MPPT 150/45

Download Datasheet Request Quote

Note : Your request will be directed to Victron Energy.

MPPT 150/45 Image

The MPPT 150/45 from Victron Energy is a Solar Charge Controllers with System Voltage 12 to 48 V, Rated Current 45 A, Power Rating 650 to 2600 W, Efficiency 98 %, Operating Temperature -30 to 60 Degree C. Tags: Maximum Power Point Tracking (MPPT). More details for MPPT 150/45 can be seen below.

Product Specifications

Product Details

  • Part Number
    MPPT 150/45
  • Manufacturer
    Victron Energy
  • Description
    12 to 48 V, 45 A, MPPT Solar Charger Controller

General

  • System Voltage
    12 to 48 V
  • Rated Current
    45 A
  • Power Rating
    650 to 2600 W
  • Type
    Maximum Power Point Tracking (MPPT) View all
  • Battery Compatibility
    Li-ion
  • Communication Interface
    Bluetooth
  • Efficiency
    98 %
  • Protection Grade
    IP43, IP22
  • Dimension
    130 x 186 x 70 mm
  • Operating Temperature
    -30 to 60 Degree C

Technical Documents
View details on the manufacturer's website
