| Featured Products this Week |
|
|
| High-Side Power Switch for Self-Powered USB Applications | |
Power Switch IC
from MaxLinear
|
| The SP2525A from MaxLinear is a High-Side Power Switch that has been designed for self-powered USB 2.0 and 3.0 hubs, USB-compliant VBUS power distribution, audio-video equipment, and generic power switching applications. It requires an input voltage of 3 - 5.5 V. This power switch meets USB voltage drop requirements for maximum transmission wire length. It features multi-purpose open-drain fault flag output indicating over-current limiting. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V 3-Phase SiC MOSFET for Inverter Applications | |
MOSFET
from Cissoid
|
| The CXT-PLA3SA12450A from Cissoid is a 3-phase SiC MOSFET that is ideal for inverter applications. It has a drain-source voltage of up to 1200 V, a gate threshold voltage of up to 2.15 V, and a drain-source on-resistance of 3.25 milli-ohms. This MOSFET has a continuous drain current of up to 450 A and a pulsed drain current of less than 720 A. It integrates power switches and the gate driver based on the CISSOID HADES2 chipset providing fast switching speed. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Enhancement Mode GaN Power Transistor for Fast Charging Applications | |
GaN Power Transistor
from Taiwan Semiconductor
|
| The TSG65N195CE RVG from Taiwan Semiconductor is an Enhancement Mode GaN Power Transistor that is ideal for power adapters, LED lighting drivers, fast battery charging, power factor correction, appliance motor drives, wireless power transfer, and power supply applications. This GaN transistor has a drain-source voltage of up to 650 V, a gate threshold voltage of 1.7 V, and a drain-source on-resistance of 150 milli-ohms. |
| |
Download Datasheet
Product Details | |
|
|
|
| PNP Transistor for High Voltage Applications | |
Bipolar Junction Transistor
from Nexperia
|
| The BSS63,215 from Nexperia is a PNP Transistor that is ideal for high-voltage general-purpose and switching applications. It has an emitter-base voltage of up to -6 V, a collector-emitter voltage of -100 V, and a collector-base voltage of less than -110 V. This transistor has a collector current of up to -100 mA and a power dissipation of less than 0.25 W. It is designed to handle low current and high voltage in a single package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Hex-Channel IGBT for UPS Applications | |
IGBT
from Yangjie Electronic Technology
|
| The MG50P12E1A from Yangjie Electronic Technology is a Hex-Channel IGBT that is ideal for motor drivers, AC and DC servo drive amplifiers, and uninterruptible power supply applications. It has a collector-emitter voltage of up to 1200 V, a gate-emitter voltage of ±20 V, and a saturated collector-emitter voltage of 2.2 V. This IGBT has a collector current of up to 50 A and a gate-emitter leakage current of less than 400 nA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Automotive-Qualified SiC Junction Field Effect Transistor | |
Junction Field Effect Transistor (JFET)
from Qorvo
|
| The UJ3N120070K3S from Qorvo is an Automotive-Qualified SiC Junction Field Effect Transistor that is ideal for over-current protection circuits, DC-AC inverters, switched mode power supplies, power factor correction modules, motor drives, and induction heating applications. It has a drain-source voltage of up to 1200 V and a drain-source on-resistance of 70 milli-ohms. This transistor has a drain current of up to 33.5 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 480 V 3-Phase Dual-Stage Power Line Filter for EV Charging Applications | |
EMI / EMC Filter
from Astrodyne TDI
|
| The RP420-150-1000-W from Astrodyne TDI is a 3-Phase Dual-Stage Power Line Filter that is ideal for power conversion systems, processing equipment, alternative energy equipment (EV charging and solar), and factory machinery applications. It has a voltage rating of 480 V and a current rating of 150 A. This RoHS-compliant dual-stage filter is UL1283/ 60929, CSA C22.2, EN 60939-approved for high reliability. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 33 V Low Voltage Multilayer Varistor | |
Varistor
from Bourns
|
| The ZV 11 K 1812 801 HT from Bourns is a Low Voltage Multilayer Varistor that has been designed to protect sensitive electronic devices against high-voltage surges in the low-voltage region. It has an AC voltage rating of 11 V (RMS), a DC voltage rating of 14 V, and a clamping voltage of 33 V. This varistor has a short response time and low clamping voltage. This RoHS-compliant varistor is available in a surface-mount package that measures 4.7 x 3.2 x 1.25 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1000 V Power Thyristor for Battery Charger Applications | |
Silicon Controlled Rectifier
from Vishay
|
| The VS-P404 from Vishay is a Power Thyristor that is ideal for power supplies, control circuits and battery charger applications. It has a break-over voltage of up to 1000 V and a break-over current of less than 385 A. This thyristor has a gate trigger voltage of up to 2 V and a gate trigger current of 60 mA. It consists of power thyristors and power diodes in a single package and has glass passivated junctions to ensure greater reliability. |
| |
Download Datasheet
Product Details | |
|
|
|
| IP40-Rated EV Traction Motor for Industrial Applications | |
EV Traction Motor
from Johnson Electric
|
| The UBR1AND5RE from Johnson Electric is an EV Traction Motor that has been designed for industrial and commercial applications demanding precise control of rotational speed and position. It requires a supply voltage of 12 - 230 V (AC) and delivers an output power of up to 0.24 W. This traction motor provides a torque of 0.77 Nm and has a speed of 300 rpm. It can stop functioning when an appropriate voltage is supplied, without being over-heated. |
| |
Download Datasheet
Product Details | |
|
|
|
| Flexible Transformer for DC-DC Converter Applications | |
Power Transformer
from Wurth Elektronik
|
| The 749196508 from Wurth Elektronik is a Flexible Transformer that is ideal for flyback converters, forward converters, push-pull converters, and step-up/step-down converters (SEPIC) applications. It has an inductance of 196 µH and a turns ratio of 1:1:1:1:1.1. This transformer has a current rating of 1.35 A and a DC resistance of less than 102 milli-ohms. It consists of six identical windings with low leakage inductance and offers an isolation voltage of up to 1500 V (AC). |
| |
Download Datasheet
Product Details | |
|
|
|
| 150 V AC Voltage Transducer for Industrial Applications | |
Voltage Transducer
from Frer Srl
|
| The MCOVS1150X05L from Frer Srl is an AC Voltage Transducer. It requires an input voltage of 0 - 150 V and a supply voltage of 20 - 60 V. This transducer provides an output current of 0 - 0.005 A. It complies with EN 60688 safety standards and includes a thermoplastic material that is compliant with UL 94-V0 flame-retardant standards. This voltage transducer operates over a temperature range from -10°C to +50°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 110 V Auxiliary-Powered Precision DC Current Transducer | |
Current Transducer
from Eltime Controls
|
| The EDCC-CX-E1-X20 from Eltime Controls is an Auxiliary-Powered DC Current Transducer that has been designed to convert DC current into a proportional DC voltage signal. It requires a supply voltage (AC) of 110 V and a supply current from ±1 mA to ±10 A. This transducer provides an output current of ±5 mA. It can conduct precise measurements in DC current applications and offers optional support for isolated DC current (in mA) or DC output voltage. |
| |
Download Datasheet
Product Details | |
|
|
|
| 320 V Single-Pole Surge Protection Device | |
Surge Suppression IC
from Prosurge
|
| The G50-320-S-3P from Prosurge is a Single-Pole Surge Protection Device that has been designed to guarantee reliability in harsh environments and high-exposure locations. It has a voltage rating of 320 V and a current rating of 50 kA. This surge suppressor has a voltage-level protection rating of less than 1.6 kV with a response time of up to 100 ns. It is non-pluggable and supports encapsulated spark gap (ESG) technology to guarantee reliability during operation. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| Integrated Electronic Power Switch for Hot-plug Protection Applications | |
eFuse IC
from STMicroelectronics
|
| The STELPD01 from STMicroelectronics is an Electronic Power Switch that is ideal for hot-swap, hot-plug protection, industrial systems, and VBUS management for Type-C and USB PD applications. It requires an input voltage from -0.3 V to - 23.5 V and provides an output current of 5 A. This switch includes an adjustable current limit with circuit breaker functionality for enhanced protection. It also offers thermal protection. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive Qualified Half-Bridge Motor Driver IC | |
Motor Driver IC
from Monolithic Power Systems
|
| The MPQ6610GJ-AEC1-Z from Monolithic Power Systems is an Automotive-Qualified Half-Bridge Motor Driver IC that is ideal for solenoid drivers, relay drivers, and brushed DC motor driver applications. This IC requires an input voltage of 4 - 55 V and provides an output current of up to 3 A. It has an internal current-sense circuit that can provide cycle-by-cycle current regulation and limiting to generate an output voltage proportional to the load current. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5 W Isolated AC-DC Converter for Industrial Control Applications | |
AC to DC Converter
from Aimtec
|
| The AMEL5-24SVZ from Aimtec is an AC-DC Converter that steps down an AC input voltage of 85 -264 V to a DC output voltage of 24 V. It delivers an output power of up to 5 W and has an efficiency of 81%. This converter offers an isolation of 4000 V (AC) for improved reliability and system safety. It provides greater cost-effectiveness due to material normalization and production automation, which further improves overall reliability and performance. |
| |
Download Datasheet
Product Details | |
|
|
|
| Single-Channel Low Side Switch for Sensor Applications | |
Power Switch IC
from Nisshinbo Micro Devices
|
| The NJW4822KH1-B from Nisshinbo Micro Devices is a Single-Channel Low Side Switch that is ideal for various sensor applications. It requires an input voltage of 2.64 – 5.5 V and provides an output current of 0.2 A. It has a drain-source voltage of 43 V and can be controlled by a logic signal (3 V/5 V) directly. This power switch integrates active clamp, over-current, error flag output and thermal shutdown that is built in with N-channel MOSFET. |
| |
Download Datasheet
Product Details | |
|
|
|
| 30 V Dual Asymmetric N-Channel MOSFET for DC-DC Converter Applications | |
MOSFET
from Alpha & Omega Semiconductor
|
| The AONG36322 from Alpha & Omega Semiconductor is a Dual-Asymmetric N-channel MOSFET that is ideal for DC-DC converters, servers, POL, telecom, and industrial applications. It has a drain-source breakdown voltage of over 30 V, a gate threshold voltage of 1.7 V, and a drain-source on-resistance of less than 6.8 milli-ohms. This MOSFET has a continuous drain current of up to 103 A and a power dissipation of less than 59 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Enhancement Mode GaN-on-Silicon Power Transistor | |
GaN Power Transistor
from Teledyne e2v HiRel Electronics
|
| The TDG650E601TSP from Teledyne e2v HiRel Electronics is an Enhancement Mode GaN-on-Silicon Power Transistor that is ideal for battery management, traction drives, dc-dc converters, space motor drives, and bridgeless totem pole PFC applications. This GaN transistor has a drain-source voltage of up to 650 V, a gate threshold voltage of 1.7 V, and a drain-source on-resistance of 25 milli-ohms. It has a continuous drain current of less than 60 A. |
| |
Download Datasheet
Product Details | |
|
