| Featured Products this Week |
|
|
| 3400 F Double Layer Capacitor | |
Supercapacitor
from LS Materials
|
| The LSUC 02R85C 3400F NH from LS Materials is a Double Layer Capacitor designed for energy storage applications that undergo very frequent charge and discharge cycles at high current and short duration. It has a capacitance of 3400 F and a capacitance tolerance of ±5%. This supercapacitor has a voltage rating of 2.85 V and an equivalent series resistance (ESR) of less than 0.23 milli-ohms. It can tolerate a surge voltage of up to 3V and operates from -40 to 65°C. It is available in a screw-mount package that measures 138 x 60 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V IGBT Module | |
IGBT
from Micro Commercial Components
|
| The MIF450R12C2TL from Micro Commercial Components is an IGBT that is suitable for an inverter for motor drive, AC and DC servo driver amplifier, UPS (Uninterruptible Power Supplies), and soft switching welding machine applications. This IGBT has a collector-emitter voltage of 1200 V and a gate-emitter threshold voltage of 5.8 V. It has a continuous current of 450 A and a pulsed collector current of 900 A. This IGBT dissipates a total power of 2307 W and can withstand an isolation voltage of up to 2500 V for 1 minute. |
| |
Download Datasheet
Product Details | |
|
|
|
| 960 W Single-Phase AC-DC Power Supplies | |
AC to DC Converter
from Mean Well
|
| The XDR Series from Mean Well are Single-Phase AC-DC Power Supplies that convert AC input voltages of 85-305 V to DC output voltages of 12-48 V. These ultra-slim AC-DC converters deliver output power ranging from 75 to 960 W and offer efficiencies of up to 96%. They have a less than 10 A ultra-low inrush current at 230 VAC input. These AC-DC converters include protection features such as short circuit, overload, overvoltage, and overtemperature protection. They operate over a temperature range from -40°C to +85°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 600 W AEC-Q101 Qualified TVS Diode | |
Power Diode
from Taiwan Semiconductor
|
| The SMA6S33CAH from Taiwan Semiconductor is an AEC-Q101 Qualified Transient Voltage Suppressor. It has a maximum breakdown voltage of 40.8 V and a clamping voltage of 53.6 V. This diode has a steady state power dissipation of 7.14 W and a non-repetitive peak impulse power dissipation of 600 W. It has a forward voltage of 3.5 V and a forward current rating of 25 A. This power diode has a reverse voltage of 33 V. It is available in a surface-mount package that measures 5.00 x 4.00 x 2.70 mm |
| |
Download Datasheet
Product Details | |
|
|
|
| 0.2 W Thick Film Chip Power Resistors | |
Power Resistor
from Panasonic Corporation
|
| The ERJ PC3 Series from Panasonic Corporation are Automotive-Grade Super High Precision Thick Film Chip Power Resistors. These resistors have a resistance range of 300 ohm to 1 megaohm with a resistance tolerance of up to ±0.5%. They have a power rating of 0.2 W and a limiting element voltage of 100 V. These AEC-Q200-compliant film resistors incorporate a thick-film resistive element. They are available in a surface-mount package that measures 1.60 x 0.80 x 0.45 mm |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by European Smart Chassis Forum 2026 | | European Smart Chassis Forum 2026 | | The European Smart Chassis Forum 2026 will bring together automotive engineers, researchers, and industry leaders to explore the latest innovations in intelligent chassis systems. The event will focus on advancements in lightweight design, electrification, autonomous driving integration, and digital control technologies, fostering collaboration to shape the next generation of safe, efficient, and connected vehicle platforms. Click here to learn more. | | | |
|
|
| 150 W AC-DC Converters | |
AC to DC Converter
from P-DUKE Power
|
| The TAD150 Series from P-DUKE Power are AC-DC Converters that step down AC input voltages of 85-264 V to DC output voltages of up to 54 V. These AC-DC converters also accept DC input voltages of 88-370 V. They deliver DC output power of up to 150 W and have efficiencies of 94%. These REACH-compliant converters consist of integrated Class B electromagnetic interference (EMI) filters and have undergone Class I and Class II safety test procedures to ensure protection against electromagnetic interference (EMI). |
| |
Download Datasheet
Product Details | |
|
|
|
| 15 kW High Reliability TVS Diodes | |
Power Diode
from Littelfuse
|
| The SM15KPA-HR Series from Littelfuse are High Reliability TVS Diodes designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. They have a reverse stand-off voltage of up to 400 V and a clamping voltage of over 643.8 V. These JEDEC-qualified TVS diodes have a peak pulse current of up to 440.2 A and a reverse leakage current of over 5 A. They have a peak pulse capability of 15 kW at 10/1000 μs waveform. |
| |
Download Datasheet
Product Details | |
|
|
|
| Fast Turn-off Synchronous Rectification Controller | |
PMIC
from Recom Power
|
| The RVSY018 from Recom Power is a Fast Turn-off Synchronous Rectification Controller designed to support both deep Continuous Conduction Mode (CCM) and Discontinuous Conduction Mode (DCM) operations. It requires a supply voltage of 4.7-10 V and operates at frequencies up to 700 kHz, making it ideal for high-speed power conversion applications. This PMIC offers ultra-fast turn-off delay. It features a programmable turn-off threshold and programmable blanking time. |
| |
Download Datasheet
Product Details | |
|
|
|
| 2400 A IGBT Power Module | |
IGBT
from Fuji Electric
|
| The 2MBI2400XRXG120-50 from Fuji Electric is an IGBT Module. It has a collector-to-emitter voltage of 1200 V and a collector current of up to 2400 A. This IGBT has a collector-emitter saturation voltage of 1.6 V. It features a low inductance module structure and has a total power dissipation of 21.1 kW. It is available as a module that measures 250 x 89 x 38 mm and is ideal for use in inverters for motor drives, AC and DC servo drives, uninterruptible power supply systems, wind turbines, and PV power conditioning systems. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4-300 W DC-DC Converters | |
DC to DC Converter
from Gaia Converter
|
| The HUGD-300 Series from Gaia Converter are DC-DC Converters that convert input voltages of 8–100 V to output power levels of 4–300 W. These converters feature embedded reverse polarity protection and operate over a temperature range of -40 to 90°C. They offer reduced capacitance with up to 80% efficiency. These DC-DC converters have a switching frequency of 700 kHz in boost mode. They include monitoring signals and have programmable hold-up capacitor voltages of up to 80 V DC. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by European Smart Chassis Forum 2026 | | |
|
|
| URX800/URX600 Power Manager | |
PMIC
from MaxLinear
|
| The MXL7080-AQB-R from MaxLinear is a Power Manager specifically designed to interface with MaxLinear's AnyWANTM SoC URX800/600 series and PUMATM 8 DOCSIS 4.0 SoC. It requires an input voltage of 3-3.6 V. It features an I2C interface and sideband signals to the SoC that enable all required power system controls and adaptive power management. It also handles all start-up sequencing and fault management, including three fault flag outputs to control system regulators during cold reset and fault events. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5.3 W Constant Current LED Driver IC | |
LED Driver IC
from LinkCom Manufacturing
|
| The BPHE005C351 from LinkCom Manufacturing is a Constant Current LED Driver. It requires an AC input voltage of 90-264 VAC. It provides an output current of 0.293-0.359 A, an output voltage of 3–18 V, and has a rated output power of 5.3 W. It integrates multiple protection features, including short-circuit protection (SCP), over-voltage protection, and over-temperature protection. This UL 1310-rated LED driver has an efficiency of up to 74% and operates within a temperature range of -20°C to +60°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 48 V PWM Solar Charge Controller | |
Solar Charge Controllers
from Kontron eSystems
|
| The 4055 Solar Charge Controller from Kontron eSystems is a 48 V Industrial-Grade Solar Charge Controller engineered for demanding outdoor and off-grid energy applications, delivering precise battery charging and intelligent load control. Designed for rugged field deployment, this controller supports a load current of up to 55 A. Rated IP65 for dust and water protection, the module is supplied with the Steca PA Tarcom data logger, PA CAB1 Tarcom cable, PA HS200 current sensor, and PA TS10 external temperature sensor. |
| |
Download Datasheet
Product Details | |
|
|
|
| 70-180 W AC-DC Converters | |
AC to DC Converter
from Power Integrations
|
| The TOPSwitchGaN Series from Power Integrations are AC-DC Converters engineered for compact offline power supply designs across consumer, industrial, and automotive-adjacent applications. Built on advanced PowiGaN technology and enhanced with EcoSmart power-saving architecture, these converters achieve up to 90% average efficiency over a wide load range, enabling reduced power loss and improved thermal performance in modern energy-conscious designs. It operates at a switching frequency of up to 150 kHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| Low-Offset Voltage CMOS Operational Amplifier | |
Power Operational Amplifier
from ROHM Semiconductor
|
| The TLR2728YFJ-CE2 from ROHM Semiconductor is a Low-Offset Voltage CMOS Operational Amplifier. It requires a single supply voltage of 2.5-5.5 V or a dual supply voltage of ±1.25 V to ±2.75 V. This high-speed op-amp features an input offset voltage of up to 550 µV, and an input bias current of 0.5 pA. It provides an output voltage of up to 150 mV and an output current of up to 50 mA. This dual CMOS operational amplifier delivers a large signal voltage gain of 115 dB and has a common mode rejection ratio (CMRR) of 100 dB. |
| |
Download Datasheet
Product Details | |
|
