VSHB0645-100MC

Download Datasheet Request Quote

Note : Your request will be directed to Codaca Electronic.

VSHB0645-100MC Image

The VSHB0645-100MC from Codaca Electronic is a Power Inductor with Inductance 10 µH, Inductance Tolerance ±20 %, DCR 44.5 to 53.4 milli-ohm, Saturation Current 5.30 A, Temperature Operating Range -55 to 155 Degree C. Tags: Surface Mount. More details for VSHB0645-100MC can be seen below.

Product Specifications

Product Details

  • Part Number
    VSHB0645-100MC
  • Manufacturer
    Codaca Electronic
  • Description
    10 µH, ±20 %, 5.30 A, Shielded Power Inductor

General

  • Types of Inductor
    Shielded Inductor View all
  • Industry
    Automotive, Commercial, Industrial
  • Inductance
    10 µH
  • Inductance Tolerance
    ±20 %
  • DCR
    44.5 to 53.4 milli-ohm
  • Saturation Current
    5.30 A
  • Qualification
    AEC-Q200 View all
  • RoHS Compliant
    Yes
  • Temperature Operating Range
    -55 to 155 Degree C
  • Dimension
    7.15 x 6.60 x 4.30 mm (L x W x H)
  • Applications
    Engine and transmission control units, Diesel injection drivers, Noise suppresion for motors:windshield wipers/power seats/Power Mirrors/heating and ventilation blower/ HID lighting
  • Package Type
    Surface Mount View all
  • Package
    SMD
  • Note
    Irms :-4.6 A
