| Featured Products this Week |
|
|
| 9 V Synchronous Rectifier Controller IC | |
PMIC
from STMicroelectronics
|
| The SRK1004DTR from STMicroelectronics is a Synchronous Rectifier Controller optimized for Non-Complementary Actively Clamped Flyback converter (NC-ACF), resonant flyback, and quasi-resonant flyback converters. This power management IC (PMIC) requires a supply voltage of 9 V. It can operate in both low-side and high-side configurations, with two different turn-off delays. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4 A Cylindrical Fuse Link | |
Solar Fuse
from DF Electric
|
| The 492205 from DF Electric is a Cylindrical Fuse Link designed for reliable protection in photovoltaic string applications. It has a current rating of 4 A and a voltage rating of 1500V DC. This fuse link offers gPV-class protection against overloads and short-circuits as per IEC/EN 60269-6 and UL248-19 standards, with a breaking capacity of 30 kA. This fuse link weighs 14.5 g and measures 10.3 x 85 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Silicon Carbide Schottky Diode | |
Power Diode
from RIR Power Electronics
|
| The RIR120CDM040B from RIR Power Electronics is a Silicon Carbide Schottky Diode that is suitable for solar inverters, EV charging stations/OBCs, power factor correction, industrial motor drives, and induction heating/welding applications. It has a forward voltage of 1.7 V and can withstand reverse voltage of up to 1200 V. This diode has a forward current rating of 40 A and has a reverse current of less than 300 µA. |
| |
Download Datasheet
Product Details | |
|
|
|
| Isolated Opto-Emulator Gate Driver IC | |
Gate Driver
from Infineon Technologies
|
| The 1ED3010MC12I from Infineon Technologies is a Single-Channel Isolated Gate Driver IC designed as a pin-to-pin compatible drop-in replacement for opto-isolated gate drivers for use with IGBTs, Si, and SiC MOSFETs. It operates from 9.6-32 V and offers a source current of up to 6A and sink peak output current of 6.5 A. This gate driver has a propagation delay of 40 ns with 10 ns part-to-part matching (skew). |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Europe Battery Energy Storage Summit 2026 | | Europe Battery Energy Storage Summit 2026 | | The Europe Battery Energy Storage Summit 2026 will bring together industry experts, innovators, and policymakers to accelerate the development of advanced energy storage solutions across Europe. The event will focus on battery technologies, grid integration, renewable energy applications, sustainability strategies, and the evolving policy and investment landscape shaping the future of energy storage. Click here to learn more. | | | |
|
|
| 3.5 W Regulated Medical DC-DC Converters | |
DC to DC Converter
from XP Power
|
| The JMR03 Series from XP Power are Regulated Medical DC-DC Converters that convert input voltages of 4.5-75 V to single and dual output voltages of 5-30 V DC. These ultra-compact converters deliver an output current of up to 700 mA, an output power of 3.5 W, and have efficiencies of over 82%. These converters are available in through-hole packages that measure 24.4 x 14.7 x 10.8 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3000 A High-Precision AC/DC Current Transducer | |
Current Transducer
from Danisense
|
| The DL2000ID from Danisense is a High-Precision AC/DC Current Transducer. It can continuously measure current levels of up to 3000 A with a linearity error of less than 1 ppm. This current transducer requires a power supply of up to +/-15.75 V and consumes a current of up to 2.2 A. It is based on the ultra-stable Danisense closed-loop flux gate technology that offers very low offset and ultra-low drift. |
| |
Download Datasheet
Product Details | |
|
|
|
| SMD Power Inductors for DC-DC Converter | |
Power Inductor
from Vishay
|
| The IHLL1210AB-1Z Series from Vishay are Power Inductors that have an inductance of 0.22-4.7 µH and a tolerance of ±20%. These power inductors have a saturation current of 2.5-11.5 A. They have a magnetically shielded composite construction and handle high transient current spikes without saturation. They are available in surface-mount packages that measure 3.2 x 2.5 x 1.2 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 W Radiation-Tolerant DC-DC Converters | |
DC to DC Converter
from VPT
|
| The VSCPL1210SG Series from VPT are Radiation Tolerant DC-DC Converters that convert an input voltage of 4.5-13.2 V to an output voltage of 0.6-5 V. They deliver an output power of up to 50 W and have an efficiency of 94%. They are radiation-tested for single event effects (SEE) to 42 MeV/mg/cm2, tested to 40 krad (Si), and ensure withstanding capability up to 30 krad (Si) for total ionising dose (TID). |
| |
Download Datasheet
Product Details | |
|
|
| Featured Interview | | Featured Interview | | everything PE recently interviewed Gary Sapia, Director, Power Systems Engineering; Geir Ostrom, ADI Fellow, Automotive Business Unit and Etienne Moulin, General Manager, High Performance Power at Analog Devices. Analog Devices specialises in designing and manufacturing analog, mixed-signal, and digital signal processing integrated circuits. Click here to learn more. | | | |
|
|
| 600 V High-Speed Gate Driver | |
Gate Driver
from Microchip Technology
|
| The MCP14H2104 from Microchip Technology is a High-speed Gate Driver capable of driving N-channel MOSFETs and IGBTs in a half-bridge configuration. It integrates a floating high-side driver capable of bootstrap operation up to 600 V with a complementary low-side driver, enabling compact half-bridge implementations. This gate driver has a source current of 290 mA and a sink current of 600 mA. |
| |
Download Datasheet
Product Details | |
|
|
|
| Dual-Mode Toroid Power Inductor | |
Power Inductor
from iNRCORE
|
| The PL8301 from iNRCORE is a Power Inductor from the HCCI-80 toroid series. It features a dual-mode inductance configuration, delivering 12.8 µH with up to 12 A rated current in series mode, and 3.2 µH with up to 24 A rated current in parallel mode, supported by low DC resistance for efficient energy transfer. It is available in a surface-mount package that measures 30.99 × 25.4 × 12.7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6 A Inrush Current Limiter | |
Inrush Current Limiter
from Semitec
|
| The 6D2-22LDTR from Semitec is an Inrush Current Limiter. It has a rated zero-power resistance of 6 ohms and a resistance tolerance of ± 15%. This inrush current limiter has a rated current of 6 A and a dissipation factor of 43 mW/oC. It has a thermal time constant of 130 s and an energy surge capacity of 63 J. This thermistor is available in a through-hole package that measures 23.0 x 8.5 x 26.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 75 V Silicon Epitaxial Planar Zener Diode | |
Power Diode
from Toshiba
|
| The CUHZ75V from Toshiba is a Silicon Epitaxial Planar Zener Diode with a zener voltage of 75 V at a test current of 2 mA. It has a dynamic resistance of 1.5 ohms and provides a peak pulse power of 1250 W. This Zener diode has an electrostatic discharge voltage of ±30 kV and a peak pulse current of 10 A. It is available in a surface-mount package that measures 2.50 x 1.40 x 0.60 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Europe Battery Energy Storage Summit 2026 | | |
|
|
| 21 F Radial Lead-Type Supercapacitor | |
Supercapacitor
from Nippon Chemi Con
|
| The DDKA2R5ELL210MM26T from Nippon Chemi Con is a Radial Lead-Type Supercapacitor that is ideal for a backup power supply for automotive electrical components. It has a capacitance of 21 F and a capacitance tolerance of ±20%. This supercapacitor has a voltage rating of 2.5 V and an equivalent series resistance of less than 30 milli-ohms. It has a lifetime of 2000 hours when operated at 2.5 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| Double Channel Gate Driver | |
Gate Driver
from Power Integrations
|
| The 2SP0230T2A0-CAS300M17BM2 from Power Integrations is a Double Channel Gate Driver designed for the operation of 62 mm half-bridge SiC and IGBT power modules up to 1700 V. It requires an input voltage of 14.5-15.5 V. This compact plug-and-play gate driver provides an output gate current of ±30 A. It is available in a surface-mount package that measures 134.14 x 62 x 6.2 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Low-Current Synchronous Buck Converter | |
DC to DC Converter
from Diodes Incorporated
|
| The AP61040CP6-7 from Diodes Incorporated is a Low-Current Synchronous Buck Converter that converts an input voltage of 2.15-5.5 V to an output voltage of 0.6-5.5 V. It provides an output current of 400 mA and has a quiescent current of 930 nA to maximize light-load efficiency. This DC-DC converter provides high efficiency, excellent transient response, and high DC output accuracy. |
| |
Download Datasheet
Product Details | |
|
