| Featured Products this Week |
|
|
| 4500 W Industrial AC-DC Power Supply | |
AC to DC Converter
from TDK Corporation
|
| The TPS4500-92/184 from TDK Corporation is an Industrial AC-DC Power Supply that converts an AC input voltage of 360–528 VAC to a DC output voltage of 92–184 V. It delivers an output power of up to 4500 W and has an efficiency of 93%. This converter can be connected in series or in parallel to increase the output voltage or power and can be used as a single or a dual output, sharing the loads in any proportion up to the rated output. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 kV SiC MOSFET for Mid- and High-Voltage Applications | |
MOSFET
from Wolfspeed
|
| The CPM3-10000-0300A from Wolfspeed is a Silicon Carbide MOSFET developed to maximise the performance and simplify the design architecture of mid and high-voltage applications. It has a drain-source breakdown voltage of 10000 V, a gate threshold voltage of 2.8 V, and a drain-source on-resistance of less than 380 milli-ohms. This MOSFET has a total charge of 268 nC and a reverse transfer capacitance of 3.4 pF. |
| |
Download Datasheet
Product Details | |
|
|
|
| MPPT Solar Charge Controller for PV Systems | |
Solar Charge Controllers
from EPEVER
|
| The XTRA1206N G3/G3 BLE from EPEVER is an MPPT Solar Charge and Discharge Controller designed for rapid power tracking and efficient solar energy utilization. It supports 12/24 VDC automatic battery recognition and is compatible with multiple battery chemistries, including lithium, gel, and sealed lead-acid batteries. This controller offers a conversion efficiency of up to 97.9% and an MPPT efficiency exceeding 99.5%. |
| |
Download Datasheet
Product Details | |
|
|
|
| 2 A Surface-Mount Nano Fuse | |
Fuses
from Littelfuse
|
| The 0415002.DRSP from Littelfuse is a Surface-Mount Nano Fuse. It has a voltage rating of 277 V and a current rating of up to 2 A. This RoHS-compliant fuse has a nominal melting I²t value of 12 A²s and an interrupt rating of 1500 A. This nano fuse is available in a surface-mount square package that measures 15 x 5 mm and is suitable for power supplies, lighting systems, industrial equipment, and white goods. |
| |
Download Datasheet
Product Details | |
|
|
|
| 32 V Automotive-Grade Isolated Gate Driver | |
Gate Driver
from STMicroelectronics
|
| The STGAP2SAC from STMicroelectronics is a Galvanically Isolated Single Gate Driver. It requires a TTL or CMOS-based input voltage of 3.1-5.5 V. This gate driver provides galvanic isolation up to ±1200 V, ensuring safe operation while protecting the low-voltage control and interface circuitry. It offers a source capability of 4 A and a sink capability of 4 A, making it ideal for mid- and high-power automotive and industrial applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V SiC Schottky Barrier Diode | |
Power Diode
from Micro Commercial Components
|
| The SIC10120G4JQ-BP from Micro Commercial Components is a Silicon Carbide (SiC) Schottky Barrier Diode designed for high-efficiency, high-frequency power conversion in compact power electronics systems. It has a peak repetitive reverse voltage of over 1200 V, and a forward voltage of 1.55 V. This rectifier has a continuous forward current of up to 31 A and a reverse leakage current of up to 25 µA. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by 4th European Automotive Decarbonization and Sustainability Summit 2026 | | | |
|
|
| Multifuse PPTC Resettable Fuses | |
Fuses
from Bourns
|
| The MF-LSMF Series from Bourns is a family of Multifuse PPTC Resettable Fuses. They are designed to protect electronic circuits against overcurrent with fast trip performance, high voltage capability, and long-term reliability. These low-profile fuses have voltage ratings from 6-72 V and power dissipation of up to 2 W. They provide fast time-to-trip performance and have low resistance for efficient circuit protection. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V GaN Half-Bridge Transistor | |
GaN Power Transistor
from Infineon Technologies
|
| The IGI60L1111B1M from Infineon Technologies is a GaN Half-Bridge Transistor that is ideal for low-power motor drives and SMPS utilising the superior switching behaviour of CoolGaN power switches. This GaN transistor has a drain-source voltage of up to 600 V, a gate threshold voltage of less than 1.2 V, and a drain-source on-resistance of 110 milli-ohms. It has a continuous drain current of up to 7.4 A, and a pulsed drain current of less than 30 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| Half-Cell Bifacial Monocrystalline PERC PV Modules | |
Solar Panels
from Znshine
|
| The ZXM8-TPLDD110 Series from Znshine is a Half-Cell Bifacial Double-Glass Monocrystalline PERC PV Module. They deliver output power ranging from 535 W to 560 W at STC (Standard Test Condition) and from 402.10 W to 420.80 W at NMOT (Nominal Module Operating Temperature), with a maximum module efficiency of up to 21.43%. These solar panels provide a maximum power voltage of 31-32 V, and a maximum current of up to 17.5 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| Power-Saving Energy Harvesting Power Supply Control | |
Battery Management IC
from ROHM Semiconductor
|
| The ML9077GDZ05B from ROHM Semiconductor is a Power-Saving Energy Harvesting Power Supply Control LSI designed to control the charging of energy harvester current to a rechargeable battery. This energy harvesting control IC supports direct charging of the energy harvester current to a rechargeable battery with a potential difference as low as 0.1 V when VSC is greater than 2 V. It features an extremely low operating current of approximately 80 nA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 40 V Rad-Hard eGaN Power HEMT | |
GaN Power Transistor
from EPC Space
|
| The FBG04N08AC from EPC Space is a Radiation-Hardened eGaN Power Switching HEMT that has been specifically designed for critical applications in commercial satellite space and other high-reliability environments. It has a drain-source voltage of over 40 V, a gate-source threshold voltage of 1.4 V, and a drain-source on-resistance of less than 28 milli-ohms. This transistor has a continuous drain current of up to 8 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1 mH Automotive-Grade Common Mode Choke | |
Power Inductor
from Coilcraft
|
| The CMA1305-105LD from Coilcraft is an Automotive-Grade Common Mode Choke for power line applications. This power inductor has an inductance of 1 mH and a common mode peak impedance of 4.1 kilo-ohms at 2.5 MHz. It has an RMS current of 2.1 A and a DCR of less than 86 milliohms. This inductor features high isolation voltage up to 1500 V. It is available in a surface-mount package measuring 13 x 13 x 5.6 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by 4th European Automotive Decarbonization and Sustainability Summit 2026 | | |
|
|
| Automotive-Qualified Thin Film Power Resistor | |
Power Resistor
from Vishay
|
| The CHA02016-100RGFTF from Vishay is an Automotive-Qualified Thin Film Power Resistor that has a very large range of frequency from DC to 70 GHz. This AEC-Q200-qualified resistor has a resistance of 100 ohms and a resistance tolerance of up to ±5%. It has a power rating of up to 0.100 W and a limiting element voltage of up to 30 V. This RoHS-compliant resistor utilizes advanced flip-chip metal film technology. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1.6 V Photorelay for Test and Measurement | |
Power Switch IC
from Toshiba
|
| The TLP3412SRLB from Toshiba is a Photorelay that is suitable for ATE (Automatic Test Equipment), probe cards, measuring instruments, high-speed logic IC testers, and high-speed memory tester applications. It requires a maximum forward voltage of 1.6 V and can handle an on-state current of up to 400 mA. This normally-open photorelay has an on-state resistance of less than 1.5 ohms and an isolation voltage of 500 Vrms. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q100 Qualified CMOS-Based Positive Voltage Regulators | |
LDO Voltage Regulator
from ABLIC
|
| The S-19243xxxH from ABLIC are Automotive-Grade CMOS-based Positive Voltage Regulators. These LDO regulators require an operational voltage of 2.5-10 V. They provide an output voltage of 0.9-6 V and have a low current consumption of 2.0 µA. These LDO regulators are based on CMOS technology and deliver a high output current of 120 µA. These AEC-Q100 qualified LDO regulators are ideal for automotive use. |
| |
Download Datasheet
Product Details | |
|
|
|
| 20 W Regulated Medical DC-DC Converter | |
DC to DC Converter
from XP Power
|
| The JMR2024S12 from XP Power is a Regulated Medical DC-DC Converter that converts an input voltage of 9-36 V to an output voltage of 12 V DC. This ultra-compact converter delivers an output current of 1670 mA, an output power of 20 W, and has an efficiency of 88.5%. This converter is compliant with IEC 60601-1 medical safety standards. It offers a 4:1 input voltage range, with a ±10% output trim, and operates from -40°C to +100°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 250 V Single-Phase Power-Line Filter | |
EMI / EMC Filter
from Kemet Corporation
|
| The FLLE2005ASRW2 from Kemet Corporation is a Single-Phase Power Line Filter that is ideal for shielded, compartment-type screened rooms, secure communications areas, and MRI-screening applications. It has a rated voltage of 250 V and a rated current of 5 A. This filter offers high attenuation performance with high accuracy in a robust construction, resulting in an optimized industry-standard performance. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 W DC/AC Sine Wave Inverter | |
DC to AC Inverter
from Premium PSU
|
| The ODS-750-7277-U from Premium PSU is a DC/AC Sine Wave Inverter that converts a DC input voltage of 154 V to an AC output voltage of 230 V. This inverter has a nominal input voltage of 110 V and provides an output current of 13 A. It delivers a power of 750 W and achieves an efficiency of 89%. This inverter offers high input-to-output isolation of 3000 V. It operates over a temperature range from −25°C to +55°C. |
| |
Download Datasheet
Product Details | |
|
