| Featured Power Electronics Products this Week |
|
|
| 2000 A AC/DC Current Transducer for Electric Vehicle Applications | |
Current Transducer
from Danisense
|
| The DL2000UB-10V from Danisense is a High-Precision AC/DC Current Transducer that is ideal for electric vehicle (EV) test bench, power measurement and power analysis, particle accelerators, MRI devices, medical scanners, battery testing, and evaluation systems, current calibration purposes, stable power supplies, and precision current sensing applications. It can continuously measure current levels of up to 2000 A with a linearity error of less than 30 ppm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 500 V Thermally Protected Metal Oxide Varistor | |
Varistor
from Meritek Electronics Corporation
|
| The TPV14N301KS from Meritek Electronics Corporation is a Thermally Protected Metal Oxide Varistor. It has an AC voltage rating of 195 V, a DC voltage rating of 250 V, and a clamping voltage of less than 500 V. This metal oxide varistor offers a high peak surge current handling capability of up to 10 kA in a standard lead-form design. It is available in a thermally enhanced through-hole package that measures 9.0 x 3.2 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1100 V Surge Suppression IC for Medical Applications | |
Surge Suppression IC
from Littelfuse
|
| The SPD2-PV11-3P0-R from Littelfuse is a Surge Suppression IC that has been designed to provide equipment protection from transient over-voltage events lasting in the order of microseconds. It requires an input voltage of up to 1100 V and has a current rating of 9 kA (IEC standard) and 50 kA (UL standard). This IP20-rated surge suppressor offers the capability to clamp and withstand high-energy transients, thereby ensuring low residual voltage. |
| |
Download Datasheet
Product Details | |
|
|
|
| 16 A IP30-Rated Inrush Current Limiter | |
Inrush Current Limiter
from Block
|
| The ES 30 from Block is an Inrush Current Limiter that has been designed to limit the inrush current in transformers with high switch-on or inrush currents (not suited for electrical machinery and motors). It has a voltage rating of up to 400 V(AC) and a current rating of 16 A. This inrush current limiter has a resistance (internal) of 3.75 ohms. It integrates a non-replaceable thermal fuse in the input circuit to enhance safety features. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q100 Qualified Single Channel Electronic Fuse | |
eFuse IC
from Vishay
|
| The SIPQ32433ADN-T1E3 from Vishay is an Automotive Qualified Single Channel eFuse IC that has been designed to protect both power sources and downstream circuitries connected to the switch from over-loads, short-circuit, voltage surges, and excessive inrush current. It requires an input voltage of 2.8 - 22 V, has a voltage rating of 28 V, and a current rating of 3.5 A. This eFuse integrates multiple control and protection features to provide enhanced controllability. |
| |
Download Datasheet
Product Details | |
|
|
|
| 32 V Bidirectional Diac for Commercial Applications | |
Diac
from TAITRON Components
|
| The DB3AM from TAITRON Components is a Bidirectional Diac (Trigger Diode) that is ideal for industrial and commercial applications. It has a break-over voltage of 32 V and a break-over current of less than 50 µA. This diac has a low breakover current, excellent symmetry and a very low leakage current. It functions as a triggering diode with a fixed voltage reference. This RoHS-compliant diac is available in a surface-mount package that measures 3.50 x 1.50 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V Triac for Inductive Applications | |
Triac
from WeEN Semiconductors
|
| The ACT102H-600D from WeEN Semiconductors is a Triac that is ideal for fan motor circuits, pump motor circuits, low-power, highly inductive, resistive, and safety load applications. It has a break-over voltage of 600 V and a break-over current of less than 8.8 A. This thyristor has a gate trigger voltage of over 0.15V and a gate trigger current of less than 5 mA. It features exclusive negative gate triggering and full-cycle AC conduction. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by APEC 2024 | | APEC 2024 | | The Applied Power Electronics Conference (APEC) focuses on the practical and applied aspects of the power electronics business. Session information and schedules have now been posted, as well as updated information for special events and travel & hotels. Registration for APEC 2024 in Long Beach, CA is now open. Click here to learn more. | | | |
|
|
| 125 V Bidirectional Sidac | |
Sidac
from Shindengen America
|
| The K1V(A)12 from Shindengen America is a Bidirectional Sidac that has been designed to provide versatile and flexible operation to meet diverse application needs. It has a break-over voltage of up to 125 V and a break-over current of less than 0.5 mA. This Sidac can be seamlessly integrated into a setup to provide direct switching capability using commercial power sources, streamlining operation and enhancing efficiency. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4500 V Radiation-Tolerant Asymmetric Gate Turn-Off Thyristor | |
Gate Turn off Thyristor
from ABB
|
| The 5SGA40L4501 from ABB is an Asymmetrical Gate Turn-Off Thyristor that has been designed to withstand effects due to cosmic radiation. It has a break-over voltage of up to 4500 V and a break-over current of less than 4000 A. This thyristor has a gate trigger voltage of 1.2 V and a gate trigger current of 4 A. It is based on patented free-floating silicon technology with an annular gate electrode construction. This asymmetric GTO offers low on-state and switching losses. |
| |
Download Datasheet
Product Details | |
|
|
|
| 66 W Radiation-Tolerant DC-DC Converter for NASA Class D Applications | |
DC to DC Converter
from VPT
|
| The VSC100-283R3S/ES+ from VPT is a Radiation Tolerant DC-DC Converter that converts an input voltage of 16 - 40 V to an output voltage of 3.3 V. It delivers an output power of up to 66 W and has an efficiency of 85%. This converter is a commercial-off-the-shelf solution that is designed for the NewSpace market. It guarantees optimal performance through the use of radiation lot acceptance tested (RLAT) components and uses proprietary packaging technologies. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3 V Wet Tantalum Supercapacitor for Avionics Applications | |
Supercapacitor
from Kyocera AVX
|
| The TWDE503K003CB0Z0000 from Kyocera AVX is a Wet Tantalum Supercapacitor that is ideal for special industrial, avionics, military and downhole drilling applications. It has a capacitance of 50 mF and a capacitance tolerance of ±10%. This supercapacitor has a voltage rating of 3 V and an equivalent series resistance (ESR) of less than 400 milli-ohms. It has high electrical and mechanical stability and has an operating temperature between -55 to 175 ºC. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1 V CMOS Linear LDO Voltage Regulator for Portable Applications | |
LDO Voltage Regulator
from AiT Semiconductor
|
| The A6303DE5R-10 from AiT Semiconductor is a CMOS Linear LDO Voltage Regulator that is ideal for smartphones, mobile phones, cordless phones, wireless communication equipment, portable games, portable AV equipment, camera and machine vision modules, battery-powered equipment, laptops, palmtops, notebook computers and voltage reference applications. It requires an input voltage of 1.8 - 5.5 V. This regulator provides an output voltage of 1 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| 120 W 3-Phase AC-DC Converter for Process Control Applications | |
AC to DC Converter
from TDK Corporation
|
| The DRB120-12-3-A0 from TDK Corporation is a Three-Phase AC-DC Converter that steps down an AC input voltage of 350 - 575 V to a DC output voltage of 12 V. It delivers an output power of 120 W and has an efficiency of up to 89.1%. This AC-to-DC converter includes narrow case widths, which makes it suitable for space-constrained applications. It has undergone conducted and radiated EMI testing to provide withstanding capability against electromagnetic disturbances. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V Schottky Barrier Power Diode for Power Supply Applications | |
Power Diode
from ROHM Semiconductor
|
| The YQ1VWM10ATR from ROHM Semiconductor is a Schottky Barrier Power Diode that is ideal for switching power supply, freewheel diode, and reverse polarity protection applications. It has a forward voltage of up to 0.7 V and a forward current of less than 1 A. This diode has a reverse voltage of up to 100 V and a reverse current of less than 6 µA. It boasts high reliability, which is characterized by its small power mold-type design. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| AEC-Q100 Qualified Zero Drift Operational Amplifier for Sensing Applications | |
Power Operational Amplifier
from STMicroelectronics
|
| The TSZ151ICT from STMicroelectronics is a Zero Drift, Single Channel Operational Amplifier that has been designed to provide very high accuracy and stability with a rail-to-rail I/O configuration. It requires a supply voltage of 1.8 - 5.5 V, an input offset current of 100 pA, and an input bias current of 50 nA. This op-amp provides an output current of 30 mA, a large signal voltage gain of 135 dB, and a common-mode rejection ratio (CMRR) of 132 dB. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Avalanche-Rugged N-Channel SiC MOSFET | |
MOSFET
from Micro Commercial Components
|
| The SICW028N120A4 from Micro Commerical Components is an N-Channel SiC MOSFET that has been designed to offer high blocking voltage while maintaining low on-resistance in a rugged package. It has a drain-source breakdown voltage of over 1200 V, a gate threshold voltage of 2 V, and a drain-source on-resistance of 28 milli-ohms. This MOSFET has a continuous drain current of up to 80 A and a pulsed drain current of less than 320 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 550 W Bi-Facial Mono-Crystalline Solar Panel | |
Solar Panels
from Canadian Solar
|
| The CS6W-550MB-AG from Canadian Solar is a Bifacial Mono-Crystalline Solar Panel that is ideal for utility power plant applications. This solar panel requires an input voltage of 41.7 V. It delivers an output power of 550 W and has an efficiency of 21.3%. This solar panel achieves high power and reliability with advanced LID/LeTID mitigation technology, reducing degradation by up to 50%. It is designed to withstand heavy snow loads of up to 5400 Pa. |
| |
Download Datasheet
Product Details | |
|
|
|
| True RMS AC/DC Voltage Transducer for Diagnostics Applications | |
Voltage Transducer
from AutomationDirect
|
| The VADT500-42-24 from AutomationDirect is an AC/DC Voltage Transducer that has been designed for high-performance true RMS sensing of AC voltage in single-phase or three-phase installations and DC voltage in DC-powered installations. It requires a supply voltage (AC/DC) of 24 V and an input voltage of 0 - 500 V. This transducer provides an output current of 4 - 20 mA. It can be used in situations where the power supplied is non-sinusoidal in nature. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8-Channel MEMS High Voltage Driver IC for RF Systems Applications | |
PMIC
from Menlo Micro
|
| The MM101-02ADA from Menlo Micro is an 8-Channel MEMS High Voltage Driver IC that has been designed for MEMS application where high voltage generation and driving capability are desired in a highly integrated form factor. It requires an input voltage of 4.5 - 5.5 V. This driver consists of a digital core (GPIO and SPI interface, control logic), high voltage level translators with push-pull output drivers, and a charge pump DC-DC converter. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 V Wire-Wound Flyback Transformer for High Frequency Applications | |
Power Transformer
from Pulse Electronics
|
| The PA1370NLT from Pulse Electronics is a Wire-Wound Flyback Transformer that is ideal for industrial automation, telecommunications, and medical equipment applications. It requires a primary voltage of 33 - 57 V and provides a secondary voltage of 12 V. This RoHS-compliant transformer has an inductance of 20.4 µH and a DC resistance of less than 80 milli-ohms. It is available in a surface-mount package that measures 15.24 x 13.08 x 11.45 mm. |
| |
Download Datasheet
Product Details | |
|
