| Featured Products this Week |
|
|
| Optically Isolated Form A Solid-State Relay | |
Power Switch IC
from Vishay
|
| The VOR1003M4T from Vishay is an Optically Isolated Form A Solid-State Relay. It delivers a continuous load current of up to 5 A with a load voltage of 30 V. This relay features contactless optical switching and can safeguard against an isolation voltage of 3750 VRMS. It has fast switching speeds and a low leakage current of less than 1 µA. This RoHS-compliant relay has a low on-resistance of 0.7 Ω and operates from -40 to +85°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 37 kWh Modular Battery Pack | |
EV Battery
from FPT Industrial
|
| The eBS 42 from FPT Industrial is a Modular Battery Pack. It requires an input voltage of 290-453 V. This EV battery has a nominal voltage of 400 V and a nominal energy of 42 kWh. It has a continuous charging rate of 1C and a discharging rate of 2C. This EV battery utilizes Li-NMC technology and offers an energy density of 170 Wh/kg. It provides more than 4000 operational lifecycles. This IP6K9K/IP68-rated battery supports a multipack configuration. |
| |
Download Datasheet
Product Details | |
|
|
|
| 40 V N-Channel Trench Power MOSFET | |
MOSFET
from Micro Commercial Components
|
| The MCG4D8N04Y-TP from Micro Commercial Components is an N-Channel Power MOSFET. It has a drain-source breakdown voltage of over 40 V, a gate threshold voltage of 2.8 V, and a drain-source on-resistance of less than 4.8 milli-ohms. This MOSFET has a continuous drain current of up to 75 A and a power dissipation of less than 60 W. It uses split-gate trench power MOSFET technology and offers a high-density cell design for low drain-source on-resistance. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V Insulated Gate Bipolar Transistor | |
IGBT
from Bourns
|
| The BIDNW30N60H3 from Bourns is an Insulated Gate Bipolar Transistor designed for high-voltage and high-current applications. It has a collector-emitter voltage of 600 V and dissipates an output power of 230 W. This IGBT has a continuous collector current of 60 A and a pulsed collector current of 120 A. It utilizes Trench-Gate Field-Stop technology, resulting in a low collector-emitter saturation voltage of 1.65 V and low switching loss. |
| |
Download Datasheet
Product Details | |
|
|
|
| 300 W Compact AC-DC Power Supplies | |
AC to DC Converter
from Traco Power
|
| The TPP 300-M Series from Traco Power are AC/DC Power Supplies that convert an AC input voltage of 85-264 V to a DC output voltage of 12-53 V. They also accept a DC input voltage of 100-240 V. These converters deliver an output power of 300 W and have an efficiency of up to 93%. They also incorporate an active power factor correction (PFC) circuit with a PFC factor of over 0.9, thereby ensuring high efficiency and power density in a compact design. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 6.6 kW Fast and Slow Charging Integrated Charger | |
On-Board Charger
from Elecpeek
|
| The RHT-OBC-6.6KW from Elecpeek is a Fast and Slow Charging Integrated Charger. It delivers an output power of 6.6 kW. This charger requires an input voltage of 90-456 VAC and provides an output voltage of 24-144 V. It incorporates CAN bus control and requires forced air cooling for enhanced thermal performance. This OBC is designed for both fast and slow charging needs to offer user convenience and flexibility with varying charging preferences. |
| |
Download Datasheet
Product Details | |
|
|
|
| 18 V Automotive-Grade GaN Power IC | |
GaN Power Transistor
from Navitas Semiconductor
|
| The NV6522 from Navitas Semiconductor is an Automotive-Qualified GaN Power IC that is ideal for AC/DC, DC-DC, CCM/CrM topologies, data center CRPS, on-board chargers, solar inverters, and motor drive applications. It requires an input voltage of 11-18 V and an input current of 3.3 mA. This AEC-Q100 Grade 1-qualified power IC is based on Navitas’ GaNFast technology, optimizing the switching speed of the transistor IC up to 2 MHz to support high-frequency. |
| |
Download Datasheet
Product Details | |
|
|
|
| 65 V Multilayer Chip Varistor | |
Varistor
from Abracon
|
| The AMCV-2220H-650-T from Abracon is a Multilayer Chip Varistor designed to enable high-density mounting. It has an AC voltage rating of up to 50 V, a DC voltage rating of 65 V, and a clamping voltage of less than 135 V. This RoHS-compliant varistor offers excellent solderability (Ni, Sn plating), clamping ratio, and voltage surge suppression capability. It is available in a surface-mount package that measures 5.7 x 5 x 2.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive-Grade Schottky Barrier Rectifier Diode | |
Power Diode
from Nexperia
|
| The PMEG4010EXD-Q from Nexperia is an Automotive-Grade Schottky Barrier Rectifier Diode that is ideal for high-efficiency DC-to-DC conversion, low voltage rectification, switch mode power supply, freewheeling application, reverse polarity protection, OR-ing applications. This AEC-Q101 qualified rectifier has a forward voltage of up to 530 mV and a forward current of up to 1 A. It has a reverse voltage of up to 40 V and a reverse current of less than 50 µA. |
| |
Download Datasheet
Product Details | |
|
|
|
| Single-Cell Lithium-Ion/Polymer Battery Protection IC | |
Battery Management IC
from ABLIC
|
| The S-821AAAB-I8T1U from ABLIC is a Single Cell Lithium Ion/Polymer Battery Protection IC. It incorporates a high-accuracy voltage detection circuit, a delay circuit, and a triple boost charge pump for improved battery performance. This RoHS-compliant BMIC operates over a temperature range of −40°C to +85°C and is available in a surface-mount package that measures 1.80 x 1.57 mm. It is suitable for lithium-ion rechargeable battery packs. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 32 V Automotive-Grade Isolated Gate Driver | |
Gate Driver
from STMicroelectronics
|
| The STGAP4S from STMicroelectronics is an Automotive-Qualified Isolated Gate Driver that has been designed to drive IGBTs and SiC MOSFETs. It requires an input voltage of 5-32 V (high-side) and from -10 V to 0 V (low-side). This driver is qualified as per the ISO 26262 standard and targets applications meeting up to ASIL-D. It galvanically isolates the low-side and high-side of the IC to ensure high reliability, and also includes separate protection, configuration, and diagnostics. |
| |
Download Datasheet
Product Details | |
|
|
|
| 125 A Fuse for EV Charging Protection Boards | |
EV Fuse
from Conquer Electronics
|
| The BMC 125 from Conquer Electronics is an Electric Vehicle Fuse that is designed for optimal protection against overload and short circuit events in high-power AC/DC circuits. It has a voltage rating of 240 V and a current rating of 125 A. This EV fuse has a breaking capacity of 160000 A at 240 V AC and 50000 A at 150 V DC. It has a cold resistance of 0.00060 ohms and has a power loss of 22 W. This RoHS-compliant EV fuse is available in a screw-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1000 W Non-Isolated DC-DC Converter | |
DC to DC Converter
from Vicor
|
| The DCM3717S60D13K0TN1 from Vicor is a Non-Isolated DC-DC Converter that steps down a DC input voltage of 40-60 V to a DC output voltage of 10-12.5 V. This buck converter delivers an output power of 1000 W and has an efficiency of 96.5%. It utilizes Vicor’s patented zero-voltage switching buck-boost regulator stage and sine amplitude converter for superior performance. This converter offers PMBus-compatible telemetry. |
| |
Download Datasheet
Product Details | |
|
|
|
| 2 A Automotive-Grade Motor Controller IC | |
Motor Driver IC
from TDK Corporation
|
| The HVC 5222D from TDK Corporation is an Automotive-Qualified Motor Controller IC that has been designed to drive brushed DC (BDC), brushless DC (BLDC), and stepper motors. It requires an input voltage of 6-18 V and provides an output current of up to 1 A (BLDC and stepper motors) and 2 A (DC motors). This IC is available in a thermally-efficient surface-mount package that measures 5 x 5 mm and has pins that are compatible with future devices. |
| |
Download Datasheet
Product Details | |
|
