SPD6D28-100M

Download Datasheet Request Quote

Note : Your request will be directed to Codaca Electronic.

SPD6D28-100M Image

The SPD6D28-100M from Codaca Electronic is a Power Inductor with Inductance 10 µH, Inductance Tolerance ±20 %, DCR 56 to 67.2 milli-ohm, Saturation Current 1.85 A, Temperature Operating Range -40 to 125 Degree C. Tags: Surface Mount. More details for SPD6D28-100M can be seen below.

Product Specifications

Product Details

  • Part Number
    SPD6D28-100M
  • Manufacturer
    Codaca Electronic
  • Description
    10 µH, ±20 %, 1.85 A, Drum Core Power Inductor

General

  • Types of Inductor
    Drum Core Inductor View all
  • Industry
    Industrial, Commercial
  • Inductance
    10 µH
  • Inductance Tolerance
    ±20 %
  • DCR
    56 to 67.2 milli-ohm
  • Saturation Current
    1.85 A
  • RoHS Compliant
    Yes
  • Temperature Operating Range
    -40 to 125 Degree C
  • Dimension
    6.80 x 6.80 x 2.80 mm (L x W x H)
  • Applications
    Ideally used in Notebook PC, LCD T, Game machine STB buck converter, network communication equipment
  • Package Type
    Surface Mount View all
  • Package
    SMD
  • Note
    Irms :-2.28 A
