| Featured Products this Week |
|
|
| 40 V N-Channel Power MOSFET | |
MOSFET
from Micro Commercial Components
|
| The MCAC180N04Y-TP from Micro Commercial Components is an N-Channel Power MOSFET. It has a drain-source voltage of 40 V, a gate threshold voltage of up to 4 V, and a drain-source on-resistance of up to 2.0 ohms. This MOSFET has a continuous body diode current of up to 180 A, a pulsed drain current of 127 A, and a power dissipation of less than 115 W. It is fabricated using split-gate trench MOSFET technology and is a halogen-free green device. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600W On-Board DC-DC Converter | |
DC to DC Converter
from Recom Power
|
| The RMOD600-80-13SEW from Recom Power is an On-Board DC-DC Converter that converts an input voltage of 33.6-120 VDC to an output voltage of 13 VDC. It delivers an output power of 600 W with an efficiency of up to 85%. This IP69K-rated converter provides a reinforced isolation voltage of 2.5 kVDC and offers plug-and-play functionality as a ready-to-use solution. It has base plate cooling that delivers full power at ambient temperatures up to 85°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q200 Compliant Decoupling Inductor | |
Power Inductor
from TDK Corporation
|
| The ADL4524VL-180M-TL000 from TDK Corporation is an AEC-Q200 Compliant Decoupling Inductor. This wire-wound inductor has an inductance of 18 µH with a tolerance of ±20%. It has a saturation current rating of 510 mA and a DCR of 0.8 ohms. This inductor utilizes an inductance measuring frequency of 100 kHz and operates across a temperature range of -55 to +155 °C. It leverages TDK's proprietary coiled-wiring architecture. |
| |
Download Datasheet
Product Details | |
|
|
|
| 400-420 W Monocrystalline PV Modules | |
Solar Panels
from MSquare Energy
|
| The MSEA-400W-420W-MH72 Series from MSquare Energy are High-Efficiency Monocrystalline PV Modules. They deliver an output power of 400-420 W at STC and 299-318 W at NMOT, with a maximum module efficiency of up to 20.63%. They provide an open-circuit voltage of up to 49.8 V, a maximum power voltage of up to 41.3 V, and a short-circuit current of up to 10.47 A. The modules incorporate half-cut cell technology with 144 mono cells. |
| |
Download Datasheet
Product Details | |
|
|
|
| 13.56 MHz NFC Wireless Charging Transmitter | |
Wireless Charging IC
from ROHM Semiconductor
|
| The ML7671-61XGD from ROHM Semiconductor is a 13.56 MHz NFC Wireless Charging Transmitter IC designed for NFC Forum WLC 2.0 compliant systems. It requires an input voltage of 0.3-6.5 V and delivers an output power of up to 250 mW when paired with the ML7670 receiver. This wireless charging IC is equipped with an abnormal detection function by software and hardware control. It features a host interface (I2C Target) function. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6.5 A Bi-directional Safety Load Switch | |
Power Switch IC
from Kinetic Technologies
|
| The KTS1865CEIAA-TA from Kinetic Technologies is a Bi-directional Safety Load Switch that is designed for USB Standard Power Range (SPR) Type-C Power Delivery systems. It requires an operating voltage of 3-23 V with VBUS and VSYS withstand of up to 29 VDC. It has a continuous current rating of 6.5 A and an on-state resistance of 20 milliohms. This load switch supports both power sinking and sourcing in USB PD systems. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 24-Port IEEE 802.3bt-Compliant PoE Midspan Injector | |
Power Over Ethernet IC
from Microchip Technology
|
| The PD-9624GC/AC-AU from Microchip Technology is a 24-Port IEEE 802.3bt-Compliant Power-over-Ethernet (PoE) midspan injector that has been designed to power IEEE 802.11 access points, pan-tilt-zoom (PTZ) and dome cameras, IP videophones, thin clients, and other high-power Ethernet end terminals. It requires an input voltage of 100-240 V. This Power Over Ethernet IC delivers an output power of 450 W (total power), and has a data rate of 10/100/1000 Mbps. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 A Low-Voltage Fuse | |
Fuses
from Eaton
|
| The 200MJ30-7 from Eaton is a Low Voltage Standard Fuse for feeder pillars. It has a voltage rating of 415 V (AC) and a current rating of 200 A. This fuse has a breaking capacity of 80 kA and uses a bolt-on connector. This RoHS-compliant fuse is available in a package that measures 111 x 31 x 31 mm and weighs 158.5 g. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Intelligent Power Module | |
IGBT
from Fuji Electric
|
| The 6MBP30XSK065-50 from Fuji Electric is an IGBT module. It has a collector-emitter voltage of up to 650 V, an input threshold voltage of up to 2.6 V, and a collector-emitter saturation voltage of up to 2.1 V. This IGBT has a collector current of 30 A and a peak forward current of 60 A. It integrates low-side IGBTs with a separate emitter configuration. This Intelligent Power Module (IPM) includes under-voltage lockout (UVLO) circuitry. |
| |
Download Datasheet
Product Details | |
|
|
|
| Synchronous Buck Power Stage Module | |
DC to DC Converter
from Alpha & Omega Semiconductor
|
| The AOZ53268QI from Alpha & Omega Semiconductor is a Synchronous Buck Power Stage Module. It requires a power supply of 2.5-25 V and a driver supply of 4.5-5.5 V. This highly integrated converter combines two asymmetrical MOSFETs with an integrated high-speed gate driver, delivering a continuous output current of up to 80 A, with pulse current capability reaching 120 A for 1 ms. It features a high-side MOSFET optimized for low capacitance. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V GaN Power Transistor | |
GaN Power Transistor
from Nexperia
|
| The GAN039-650NBB from Nexperia is an Automotive Qualified GaN Power Transistor. This transistor has a drain-source breakdown voltage of 650 V, a gate threshold voltage of up to 4.6 V, and a drain-source on-resistance of 33-86 milli-ohms. It has a continuous drain current of 58.5 A. This GaN transistor is a normally-off device that combines Nexperia’s latest high-voltage GaN HEMT H2 technology and low-voltage silicon MOSFET technologies. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 A High Precision DC and AC Current Clamp-on | |
Current Transducer
from Danisense
|
| The MK500ID from Danisense is a High Precision DC and AC Current Clamp-on that is ideal for EV battery testing, temporary installations, calibration, and in-field analysis, EV inverter evaluation, PV power generation, retrofit and maintenance purposes, transmission and distribution, wind, solar and energy applications. It can continuously measure current levels of up to 750 A with a linearity error of less than 20 ppm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 600 V Half-Bridge Gate Driver | |
Gate Driver
from STMicroelectronics
|
| The STDRIVEG612 from STMicroelectronics is a Half-Bridge Gate Driver that is ideal for AC/DC and DC/DC conversion, synchronous rectification, resonant converters, PFC, adapters, and battery charger applications. It requires an input voltage of 10.3-18 V. This gate driver IC has been designed to withstand a voltage of 600 V on the high-voltage rails on the high side. It can also handle high current and supports a propagation delay of 50 ns. |
| |
Download Datasheet
Product Details | |
|
|
|
| 24 V Push-Pull Power Plug-in Connector | |
Power Connector
from Weidmuller
|
| The IE-PS-VAPM-5P-2.5 from Weidmuller is a Push-Pull Power Plug-in Connector. It has a rated voltage of 24 V and a rated current of 16 A. This power connector is designed for more than 100 plugging cycles. It is compliant with the PROFINET specification and IEC 61076-3-126 standard. This IP65/67-rated power connector can operate over a temperature range of -40°C to 70°C. It has a zinc die-cast body with nickel plating and Cu-alloy. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V ePower Stage IC | |
PMIC
from Efficient Power Conversion
|
| The EPC23109 from Efficient Power Conversion is an ePower Stage IC. It requires an input voltage of up to 100 V and has a nominal bias supply voltage of 5 V. This power management IC (PMIC) operates at a PWM frequency of 3 MHz and delivers a continuous load current of 35 A. It uses EPC’s proprietary GaN IC technology and integrates an input logic interface, high-side level shifting, synchronous bootstrap charging, and gate drivers. |
| |
Download Datasheet
Product Details | |
|
|
|
| Wire-wound Metal Power Inductor | |
Power Inductor
from Taiyo Yuden
|
| The LSDND4040WKTR47NM from Taiyo Yuden is a Wire-wound Metal Power Inductor. It has an inductance of 0.47 µH with a tolerance of ± 30%. This power inductor has a rated current of 7.8 A, a saturation current of up to 10 A and a DCR of 13 milli-ohms. It has an operating temperature range of -40 to +125°C that includes self-generated heat. This RoHS/REACH-compliant power inductor is available in a surface-mount package that measures 4 x 4 x 2 mm. |
| |
Download Datasheet
Product Details | |
|
