| Featured Products this Week |
|
|
| 200 A Battery Pack Fuse | |
EV Fuse
from Mersen
|
| The MEV100A200-4 from Mersen is an Electric Vehicle Fuse that is designed for DC applications. It has a current rating of 200 A and a voltage rating of 1000 V. This EV Fuse has a minimum breaking capacity of 1510 A and a power dissipation of 7.4 W. It provides low watt losses and has high cycling performance. This EV fuse provides full coverage of the battery module voltage and current. It has a mass of 0.19 kg. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3 W Vehicle Control Unit | |
EV ECU
from Ecotron
|
| The EV22297A03 from ECOTRON is a Vehicle Control Unit that has been designed to act as the master controller for electric and hybrid vehicles. It requires an input voltage of 9-32 V. This vehicle control unit (VCU) has an input current of less than 1 mA and a rated power consumption of 3 W. It is based on Infineon’s 32-bit TC297TP chip that supports 8 MB flash memory, 728 KB SRAM, and 512 KB EEPROM. It is available in an IP67-rated package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 W Convection-Cooled AC-DC Power Supply | |
AC to DC Converter
from XP Power
|
| The AQM200PS15 from XP Power is a Convection-Cooled AC-DC Power Supply that converts an AC voltage of 85-264 V to a DC voltage of 15 V. It has a low standby power consumption of less than 150 mW and an efficiency of 92%. This IP-22 rated converter is fully compliant with international medical safety standards, including EN/IEC 60601-1 and 4th edition EMC requirements. It has a low earth leakage current and operates from 0 to 60°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1.5 V CMOS LDO Voltage Regulator | |
LDO Voltage Regulator
from Analog Devices
|
| The ADPL42005ACPZ-1.5-R7 from Analog Devices is a CMOS-Based Low Dropout Voltage Regulator that is ideal for the regulation of noise-sensitive applications such as ADC, DAC, precision amplifiers, clocks, and PLLs, communications and infrastructure, medical, healthcare, instrumentation, and industrial applications. It requires an input voltage of 4-20 V. This regulator provides an output voltage of 1.5 V and has a dropout voltage of 400 mV (at 200 mA). |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| Automotive-Qualified Flyback Transformer | |
Power Transformer
from Bourns
|
| The HVMA01F35A-ST10S from Bourns is an Automotive-Qualified Flyback Transformer. It has a working voltage of 900 V and a switching frequency of 100 to 400 kHz. This AEC-Q200-qualified transformer has a turns ratio of 1:1:1 and has an inductance of 35 µH. This RoHS-compliant transformer is available in a surface-mount package that measures 13 x 10.3 x 9.5 mm and is ideal for transistor gate drive power, inverter circuits and battery management systems. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 nH SMT High-Current Flatwire Inductor | |
Power Inductor
from Wurth Elektronik
|
| The 7443000910100 from Wurth Elektronik is an SMT High-Current Flatwire Inductor. It has an inductance of 100 nH with an inductive tolerance of ±15%. This inductor operates at 40 V DC and has a rated current of 78 A. It has a DC resistance of up to 0.33 milliohms and a coupling coefficient of 0.95. This RoHS/REACH-compliant inductor utilizes flat wire technology and has a saturation current of up to 190 A. It is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V Sensitive Gate Silicon Controlled Rectifier | |
Silicon Controlled Rectifier
from Littelfuse
|
| The S6002TSRP from Littelfuse is a Sensitive Gate Silicon Controlled Rectifier. It has a repetitive off-state voltage of over 600 V and an on-state RMS current of 2 A. This SCR has a sensitive gate that requires a gate trigger voltage of 0.8 V and a gate trigger current of 200 µA. It offers high static di/dt and low turn-off time through a small die planar construction, complemented by glass-passivated junctions for long-term reliability and parametric stability. |
| |
Download Datasheet
Product Details | |
|
|
|
| Three-Phase Bi-Directional On-Board Charger | |
On-Board Charger
from Current Ways
|
| The CWOBA1133Q from Current Ways is a Three-Phase Bi-Directional Isolated On-Board Charger. It requires an input voltage of 400 VAC and provides an output voltage of 550-850 VDC. This on-board charger delivers an output power of 11 kW. It is designed based on the Common Technology Platform and supports up to 8 SiC-based half-bridge modules. This reverse polarity protected charger includes modular magnetics and has a customizable front connector face. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| Non-Isolated Buck DC-DC Converter | |
DC to DC Converter
from Traco Power
|
| The TSR 0.5-24120 from Traco Power is a Non-Isolated Buck DC-DC Converter that converts an input voltage of 15-32 V to an output voltage of 12 V. It has an efficiency of 97%. This converter is designed to act as a drop-in replacement for LM78 linear switching regulators when energy efficiency is a crucial parameter to be considered during the design. It achieves excellent line/load regulation while maintaining a low standby current consumption for maximum efficiency. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V Half-Bridge Gate Driver IC | |
Gate Driver
from STMicroelectronics
|
| The STDRIVEG610 from STMicroelectronics is a Half-Bridge Gate Driver IC that has been designed to drive Enhancement Mode GaN power switches. This driver requires an input voltage of up to 600 V (high-voltage rails). It includes a control logic with an interlocking function, 2x gate drivers, N-channel MOSFETs arranged in a half-bridge configuration, and protection circuitries. This gate driver consists of low-side and high-side drivers. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4400 W Three-Phase Asynchronous Electric Motor | |
EV Traction Motor
from e-comer
|
| The AMAC 200 050 05 36 from e-comer is a Three-Phase Asynchronous Electric Motor that is ideal for e-mobility, cleaning, logistics, agriculture, construction, and marine applications. This AC motor includes an inverter that requires an input voltage of 36 V (DC). It delivers an output power of 4400 W and has an efficiency of 81%. This motor provides a torque of up to 18 Nm and has a speed of less than 4000 rpm. It has a modular design for better flexibility. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8:1 Fixed Ratio Digital Intermediate Bus Converter | |
DC to DC Converter
from Flex Power Modules
|
| The BMR3231000/001C from Flex Power Modules is an 8:1 Fixed Ratio Digital Intermediate Bus Converter (IBC) that converts an input voltage of 40-60 V to an output voltage of 5-7.5 V. It delivers an output power of 600 W and has an efficiency of 97.8%. This non-isolated converter has been intended for applications in need of a low-voltage IBC for improved system efficiencies. It offers a PMBus-compatible digital interface and is supported by the Flex Power Designer tool. |
| |
Download Datasheet
Product Details | |
|
