Mount. More details for CSBX0650-4R7M can be seen below.

Product Specifications

Product Details

  • Part Number
    CSBX0650-4R7M
  • Manufacturer
    Codaca Electronic
  • Description
    5.60 μH, 11.4 A, Shielded Power Inductor

General

  • Types of Inductor
    Shielded Inductor View all
  • Industry
    Industrial, Commercial
  • Inductance
    5.60 µH
  • Inductance Tolerance
    ±20 %
  • DCR
    19.2 to 22.1 milli-ohm
  • Saturation Current
    11.4 A
  • Qualification
    AEC-Q200 View all
  • RoHS Compliant
    Yes
  • Temperature Operating Range
    -55 to 150 Degree C
  • Dimension
    7 x 6.90 x 4.70 mm (L x W x H)
  • Applications
    Rraphic cards/ industrial conputers, DC /DC converters/Motherboards/Filter, High current switching regulators/Polyphase-switching regulators
  • Package Type
    Surface Mount View all
  • Package
    SMD
