| Featured Products this Week |
|
|
| 3750 V Isolated Gate Driver IC | |
Gate Driver
from ROHM Semiconductor
|
| The BM79330FV-LBE2 from ROHM is an Isolated Gate Driver IC designed for safe and efficient driving of MOSFETs in industrial control and power switching applications. It requires an input voltage of 4.5-5.5 V and operates at a current of 40 mA. This gate driver IC features reinforced galvanic isolation rated at 3750 Vrms. It has a maximum propagation delay of 20 µs. It is available in a compact SOP package that measures 6.5 x 8.1 x 2.01 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 220 kW DC-AC Inverter | |
DC to AC Inverter
from Equipmake
|
| The HPI-450 from Equipmake is a DC-AC Inverter designed for high-speed automotive, heavy commercial, and aerospace EV applications. It requires a DC supply voltage of 400–800 V. This inverter delivers a continuous output power of up to 220 kW and has a peak power density of up to 30 kW/kg. It provides a peak output current of 450 A and a continuous output current of 300 A. This inverter supports switching frequencies from 1-20 kHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5 V Zero Drift Operational Amplifier | |
Power Operational Amplifier
from STMicroelectronics
|
| The TSZ901ILT from STMicroelectronics is a Zero Drift Operational Amplifier. It requires a supply voltage of 2.5-5.5 V and a low supply current of 1.5 mA at 5 V. This single op-amp has an offset voltage of 5 μV and a gain bandwidth product of 10 MHz. It features rail-to-rail input and output and offers high accuracy without any calibration needs. This operational amplifier is available in a surface-mount package that measures 2.90 x 2.80 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8-Channel LED Driver IC for Backlighting | |
LED Driver IC
from Kinetic Technologies
|
| The KTZ8869EUAD-TB from Kinetic Technologies is an 8-Channel LED Driver IC designed for LED backlighting and LCD bias power of medium-sized panels. It requires an input voltage of 2.7-5.5 V. This LED driver features two step-up converters, each of which can drive up to four current sinks. This LED driver has an LCD bias power section that generates dual outputs whose voltage levels can be programmed via an I2C interface. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Ultrafast Recovery Rectifier | |
Power Diode
from Micro Commercial Components
|
| The MURZ50120P-BP from Micro Commercial Components is an Ultrafast Recovery Rectifier. This power diode has a forward voltage of 1.65 V and an average forward current of up to 50 A. It has a reverse voltage of less than 840 V and a reverse current of 10 µA. This power diode has a repetitive peak reverse voltage of up to 1200 V. It is available in a through-hole package that measures 41.80 x 16.30 x 5.20 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 W AC-DC Power Supplies | |
AC to DC Converter
from Mean Well
|
| The NSP-750 Series from Mean Well are AC-DC Power Supplies that convert AC input voltages of 85-305 V to DC output voltages of 5-60 V. These AC-DC converters also accept DC input voltages of 120-431 V. They deliver output power of 750 W and have efficiencies of up to 95%. These OVC III-rated converters can operate from -40°C to +85°C and function at altitudes up to 5000 meters. These converters measure 129 x 97 x 30 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by 18th Solar PV & Energy Storage World Expo 2026 | | 18th Solar PV & Energy Storage World Expo 2026 | | The 18th Solar PV & Energy Storage World Expo 2026 will be held from September 16–18, 2026, in Guangzhou, China. The event will bring together global leaders to promote innovation and collaboration in the solar and energy storage industries. It will focus on advancements in photovoltaic technologies, energy storage systems, and smart energy solutions, driving the transition toward a sustainable and low-carbon future. Click here to learn more. | | | |
|
|
| 3.5 kW Solar Charge Controller | |
Solar Charge Controllers
from Schneider Electric
|
| The 865-1030-1 from Schneider Electric is a Solar Charge Controller designed to maximize energy harvest from photovoltaic (PV) arrays while delivering precise, multi-stage charging to battery systems. It supports 12-60 V DC battery banks and provides a charge current of up to 60 A. This controller handles PV array voltages up to 150 V. This IP20-rated controller is available as a module that measures 36.8 x 14.6 x 13.8 cm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Fast Acting Thin Film Chip Fuses | |
Fuses
from Vishay
|
| The S2F Series from Vishay are Fast Acting Thin Film Chip Fuses designed to ensure circuit continuity with minimal resistance and reliable interruption under overload conditions. They have a current rating of over 7 A. These UL 248-14 compliant fuses offer maximal protection as they are designed to open within 1 min at 200 % overload. They offer low resistance and have a body temperature rise of less than 75 °C at 100 % rated current. |
| |
Download Datasheet
Product Details | |
|
|
|
| Battery Pack Monitor for Grid Energy Storage | |
Battery Management IC
from Analog Devices
|
| The ADBMS2950B from Analog Devices is a Battery Pack Monitor IC for current or voltage sense applications. It requires an input voltage of 4.5-20 V. This battery management IC (BMIC) enables precise measurement of battery pack current by sensing the voltage drop across a shunt resistor. It supports redundant current measurement with dual current ADCs operating at a high sampling frequency of up to 4.5 MHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 120 V Hardwired Hybrid Surge Protective Device | |
Surge Suppression IC
from Bourns
|
| The 1202-120S from Bourns is a Type 1 Hardwired Hybrid Surge Protective Device (H-SPD) designed for 120 VAC single-phase AC infrastructure applications. It operates over a nominal voltage of 120 VAC and features a short-circuit current rating of up to 25 kA. This surge protector combines fast responding MOV technology with low leakage GDT technology. It is available in a panel-mount package that measures 59.5 x 59.5 x 69.0 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 640 W Solar Module | |
Solar Panels
from Longi
|
| The LR7-72HVD-640M from Longi is a Solar Module suitable for industrial and commercial cement roofs and high-temperature scenarios. It delivers a maximum power output of 640 W with a module efficiency of 23.7%. This solar module supports a maximum system voltage of 1500 V, with a power tolerance of 0-3%, and excels in harsh conditions. This solar module weighs 33.5 kg and measures 2382 x 1134 x 30 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 V Silicon Carbide MOSFET | |
MOSFET
from Infineon Technologies
|
| The IMBG75R007M2H from Infineon Technologies is a Silicon Carbide MOSFET. It has a drain-source breakdown voltage of 750 V and a drain-source resistance of 7.2 milli-ohms. This MOSFET supports a continuous drain current of 198 A at 25°C, a peak drain current of 844 A, and has a maximum power dissipation of 651 W. It operates with a gate-source voltage ranging from -7 to +23 V and has a gate threshold voltage of 4.5 V. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by 18th Solar PV & Energy Storage World Expo 2026 | | |
|
|
| Automotive-Grade Power Management ICs | |
PMIC
from ABLIC
|
| The S-19560B Series from ABLIC are Automotive-Grade Power Management ICs. It requires an input voltage of 4-16 V. These Power Management ICs (PMICs) are composed of a two-channel step-down switching regulator (step-down DC-DC converter) and a one-channel voltage regulator (LDO regulator). The DC-DC converters operate via PWM control, thereby achieving both high efficiency and low ripple voltage. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 A IGBT for High-Power Switching | |
IGBT
from Mitsubishi Electric
|
| The CM50MXUA-24T from Mitsubishi Electric is an IGBT Module designed to provide efficient high-power switching operation for a range of applications. It has a collector-to-emitter voltage of up to 1200 V and a gate-emitter voltage of ±20 V. This IGBT has a DC collector current of up to 50 A and a gate-emitter leakage current of less than 0.5 µA. It has a saturated collector-to-emitter voltage of less than 2.15 V and a power dissipation of up to 330 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 610 W P-Type Mono PERC Half-Cell Module | |
Solar Panels
from JA Solar
|
| The JAM78S30-610/GR from JA Solar is a P-Type Mono PERC Half-Cell Module designed for use on commercial and industrial roofs and in large-scale PV projects. It provides a maximum output power of 610 W with a peak current of 13.33 A and a voltage of 45.77 V. This IEC/UL-approved solar panel offers an efficiency of 21.8% and has a low temperature coefficient. This 156-cell solar panel is available as a module that measures 2465 x 1134 x 35 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 V N-Channel Power MOSFET | |
MOSFET
from iDEAL Semiconductor Devices
|
| The iS20M028S1P from iDEAL Semiconductor Devices is an N-channel power MOSFET. It has a drain-source voltage of over 200 V, a gate threshold voltage of 4.1 V, and a drain-source on-resistance of 25 milli-ohms. This MOSFET has a continuous drain current of up to 40 A, a pulsed drain current of 154 A, and a power dissipation of 100 W. It is available in a surface-mount package that measures 31.24 x 10.66 x 4.82 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Dual Output Step-Down DC-DC Converter | |
DC to DC Converter
from Calex Manufacturing
|
| The KMS30H24D15 from Calex Manufacturing is a Dual Output Step-Down DC-DC Converter that converts an input voltage of 24 V into a DC output of ±15 V. It has an input current of 20 mA at no-load condition and delivers an output current of up to 1000 mA. This CSA-approved power supply delivers an output power of 30 W and has an efficiency of up to 89%. It is available as a through-hole package that measures 50.8 x 40.6 x 9.3 mm. |
| |
Download Datasheet
Product Details | |
|
