| Featured Products this Week |
|
|
| 12.5 A Surface-Mount Nano Fuse | |
Fuses
from Littelfuse
|
| The 0415001.DRSP from Littelfuse is a Surface-Mount Fuse. It has a voltage rating of 277 V and a current rating of up to 12.5 A. This RoHS-compliant fuse has a nominal melting I²t value of 0.055-340 A²s and an interrupt rating of 1500 A. It is available in a surface-mount package that measures 15 x 5 mm and is suitable for power supplies, lighting systems, industrial equipment, and white goods. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Trench and Field Stop IGBT | |
IGBT
from Micro Commercial Components
|
| The MIW40N65AT2Y-BP from Micro Commercial Components is a Trench and Field Stop IGBT. It has a collector-emitter breakdown voltage of over 650 V, a gate threshold voltage of up to 6.1 V, and a collector-emitter saturation voltage of 2 V. This IGBT has a continuous collector current of up to 80 A and a pulsed collector current of 120 A. This IGBT has a power dissipation of less than 187 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V N-Channel SiC MOSFET | |
MOSFET
from RIR Power Electronics
|
| The RIR120CMF040B4N from RIR Power Electronics is an N-Channel SiC MOSFET. It has a drain-source breakdown voltage of 1200 V, a gate threshold voltage of up to 4.5 V, and a drain-source on-resistance of less than 40 milli-ohms. This MOSFET has a continuous drain current of 62 A and has a power dissipation of 288 W. It is available in a through-hole package that measures 41.02 x 15.94 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V GaN Half-Bridge Transistor | |
GaN Power Transistor
from Infineon Technologies
|
| The IGI60L2727B1M from Infineon Technologies is a GaN Half-Bridge Transistor that is ideal for low-power motor drives and SMPS utilizing the superior switching behavior of CoolGaN power switches. This GaN transistor has a drain-source voltage of up to 600 V, a gate threshold voltage of less than 1.2 V, and a drain-source on-resistance of 270 milli-ohms. It has a continuous drain current of up to 4.8 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V Circular Power Connector | |
Power Connector
from Bulgin
|
| The EXP-0911-05-S-1 from Bulgin is a Circular Power Connector that is designed for applications in hazardous areas. It has a rated voltage of 600 V and a rated current of up to 18 A. This power connector accommodates cables with diameters ranging from 7 mm to 15 mm and accepts contact sizes from 2.5 mm² to 4 mm² (10-14 AWG). This IP68-rated connector offers waterproof and dustproof protection. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by APEC 2026 | | APEC 2026 | | APEC 2026, is a premier international conference uniting experts and innovators across power electronics, components, and systems. This event brings together industry leaders, researchers, and engineers to explore cutting-edge technologies, foster collaboration, and shape the future of energy-efficient electronics. Click here to learn more. | | | |
|
|
| Three-Phase Half-Bridge Gate Driver IC | |
Gate Driver
from Microchip Technology
|
| The MCP8062136 from Microchip Technology is a Three-Phase Half-Bridge Gate Driver IC designed for high-voltage and high-speed applications. It requires a supply voltage of 10-20 V. This gate driver is designed to drive N-channel MOSFETs and IGBTs in a half-bridge configuration. It enables high-side drive of up to 600V in bootstrap operation and supports peak source/sink current of up to 350 mA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1-Cell Li+ Battery Charger for USB Type-C Power Delivery | |
Battery Management IC
from Analog Devices
|
| The MAX77786 from Analog Devices is a 1-Cell Li+ Battery Charger ideal for USB Type-C Power Delivery (PD) applications. This battery management IC (BMIC) supports fast-charge currents up to 5.5 A and achieves 90% buck efficiency at 4 A with a 15 V input, operating at a 1.3 MHz switching frequency with a compact 1 µH inductor. It operates over an input voltage range of 4.7 V to 18.2 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| 11 A Negative Temperature Coefficient Thermistor | |
Inrush Current Limiter
from Songtian Electronics
|
| The 1D-25 from Songtian Electronics is a Negative Temperature Coefficient Thermistor that is ideal for power supply, electronic motors, transformers, adapters, projectors, halogen machines, and LED drive applications. It has a current rating of 11 A and a resistance of 1 ohm. This thermistor has a heat dissipation coefficient of over 30 mW/°C and operates over a temperature range from -40°C to +200°C |
| |
Download Datasheet
Product Details | |
|
|
|
| 24 V True Sine Wave Power Inverter | |
DC to AC Inverter
from Exeltech
|
| The XP-6-0-2-5-1 from Exeltech is a True Sine Wave Power Inverter that converts a DC input voltage of 24 V to an AC output voltage of 100 V. It delivers an output power of 1100 W (continuous) and has an operating frequency of 50 Hz. It offers a high degree of ruggedness to withstand the harshest mobile environments. It is available in a chassis-mount package that measures 3.57 x 7.69 x 12.10 inches. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8 A Surge Current Limiter | |
Inrush Current Limiter
from Ametherm
|
| The SL22 10008 from Ametherm is a Surge Current Limiter that has been designed to protect electrical systems by mitigating the impact of potentially harmful power surges. It has a current rating of 8 A (steady state) and a resistance of 10 ohms. This current limiter can handle up to 90 J of surge energy and has a dissipation constant of 32.4 mW/°C. It is available in a through-hole package that measures 20 x 5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 12 V AC-DC Single-Output Power Supply | |
AC to DC Converter
from XP Power
|
| The ECE05US12 from XP Power is an AC-DC Single-Output Power Supply that converts an AC input voltage of 85-264 V to a single DC output voltage of 12 V. This converter delivers an output power of 5 W and offers an efficiency of 82%. It provides two options that include open-frame and encapsulated PCB mount designs. It is available in a surface-mount package that measures 25.4 x 25.4 x 15.24 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 605 W Monocrystalline Solar Panel | |
Solar Panels
from HT Saae
|
| The HT60-210-605W from HT Saae is a Monocrystalline Solar Panel. It has an operating voltage of 35.1V, an operating current of 17.25A and delivers an output power of up to 605 W. This solar panel has a maximum system voltage of 1500 V DC and offers a module efficiency of 21.4%. It operates from -40 to 85°C and weighs 30.5 kg. This solar panel measures 2172 x 1303 x 35 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 300 A Phase Leg IGBT Power Module | |
IGBT
from Microchip Technology
|
| The APTGX300A170TDP3EG from Microchip Technology is a Phase Leg IGBT Power Module. It has a collector-emitter voltage of up to 1700 V, a gate threshold voltage of 5.15-6.45 V, and a saturated collector-emitter voltage of up to 2.1 V. This low-profile IGBT has a continuous collector current of up to 300 A and a pulsed collector current of less than 600 A. This IGBT has a power dissipation of 1311 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive-Grade NTC Thermistor | |
Inrush Current Limiter
from TDK Corporation
|
| The NTCSP164KF104FT1H from TDK Corporation is an Automotive-Grade Negative Temperature Coefficient Thermistor that is designed for conductive glue mounting. It has a resistance value of 100000 ohms with a tolerance of ± 1%. This multilayer chip thermistor has a power rating of 150 mW and a B-constant of 4419-4509 K. It is available in a surface-mount package that measures 1.6 x 0.8 x 0.8 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 W AC-DC Isolated Power Factor Corrected Converter | |
AC to DC Converter
from Gaia Converter
|
| The HGMB-50-W-17 from Gaia Converter is an AC-DC Isolated Power Factor Corrected Module that converts an input voltage of 95-140 V to an output voltage of 17 V. This dual-output converter features a galvanic isolation of up to 1500 VAC and operates over a temperature range of -40 to 85°C. It delivers an output power of up to 50 W and has an efficiency of up to 80%. |
| |
Download Datasheet
Product Details | |
|
