GVB-8-Li-56.8V-WP

Solar Charge Controllers by Genasun
27 more product from this company
Download Datasheet Request Quote

Note : Your request will be directed to Genasun.

GVB-8-Li-56.8V-WP Image

The GVB-8-Li-56.8V-WP from Genasun is a Solar Charge Controllers with System Voltage 56.8 V, Rated Current 8 A, Power Rating 350 W, Efficiency 96 to 99 %, Operating Temperature -40 to 85 Degree C. Tags: Maximum Power Point Tracking (MPPT). More details for GVB-8-Li-56.8V-WP can be seen below.

Product Specifications

Product Details

  • Part Number
    GVB-8-Li-56.8V-WP
  • Manufacturer
    Genasun
  • Description
    56.8 V, 8 A, MPPT Solar Charger Controller

General

  • System Voltage
    56.8 V
  • Rated Current
    8 A
  • Power Rating
    350 W
  • Type
    Maximum Power Point Tracking (MPPT) View all
  • Battery Compatibility
    LiFePO4
  • Efficiency
    96 to 99 %
  • Protection Grade
    IP68
  • Dimension
    14 x 8.1 x 5.5 cm
  • Operating Temperature
    -40 to 85 Degree C
  • Applications
    Marine, Industrial, Military, Golf Cart, e-Bike

Technical Documents
View details on the manufacturer's website
