VSAB0530-5R6M

Download Datasheet Request Quote

Note : Your request will be directed to Codaca Electronic.

VSAB0530-5R6M Image

The VSAB0530-5R6M from Codaca Electronic is a Power Inductor with Inductance 5.60 µH, Inductance Tolerance ±20 %, DCR 67 to 73 milli-ohm, Saturation Current 3.50 A, Temperature Operating Range -55 to 155 Degree C. Tags: Surface Mount. More details for VSAB0530-5R6M can be seen below.

Product Specifications

Product Details

  • Part Number
    VSAB0530-5R6M
  • Manufacturer
    Codaca Electronic
  • Description
    5.60 µH, ±20 %, 3.50 A, Shielded Power Inductor

General

  • Types of Inductor
    Shielded Inductor View all
  • Industry
    Automotive, Commercial, Industrial
  • Inductance
    5.60 µH
  • Inductance Tolerance
    ±20 %
  • DCR
    67 to 73 milli-ohm
  • Saturation Current
    3.50 A
  • Qualification
    AEC-Q200 View all
  • RoHS Compliant
    Yes
  • Temperature Operating Range
    -55 to 155 Degree C
  • Dimension
    5.45 x 5.20 x 2.80 mm (L x W x H)
  • Applications
    Engine and transmission control units, Diesel injection drivers, Noise suppresion for motors:windshield wipers/power seats/Power Mirrors/heating and ventilation blower/ HID lighting
  • Package Type
    Surface Mount View all
  • Package
    SMD
  • Note
    Irms :-3.50 A

Technical Documents
View details on the manufacturer's website
