| Featured Products this Week |
|
|
| 600 V High-Speed Gate Driver | |
Gate Driver
from Microchip Technology
|
| The MCP14LH2190 from Microchip Technology is a High-speed Gate Driver capable of driving N-channel MOSFETs and IGBTs in a half-bridge configuration. It integrates a floating high-side driver capable of bootstrap operation up to 600 V with a complementary low-side driver, enabling compact half-bridge implementations. This gate driver delivers high-current gate drive performance with typical sink/source currents of 4.5 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 W Industrial Grade AC-DC Power Supply | |
AC to DC Converter
from Advanced Energy Industries
|
| The SLB350 Series from Advanced Energy Industries are Industrial Grade AC-DC Power Supplies that converts an AC input voltage of 85-264 V to a DC output voltage of 12-56 V. They deliver an output power of up to 200 W. These single-output converters provide an input-output isolation voltage of up to 4000 VAC and have a switching frequency of over 100 kHz. These RoHS-compliant converters are available in open-frame packages that measure 3 x 5 x 1.5 inches. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Trench and Field Stop IGBT | |
IGBT
from Micro Commercial Components
|
| The MIW30N65AT2Y-BP from Micro Commercial Components is a Trench and Field Stop IGBT. It has a collector-emitter breakdown voltage of over 650 V, a gate threshold voltage of up to 5.8 V, and a collector-emitter saturation voltage of 1.75 V. This IGBT has a continuous collector current of up to 60 A and a pulsed collector current of 90 A. It has a power dissipation of less than 187 W. This IGBT has a high short circuit capability of 5 μs. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V Power MOSFET | |
MOSFET
from ROHM Semiconductor
|
| The RS7P200BMTB1 from ROHM Semiconductor is an N-Channel Power MOSFET. It has a drain-source breakdown voltage of 100 V, a gate threshold voltage of up to 4.0 V, and a drain-source on-resistance of less than 4 milli-ohms. This wide-SOA MOSFET has a continuous drain current of 200 A and has a power dissipation of 217 W. This RoHS-compliant MOSFET is available in a surface-mount package that measures 5.1 x 6.1 x 1.1 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Film Power Capacitors for DC Link Applications | |
Power Capacitor
from TDK Corporation
|
| The B25648A Series from TDK Corporation is a series of Modular Power Capacitors. They have a rated capacitance of 470-880 µF and a capacitance tolerance of ±10%. These film capacitors require a DC voltage of 1350-1800 V and a ripple voltage of up to 282 V. They have an operational bandwidth of up to 100 kHz and an inductance of 8 nH. These capacitors have a rated current of 180-205 A and a thermal resistance of 1.5 K/W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 18 V Automotive-Grade Isolated SiC Driver | |
Gate Driver
from Allegro MicroSystems
|
| The AHV85003K18ESTR from Allegro MicroSystems is an Automotive-Grade Self-Powered Isolated SiC Driver Chipset. It requires an input voltage of 10.5-13.2 V. It transmits both PWM signal and gate bias power through the external transformer, eliminating the need for any external auxiliary bias supply or high-side bootstrap. It is configured with the VSECP setting for a primary output of 18 V. It is available in a surface-mount package that measures 4.0 x 4.0 x 0.75 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| USB Power Delivery Dual-Role Power Controller | |
PMIC
from Diodes Incorporated
|
| The AP53781 from Diodes Incorporated is a USB Type-C® PD3.2 Dual-Role Power (DRP) Controller. It supports Extended Power Range (EPR)/Adjustable Voltage Supply (AVS) of up to 28 V with 100 mV/Step and Standard Power Range (SPR) of up to 21 V. It requires a power supply voltage of 3.6-31 V and an operating current of 2.5-6 mA. This DRP controller delivers an output voltage of 4.4-5.4 V and an output current of 30 mA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 20 A Signal and Power Hybrid Connector | |
Power Connector
from Hirose Electric
|
| The BH12WP-3SC from Hirose Electric is a Signal and Power Hybrid Connector. It has an AC voltage rating of 30 V, a DC voltage rating of 42 V, and a current rating of 20 A. This receptacle connector consists of three positions on the front side for connection and has a contact resistance of less than 10 milli-ohms. It can withstand 30 mating/unmating cycles. It is available in an IPX7-rated screw-mount package that measures 28 x 16.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V SiC Schottky Barrier Diode | |
Power Diode
from Fuji Electric
|
| The FDCC10S65 from Fuji Electric is a SiC Schottky Barrier Diode. It has a peak repetitive reverse voltage of over 650 V and a forward voltage of 1.8 V. This rectifier has a continuous forward current of up to 10 A and a reverse leakage current of up to 10 µA. It offers fast switching characteristics. This power diode is available in a surface-mount package that measures 10 x 9.5 x 4.5 mm and is ideal for switching power supplies, UPS, and solar applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| Toroid Power Inductor with Dual-Mode Inductance | |
Power Inductor
from iNRCORE
|
| The PL8300 from iNRCORE is a Power Inductor from the HCCI-80 toroid series. It features a dual-mode inductance configuration, delivering 4.52 µH with up to 9.5 A rated current in series mode, and 18.1 µH with up to 19 A rated current in parallel mode, supported by low DC resistance for efficient energy transfer. It has an operating temperature of 55°C to +130°C. It is available in a surface-mount package that measures 30.99 × 25.4 × 12.7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 500 mA CMOS LDO Regulator | |
LDO Voltage Regulator
from Sgmicro
|
| The SGM2037-1.2XN5G/TR from Sgmicro is a CMOS LDO Regulator. It requires an input voltage of 0.8-5.5 V and a bias voltage of 2.5-5.5 V. This LDO regulator provides a fixed output voltage of 1.2 V and has an output current capability of up to 500 mA. It delivers a low dropout voltage of 120 mV, shutdown current of 0.01 µA, and has a low quiescent current of 37 µA. This regulator features low output noise of 25 µVRMS. |
| |
Download Datasheet
Product Details | |
|
|
|
| 75 A Fluxgate Current Transducer | |
Current Transducer
from Hottinger Brüel & Kjær
|
| The CTS50ID from Hottinger Brüel & Kjær is a High-Precision Fluxgate Current Transducer designed for accurate, non-intrusive measurement of DC and AC currents. It supports AC currents of up to 50 A RMS and DC currents of ±75 A. This transducer has a bandwidth of 1000 kHz and a primary-secondary ratio of 1:500. It has an aperture size of 27.6 mm. This transducer is available in a panel-mount package that measures 121.4 x 107.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 5.5 A Integrated Half-Bridge Motor Driver IC | |
Motor Driver IC
from Power Integrations
|
| The BRD2365C-TL from Power Integrations is an Integrated Half-bridge Motor Driver IC. It has a breakdown voltage of over 600 V and an output current of up to 5.5 A. This motor driver IC delivers an efficiency of up to 99% and has a rated continuous RMS current of 1 A. It consumes less than 4 mW from a 325 VDC bus in sleep mode and supports complementary PWM control. It is available in a surface-mount package that measures 13.63 x 9.40 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 A Photovoltaic Fuse Link | |
Solar Fuse
from Mersen
|
| The NH1GR80V50B from Mersen is a Photovoltaic Fuse Link designed specifically for reliable overcurrent protection in photovoltaic systems. It has a rated voltage of 800 VAC and a rated current of 50 A. This fuse has a low power loss of 11 W. It features low fault current interrupting capability, excellent temperature cycling resistance, and durable construction for long-term reliability under harsh environmental conditions. |
| |
Download Datasheet
Product Details | |
|
|
|
| Power Management ICs for Flyback Converters | |
PMIC
from STMicroelectronics
|
| The SRK1004 Series from STMicroelectronics is a series of Synchronous Rectifier Controllers optimised for Non-Complementary Actively Clamped Flyback converter (NC-ACF), resonant flyback, and quasi-resonant flyback converters. These power management ICs (PMICs) require a supply voltage of 4-36 V. They can operate in both low-side and high-side configurations, with two different turn-off delays. These PMICs have a very low operating current of 580 µA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 W Automotive-Grade Asymmetric TVS Diode | |
Power Diode
from Littelfuse
|
| The TPSMB2818CA from Littelfuse is an Automotive-Grade Asymmetric TVS Diode designed for 12 V system reverse battery protection. It has a reverse standoff voltage of 28 V on the high side and 18 V on the low side. This TVS diode features a breakdown voltage range of 34.4 V (K to A) and 22.1 V (A to K), delivering strong clamping performance with maximum clamping voltages of 42.5 V and 29.2 V, respectively. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 A Insulated Schottky Rectifier | |
Power Diode
from Vishay
|
| The VS-QA100FA10 from Vishay is an Insulated Schottky Rectifier that is optimized for power conversion. It has a peak repetitive reverse voltage of over 100 V and a forward voltage of 1.03 V. This rectifier has a continuous forward current of up to 100 A, a reverse leakage current of up to 0.8 mA, and has a power dissipation of 67 W. It integrates two fully independent diodes and utilizes Trench MOS Barrier Schottky technology. |
| |
Download Datasheet
Product Details | |
|
