| Featured Products this Week |
|
|
| 1200 V Automotive-Grade SiC Power Module | |
MOSFET
from ROHM Semiconductor
|
| The BST70B2P4K01-VC from ROHM Semiconductor is an Automotive-Grade SiC Power Module that is ideal for inverters, converters, automotive, and electric vehicle applications (EV, HEV). It has a drain-source breakdown voltage of over 1200 V, a gate threshold voltage of up to 4.8 V, and a drain-source on-resistance of less than 44 milli-ohms. It has a continuous drain current of up to 70 A and a power dissipation of 385 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3-Phase Motor Controller for BLDC Motor | |
Motor Driver IC
from STMicroelectronics
|
| The STSPIN32G4 from STMicroelectronics is a Three-phase Motor Controller with an embedded STM32G4 MCU. It is designed for driving 3-phase brushless motors, helping designers to choose the most suitable driving mode and reduce PCB area and overall Bill of Materials. This motor controller operates from a 5.5 V to 75 V motor supply voltage. It incorporates an embedded buck converter of up to 200 mA with programmable output and an embedded MOSFET. |
| |
Download Datasheet
Product Details | |
|
|
|
| 385 W Monocrystalline PERC Solar Panel | |
Solar Panels
from Heliene
|
| The 108HC M10 SL 385W from Heliene is a Monocrystalline PERC Solar Panel that utilizes 108 half-cut M10 (182 mm) cells. It delivers a peak power output of 385 W with a maximum power voltage of 30.85 V and a maximum power current of 12.48 A. This solar panel has an open-circuit voltage of 36.95 V and a short-circuit current of 13.24 A. It offers a module efficiency of 19.7% under standard test conditions (STC). It has a maximum series fuse rating of 30 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 16 A Single-Phase AC Line Filter | |
EMI / EMC Filter
from Schurter
|
| The 5500.2605.04 from Schurter is a Single-Phase AC Line Filter that is designed for current applications. It has an inductance of 0.65 mH and a capacitance of 0.33 nF. This AC filter has a current rating of 16 A. It has a power loss of 4.1 W and a resistance of 8 milli-ohms. This medical (M5) broadband filter uses a quick-connect terminal measuring 6.3 x 0.8 mm. It is available as a module that measures 90 x 51 x 41 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Trench and Field Stop IGBT | |
IGBT
from Micro Commercial Components
|
| The MIW40N120AH2Y-BP from Micro Commercial Components is a Trench and Field Stop IGBT. It has a collector-emitter breakdown voltage of over 1200 V, a gate threshold voltage of up to 6.6 V, and a collector-emitter saturation voltage of 1.95 V. This IGBT has a DC collector current of up to 80 A and a pulsed collector current of 120 A. It has a power dissipation of less than 288 W. It is available in a through-hole package that measures 40.32 x 15.50 x 4.80 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Europe Battery Energy Storage Summit 2026 | | Europe Battery Energy Storage Summit 2026 | | The Europe Battery Energy Storage Summit 2026 will bring together industry experts, innovators, and policymakers to accelerate the development of advanced energy storage solutions across Europe. The event will focus on battery technologies, grid integration, renewable energy applications, sustainability strategies, and the evolving policy and investment landscape shaping the future of energy storage. Click here to learn more. | | | |
|
|
| 440 A Hybrid Charge Controller | |
Wind Turbine Charge Controllers
from Missouri Wind and Solar
|
| The SKY440-HY12V from Missouri Wind and Solar is a Hybrid Charge Controller that is ideal for wind, solar, and hydro power systems. It is designed for 12 V, 24 V, or 48 V battery banks and features dual metering that simultaneously displays voltage, current, power, and energy production from each charging source, enabling comprehensive system monitoring. This controller uses dual microprocessor control for stable, precise regulation. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Automotive-Grade SiC MOSFET | |
MOSFET
from Wolfspeed
|
| The EDB010M12TM4L from Wolfspeed is an Automotive-Grade Silicon Carbide MOSFET Module. It has a drain-source voltage of 1200 V, a gate threshold voltage of 3.6 V, and a drain-source on-resistance of over 9.3 milli-ohms. This SiC MOSFET has a continuous drain current of 160 A and has a Comparative Tracking Index (CTI) greater than 600 V. It uses a high-performance Si3N4 insulator and ultra-reliable interconnect technologies. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 V GaN Half-Bridge Transistor | |
GaN Power Transistor
from Infineon Technologies
|
| The IGI60L5050B1M from Infineon Technologies is a GaN Half-Bridge Transistor that is ideal for low-power motor drives and SMPS utilising the superior switching behaviour of CoolGaN power switches. This GaN transistor has a drain-source voltage of up to 600 V, a gate threshold voltage of less than 1.2 V, and a drain-source on-resistance of 500 milli-ohms. It has a continuous drain current of 3 A and a pulsed drain current of 6.7 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 450 W True Sine Wave DC-AC Power Inverter | |
DC to AC Inverter
from Mean Well
|
| The NTS-450-124UN from Mean Well is an Off-Grid True Sine Wave DC-AC Power Inverter that converts a DC input voltage of 24 V to an AC output voltage of 110 V. It delivers an output power of 450 W. This inverter provides a true sine wave output signal. It features a digital design with a microcontroller unit (MCU) and streamlined control circuitry that quickly responds to environmental changes and improves reliability. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q200-Qualified High-clearance and Creepage Transformer | |
Power Transformer
from Bourns
|
| The HCTSM151207FAL from Bourns is an AEC-Q200-qualified High-clearance and Creepage Transformer designed for energy storage systems, high-voltage and high-current DC meters, CAN-interface digital input modules, and RS-485/RS-232 isolation. This transformer has a primary inductance of 400 µH and a secondary inductance of up to 70 µH. This transformer provides a Hi-Pot DC voltage of 7640 V at 1 mA and has a DC resistance of 1.0-1.5 ohms. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Europe Battery Energy Storage Summit 2026 | | |
|
|
| 1.2 V Embedded Silicon Capacitor | |
Power Capacitor
from Empower Semiconductor
|
| The EC2005P from Empower Semiconductor is an Embedded Silicon Capacitor designed to meet the power integrity demands of next-generation AI and high-performance computing (HPC) processors. This multi-domain capacitor has a capacitance of 9.34 µF and an operating voltage of 1.2 V. It is designed using deep trench capacitor technology. This Si capacitor features ultralow equivalent series inductance (ESL) and equivalent series resistance (ESR). |
| |
Download Datasheet
Product Details | |
|
|
|
| 110 W Foldable Solar Panels | |
Solar Panels
from Tommatech
|
| The TT-FLEX-FBAG-110 110Wp Series from Tommatech are Foldable Solar Panels. They have a rated voltage of 18.84 V and an output current of 5.90 A. These solar panels have a power rating of 110 W and support a system voltage of up to 1000 VDC. They feature high-efficiency IBC solar cell technology combined with a prism surface design. These solar panels have an open circuit voltage of 22.80 V and a short circuit current of 6.33 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 120 W Single-Phase AC-DC Power Supply | |
AC to DC Converter
from TDK Corporation
|
| The D1SE120-24-A5 from TDK Corporation is a Single-Phase AC-DC Power Supply that converts an AC input voltage of 100-240 V to a nominal DC output voltage of 24 V. It requires input DC voltages of 93-300 V and has a power factor of 0.92. This converter delivers an output power of 120 W and has an efficiency of up to 92%. It includes a power boost capability and has a sophisticated thermal design for minimal installation clearances. |
| |
Download Datasheet
Product Details | |
|
|
|
| Rad-Hard Multifunctional Power Module | |
GaN Power Transistor
from EPC Space
|
| The FBS-GAM02-P-R50 from EPC Space is a Radiation-Hardened Multifunctional Power Module that incorporates eGaN® switching power HEMTs with an intended end-use design within commercial satellite space environments. This GaN transistor has a drain-source voltage of up to 1.15 V and a drain-source on-resistance of 28 milli-ohms. It has a continuous drain current of up to 10 A and a pulsed drain current of less than 15 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3.5 kW Solar Charge Controller | |
Solar Charge Controllers
from Schneider Electric
|
| The 865-1030-1 from Schneider Electric is a Solar Charge Controller designed to maximize energy harvest from photovoltaic (PV) arrays while delivering precise, multi-stage charging to battery systems. It supports 12-60 V DC battery banks and provides a charge current of up to 60 A. This controller handles PV array voltages up to 150 V, with a maximum output power of approximately 3.5 kW on 48 V systems. It is available as a module that measures 36.8 x 14.6 x 13.8 cm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Integrated Two-Phase SPI Boost Controller | |
PMIC
from Diodes Incorporated
|
| The AL8859Q from Diodes Incorporated is an Automotive-Grade Integrated Two-Phase SPI Boost Controller designed for high-power and high-efficiency power systems. It has an input voltage of 4.5-60 V and provides a regulated output voltage with an accuracy of ±0.5% at 50V. This AEC-Q100 Grade 1 controller features soft-start and offers efficiency of up to 95%. It has a programmable SPI interface with up to 4-phase control, switching current limit, and overvoltage protection. |
| |
Download Datasheet
Product Details | |
|
