| Featured Products this Week |
|
|
| 1200 V Automotive-Grade SiC MOSFET | |
MOSFET
from Navitas Semiconductor
|
| The G3F135MT12J from Navitas Semiconductor is an Automotive-Grade Silicon Carbide MOSFET that utilizes Trench-Assisted Planar technology. It has a drain-source breakdown voltage of over 1200 V, a gate threshold voltage of 4.3 V, and a drain-source on-resistance of 135 milli-ohms. It has a continuous drain current of up to 18 A and a pulsed drain current of 48 A. This AEC-Q101-qualified MOSFET integrates a body diode with low forward voltage. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 36 V 4-Channel Solid-State Power Relay IC | |
Power Switch IC
from STMicroelectronics
|
| The IPS4140HQ-1 from STMicroelectronics is a Quad-Channel High-Side Solid-State Power Relay IC that is ideal for programmable logic control (PLC), numerical control machines, and industrial PC peripheral applications. It requires an input voltage of 10.5-36 V, an input current of 0.25 mA, and provides an output current of up to 0.1 A (per channel). This solid-state relay is based on STMicroelectronics’ VIPower technology. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 130 kW Coaxial Electric Drive System | |
Electric Axle
from Brogen EV Solution
|
| The 6PE from Brogen EV Solution is a Coaxial Electric Drive System that is designed for 5M-6M electric buses and 4.5T trucks. This electric axle integrates the motor and drive axle into one unit. It has a rated voltage of 540 V and a gear ratio of 16.5. This e-axle has a peak speed of 12000 rpm and delivers an output power of up to 130 kW. It provides an output torque of up to 5700 Nm and has a load capacity of 3500 kg. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 2000 V Schottky Diode | |
Power Diode
from Infineon Technologies
|
| The IDWD25G200C5 from Infineon Technologies is a Schottky Diode. It has a diode forward voltage of up to 1.5 V, a power dissipation of 468 W and a continuous forward current of up to 77 A. This diode has a repetitive peak reverse voltage of less than 2000 V and a reverse current of up to 375 µA. It has a total capacitive charge of 224 nC and a total capacitance of up to 2850 pF. This RoHS-compliant diode is qualified for industrial applications according to JEDEC47/20/22. |
| |
Download Datasheet |
Product Details | |
|
|
|
|
|
| 230 V IP40-Rated Electric Motor | |
EV Traction Motor
from Johnson Electric
|
| The UBR14NJ1RE from Johnson Electric is an Electric Motor. It requires an input voltage of 12-230 V. This motor delivers an output power of up to 0.24 W. It provides a torque of 0.77 Nm and has a speed of up to 300 rpm. This electric motor’s design allows the direction of rotation to be reversed for enhanced flexibility. It can be stopped when an appropriate voltage is applied across the ends to avoid the risk of overheating. |
| |
Download Datasheet |
Product Details | |
|
|
|
| Non-Isolated PWM DC-DC Converter | |
DC to DC Converter
from ROHM Semiconductor
|
| The BM2PBB3YF-E2 from ROHM Semiconductor is a Non- Isolated PWM DC-DC Converter IC. It requires an input voltage of 11.10-26.00 V. This DC-DC converter employs a PWM current mode control method with a switching frequency of 25 kHz. It has a built-in 730 V startup circuit and superjunction MOSFET, which contributes to its low power consumption while offering a simple design. This RoHS-compliant converter features a frequency-hopping function. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 40 V Bi-Directional GaN Field Effect Transistor | |
GaN Power Transistor
from Nexperia
|
| The GANB1R2-040QBA from Nexperia is a Bi-Directional GaN Field Effect Transistor (FET) that is ideal for high-side load switch, OVP protection in smart phone USB port, power switch circuits and stand-by power system. It has a drain-drain voltage of up to 40 V, a gate-source threshold voltage of up to 2.4 V, and a drain-drain on-state resistance of up to 1.2 milli-ohms. This GaN transistor has a drain current of up to 100 A and a power dissipation of up to 105 W. |
| |
Download Datasheet |
Product Details | |
|
|
|
| ASIL-C-Compliant Electronic Safety Controller | |
EV ECU
from TTTech Auto
|
| The TTC 580 from TTTech Auto is an Automotive-Qualified Electronic Safety Controller that has been designed for use in demanding, safety-critical, and complex automotive transportation scenarios. It requires an input voltage of 8-32 V and provides an output current of 60 A (RMS). This controller fulfills the safety requirements up to ASIL-C, SIL 2, and PL d standards. It embeds a 32-bit TMS570 microcontroller based on ARM Cortex-R4F core with built-in 256 KB RAM. |
| |
Download Datasheet |
Product Details | |
|
|
| Sponsored by European EV Thermal Management Summit 2025 | | European EV Thermal Management Summit 2025 | | European EV Thermal Management Summit 2025 will focus on innovative thermal management technologies for electric vehicles under the net-zero and sustainability goals. The summit invites over 17 leading speakers and more than 200 top industry experts, and organizes two roundtable discussions, offering you the latest technical insights and opportunities for face-to-face Q&A exchanges. This will enable to comprehensively understand advancements and improvements in areas such as the smart and lightweight design of thermal systems, battery thermal safety, etc under the new policies. Click here to learn more. | | | |
|
|
| Battery Protection ICs for 2-Serial-Cell Pack | |
Battery Management IC
from ABLIC
|
| The S-82C2A Series from ABLIC are Battery Protection ICs that are designed for the protection of 2-serial-cell lithium-ion/lithium polymer rechargeable battery packs from overcharge, over discharge, and overcurrent. They require an input voltage of 1.5-28 V. These battery management ICs (BMICs) consist of high-accuracy voltage detection and delay circuits that confirm over-charge detection operations. They allow the delay time to be set only by an internal circuit. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 2.2 µH Shielded Power Inductors | |
Power Inductor
from Bourns
|
| The HRP5022X Series from Bourns are Shielded Power Inductors. These inductors have an inductance of up to 2.2 µH and an inductance tolerance of ±20%. They have a current rating of up to 187 A, a saturation current of up to 280 A and a DCR of up to 0.23 ohms. These RoHS-compliant inductors feature low buzz noise. They are available in surface-mount packages that measure 50.9 x 38.1 x 21.7 mm. |
| |
Download Datasheet |
Product Details | |
|
|
|
| Automotive-Grade Bidirectional DC Current Sensor | |
Current Transducer
from Allegro MicroSystems
|
| The ACS37010LLZATR-050B3 from Allegro MicroSystems is an Automotive-Grade Bidirectional DC Current Sensor IC that has been designed to sense current flowing through the package. It requires an input voltage of 3.3 V and has a current measurement range of ±50 A. This AEC-Q100 Grade 0-qualified current sensor is factory-trimmed to provide a high measurement accuracy of ±1.5% over the entire operating range. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 3.3 F Cylindrical Supercapacitor | |
Supercapacitor
from Eaton
|
| The TV1020-3R0605-R from Eaton is a Cylindrical Supercapacitor that has been designed for backup power, pulse power and hybrid power systems. It has a capacitance of 3.3 F, a capacitance tolerance of -10% to +30% and a peak power of 30 W. This UL-recognized capacitor has a voltage rating of 3 V, a leakage current of 15 µA and an equivalent series resistance (ESR) of less than 0.075 ohms. It utilizes electrochemical double-layer capacitor (EDLC) construction. |
| |
Download Datasheet |
Product Details | |
|
|
| Sponsored by European EV Thermal Management Summit 2025 | | |
|
|
| Dual Stage 4-Wire EMI/EMC Line Filter | |
EMI / EMC Filter
from Delta Electronics
|
| The 16TYT8-2 from Delta Electronics is a Dual Stage 4-Wire EMI/EMC Line Filter. It has a voltage rating of 520 V (AC) and a current rating of 16 A. This three-phase filter operates at a frequency range of 50/60 Hz and has an inductance of up to 1.7 mH. It is available in a chassis-mount package that measures 143 x 120 mm and is suitable for electric equipment, UPS, machine tools, copy machines, automation equipment, robots, and AC motor drives. |
| |
Download Datasheet |
Product Details | |
|
|
|
| 3 kW IP65-Rated Battery Charger | |
On-Board Charger
from ZIVAN
|
| The SG3 96V from ZIVAN is a Battery Charger that is ideal for construction equipment, e-mobility, aerial work platforms, agriculture, mobile robotics, and outdoor powering applications. It requires an AC input voltage of 95-265 V and an input current of up to 16 A. This charger delivers an output power of up to 3 kW and an output voltage of 96 V. It supports operation over a universal AC input range. This battery charger consists of an optional EVSE charging controller. |
| |
Download Datasheet |
Product Details | |
|
