| Featured Products this Week |
|
|
| 800 V Sensitive Gate Silicon Controlled Rectifier | |
Silicon Controlled Rectifier
from Surge Components
|
| The JX080H from Surge Components is a Sensitive Gate Silicon Controlled Rectifier that is ideal for residual current circuit breaker, straight hair and igniter applications. It has a break-over voltage of up to 800 V and a break-over current of less than 70 A. This rectifier has a gate trigger voltage of up to 0.8 V and a gate trigger current of less than 200 µA. It provides a high dv/dt rate with strong resistance to electromagnetic interface. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1700 V Symmetrical Gate Turn-Off Thyristor | |
Gate Turn off Thyristor
from Littelfuse
|
| The H0700KC14Y from Littelfuse is a Symmetrical Gate-Turn-off Thyristor that is ideal for industrial and commercial applications. It has a break-over voltage of up to 1700 V and a break-over current of less than 700 A. This GTO thyristor has a gate trigger voltage of 0.8 V and a gate trigger current of 0.4 A. This thyristor has storage temperature range of -40 to +150 °C. It is available in a surface-mount package that measures 50.55 x 16.50 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 32 V Diac for Oscillator Applications | |
Diac
from STMicroelectronics
|
| The SMDB3 from STMicroelectronics is a Diac that has been designed to function as a trigger diode with a fixed voltage reference. It has a break-over voltage of 32 V and a break-over current of less than 10 µA. This DIAC can be used in conjunction with Triacs for simplified gate control circuits or as a starting element in fluorescent lamp ballasts. It is available in a through-hole package that measures 2.75 x 0.89 mm and is ideal for a 32 V trigger device for oscillator circuits. |
| |
Download Datasheet
Product Details | |
|
|
|
| -120 V Silicon Epitaxial PNP Transistor for High-Speed Switching Applications | |
Bipolar Junction Transistor
from Toshiba
|
| The TTA014 from Toshiba is a Silicon Epitaxial PNP Transistor that is ideal for high-speed switching and DC-DC converter applications. It has a collector-emitter voltage of up to -120 V, a base-emitter voltage of -7 V, and a saturated collector-emitter voltage of up to -1.15 V. This transistor has a Collector current (DC) of -2.5 A and a power dissipation of 2.5 W. It exhibits a high DC current gain and a low collector-emitter saturation voltage. |
| |
Download Datasheet
Product Details | |
|
|
|
| 400 V Military-Grade Bidirectional Triode Thyristor | |
Triac
from Digitron Semiconductors
|
| The T6421DHR from Digitron Semiconductors is a Bidirectional Triode Thyristor that is ideal for industrial and commercial applications for full wave control of AC loads, control circuits, heater and motor controls, and other switching applications. It has a break-over voltage of up to 400 V and a break-over current of less than 300 A. This MIL-PRF-19500 standard thyristor has a gate trigger voltage of up to 1.35 V and a gate trigger current of 35 mA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 114 Ah Automotive Qualified NMC Battery System | |
Electric Vehicle Battery
from Elinta Motors
|
| The ESS7A.360.42 from Elinta Motors is an Automotive-Qualified NMC Battery System that is ideal for electric and hybrid vehicles, industrial UPS and heavy machinery applications. It requires a supply voltage of 365 V. This battery pack provides an energy of 42 kWh (40.80 kWh usable) and has a capacity of 114 Ah. It delivers a constant discharging power of 60 kW and a peak discharge power of 90 kW. This battery system is available in a module. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 kW Electric Transaxles for e-Mobility Applications | |
Electric Axle
from e-comer
|
| The TX2 SERIE - CVJ VERSION from e-comer are Electric Transaxles that are ideal for construction, logistics, agriculture, cleaning, and e-mobility applications. They deliver a continuous output power of 10 kW, a peak output power of up to 15 kW, and have an efficiency of 95%. These transaxles provide a torque of 1000 Nm and have a speed of less than 7200 rpm. They consist of a gearbox and an electric motor (rated to KTY 84-130 thermal protection class). |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 1000 V Depletion Mode GaN Power Transistor for Aerospace Applications | |
GaN Power Transistor
from Solid State Devices
|
| The SGF15D100JUB from Solid State Devices is a Depletion Mode GaN Power Transistor that is ideal for high-efficiency DC-DC/PoL converters, motor controllers, robotics/automation, and military and aerospace applications. This power transistor has a drain-source breakdown voltage of over 1000 V, a gate threshold voltage from -27 V to -8 V, and a drain-source on-resistance of 140 milli-ohms. It has a continuous drain current of up to 15 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 16 V Ceramic Capacitor for Commercial Applications | |
Power Capacitor
from Venkel
|
| The C1206X7R160-564KNP from Venkel is a Ceramic Capacitor that has been designed for industrial and commercial applications. It has a capacitance of 0.56 µF and a capacitance tolerance of ±10%. This capacitor has a voltage rating of 16 V. This capacitor features 100% matte Tin (Sn), Palladium Silver (Pd-Ag), Gold (Au), and Lead (Pb) terminations that cater to diverse connection needs. It possesses ceramic monolithic structure that ensures excellent reliability. |
| |
Download Datasheet
Product Details | |
|
|
|
| 2 kW IP66-Rated On-Board Charger for Light Electric Vehicle Applications | |
On-Board Charger
from IES Synergy
|
| The ELIPS 2000 from IES Synergy is an On-Board Charger that has been compactly designed with high-frequency electronics for integration into light electric vehicles. It requires an input voltage (AC) of 85 - 265 V (single-phase). This charger delivers an output power (DC) of 2 kW and has an efficiency of over 90%. It is designed in a robust, sealed case and adheres to automotive standards ensuring its durability against mechanical shocks & vibrations. |
| |
Download Datasheet
Product Details | |
|
|
|
| 145 kW Automotive Qualified Motor/Inverter System | |
EV Traction Motor
from Dana TM4
|
| The SUMO MD HV3000-6P from Dana TM4 is a Motor/Inverter System that has been designed to interface directly with standard rear differentials, gearboxes, and/or e-axles. It delivers a continuous output power of 145 kW and a peak output power of 235 kW. This motor provides a torque of 1055 Nm and has a speed of up to 3000 rpm. It is based on proven permanent magnet technology that ensures optimal efficiency with an outer rotor topology for maximum torque density. |
| |
Download Datasheet
Product Details | |
|
|
|
| Asynchronous Boost DC-DC Converter for Network Card Applications | |
DC to DC Converter
from AiT Semiconductor
|
| The A7542E6VR from AiT Semiconductor is an Asynchronous Boost DC-DC Converter that requires an input voltage of 2.5 - 5.5 V. It provides a switching frequency of 1 MHz and has an efficiency of up to 92%. This converter provides a switch current of up to 3 A and has low on-resistance. It uses a constant frequency peak current mode and requires an external Schottky diode. This converter operates at light mode with a supply current of 100 µA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 µH Magnetically-Shielded Power Inductor for Control Applications | |
Power Inductor
from CODACA Electronic
|
| The CPEX3231A-100MC from CODACA Electronic is a High Current Power Inductor that is ideal for PV inverter, industrial control, new energy, DC-DC converters, motherboards, filters, and high current switching regulator applications. It has an inductance of 10 µH and an inductance tolerance of ±20%. This power inductor has a saturation current of 86 A and a dynamic contact resistance (DCR) of less than 1.05 milli-ohms. It is magnetically shielded. |
| |
Download Datasheet
Product Details | |
|
|
|
| 60 V N-Channel Power MOSFET | |
MOSFET
from Micro Commercial Components
|
| The MCACL220N06YHE3-TP from Micro Commercial Components is an N-Channel Power MOSFET that has been designed in an excellent package to provide optimal heat dissipation and performance. It has a drain-source breakdown voltage of over 60 V, a gate threshold voltage of up to 2.5 V, and a drain-source on-resistance of less than 1.6 milli-ohms This power MOSFET has a continuous drain current of up to 220 A and a power dissipation of less than 147 W. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 1200 V Junction Field Effect Transistor for SMPS Applications | |
Junction Field Effect Transistor (JFET)
from Qorvo
|
| The UJ3N120035K3S from Qorvo is a Junction Field Effect Transistor that is ideal for over-current protection circuits, DC-AC inverters, switch mode power supplies (SMPS), power factor correction modules, motor drives, and induction heating applications. It has a drain-source breakdown voltage of over 1200 V, a gate threshold voltage of -11.5 V, and a drain-source on-resistance of 35 milli-ohms. This field effect transistor (FET) has a continuous drain current of up to 63 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1300 A High-Precision AC/DC Current Transducer | |
Current Transducer
from Danisense
|
| The DQ600ID-P1300 from Danisense is a High-Precision AC/DC Current Transducer that is designed for non-intrusive, isolated DC and AC current measurements up to 1300 A. It continuously measures current levels of 1300 A while maintaining a linearity error of less than 1 ppm. This current transducer requires an input current of less than 1300 A and a supply voltage of 15 V. It has a green diode to indicate its normal operation. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 V IP20-Rated AC Voltage Transducer | |
Voltage Transducer
from Circutor
|
| The CV-A-RMS Out2 from Circutor is an AC Voltage Transducer that has been designed to convert AC signals into DC process indicator signals. It requires a supply voltage of 24/115/230/400 V (AC) and 9 - 140 V (DC). This transducer provides an output voltage of 0 - 10 V and an output current of 4 - 20 mA. It delivers an analog output signal that is directly proportional to the input signal, calibrated in RMS format with a sinusoidal signal oscillating at 50 Hz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3 kW Pure Sine Wave Power Inverter | |
DC to AC Inverter
from Samlex America
|
| The PST-300S-24E from Samlex America is a Pure Sine Wave Power Inverter that converts a DC input voltage of 24 V to an AC output voltage of 230 V. It delivers an output power of 3000 W (continuous) and 6000 W (surge) and has an efficiency of up to 90 %. It can operate at wide ranges for DC input voltage and operating temperature and includes hard wiring and a schuko outlet for AC output. This DC-AC inverter benefits from ON/OFF control through contact closure. |
| |
Download Datasheet
Product Details | |
|
|
|
| Isolated Multi-Channel Smart Switch IC for PLC Applications | |
Power Switch IC
from Skyworks Solutions
|
| The Si83408ADA-IF from Skyworks Solutions is an Isolated Multi-Channel Smart Switch IC that has been designed to drive resistive and inductive loads such as solenoids, relays, and lamps commonly used in industrial control systems. It requires an input voltage of 9 - 32 V and provides a continuous output current of 0.7 A. This power switch integrates up to four high-side or low-side switches with low on-resistance. |
| |
Download Datasheet
Product Details | |
|
|
|
| High-Power LED Driver IC for Infrared LED Applications | |
LED Driver IC
from Kinetic Technologies
|
| The KTD2691ERAA-TA from Kinetic Technologies is a High-Power Flash LED Driver IC that has been designed for smartphone, tablet camera Flash, IR LED driver, and digital camera applications. It requires an input voltage of 2.7 - 5.5 V. This LED driver includes one current source that can provide a flash current of up to 1.5 A or a torch current of up to 376 mA, which contributes to a very small footprint to cater to portable applications. |
| |
Download Datasheet
Product Details | |
|
