| Featured Products this Week |
|
|
| 100 mA High Voltage Linear Regulator | |
LDO Voltage Regulator
from onsemi
|
| The NCP737ADN330R2G from onsemi is a High Voltage Linear Regulator that is ideal for telecom, industrial, battery, and high-voltage rail sensors, alarms and security systems, battery-powered hand tools, home automation, smart metering, and white goods. This LDO regulator requires an input voltage of 3-65 V. It provides an output current of up to 100 mA at a fixed output voltage of 3.3 V and has a dropout voltage of 265 mV. |
| |
Download Datasheet
Product Details | |
|
|
|
| 168 W DC-DC Converter | |
DC to DC Converter
from Sinpro Electronics
|
| The VEK168-106 from Sinpro Electronics is a DC-DC Converter that converts an input voltage of 60-118 V to an output voltage of 6-16 V. It delivers an output power of 168 W and offers an efficiency of 88%. This converter provides a total regulation of ±5% and has a ripple and noise of 200 nVp-p. It supports both constant current mode and constant voltage mode. It is available as a module that measures 120.9 x 96.2 x 36.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 48 V Air-Cooled DC-AC Inverter | |
DC to AC Inverter
from Turntide Technologies
|
| The Size 6 X- 48V from Turntide Technologies is an Air-Cooled DC-AC Inverter that converts a DC input voltage of 20-63 V to an AC voltage of 48 V. This inverter provides an output power of up to 43 kW and an output current of over 650 A. It uses maximum torque per ampere algorithms for IPM/SPM motors, along with field weakening and vehicle control features like hill-hold and anti-jerk. This inverter offers variable PWM frequency up to 12 kHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1:12 SMT Flyback Transformer | |
Power Transformer
from iNRCORE
|
| The PL3290T from iNRCORE is an SMT Flyback Transformer. It has a turns ratio of 1:12 and an inductance of 21.14 µH, with a minimum inductance of 18 µH at 1.5 A DC. This transformer offers a maximum leakage inductance of 750 nH and a low DCR of 0.16 ohms. It has a dielectric withstand voltage of 500 V and operates across a wide temperature range of -55 to +130°C. It is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 30 V PNP Darlington Transistor | |
Bipolar Junction Transistor
from Diodes Incorporated
|
| The MMBTA63-7-F from Diodes Incorporated is a PNP Darlington Transistor. It has a collector-emitter breakdown voltage of -30 V, a collector-base breakdown voltage of -30 V, and an emitter-base breakdown voltage of -10 V. This transistor supports a continuous collector current of -500 mA and offers a DC current gain of over 10000. It offers a collector-emitter saturation voltage of -1.5V at -100 mA. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Data Centers & National Security Summit | | Data Centers & National Security Summit | | Data Centers & National Security Summit will convene senior leaders, top experts, and strategic decision makers from across the Commercial Sector, Federal Government, DoW, National Labs, and Academia for in-depth discussions on powering and securing critical data center infrastructure in support of national security. This forum aims to explore the technologies and strategies that ensure data centers operate efficiently and securely, with a focus on power management, cooling systems, and operational resilience. Click here to learn more. | | | |
|
|
| 2 MHz Low-Voltage AOT Synchronous Buck Regulator | |
DC to DC Converter
from Kinetic Technologies
|
| The KTB8316EEAA-BD-TA from Kinetic Technologies is a Low-Voltage AOT (adaptive-on-time) Synchronous Buck Regulator with a switching frequency of 2 MHz. It converts an input voltage of 2.5-5.5 V to an output voltage of 0.6-1.8 V. This DC-DC converter delivers an output current of up to 2.5 A and maintains a high output-voltage accuracy of ±0.75%. It offers peak efficiency up to about 90% and a quiescent supply current of 39 µA. |
| |
Download Datasheet
Product Details | |
|
|
|
| High-Speed Dual-Channel Power Operational Amplifier | |
Power Operational Amplifier
from STMicroelectronics
|
| The TSB192IST from STMicroelectronics is a High-Speed Dual-Channel Power Operational Amplifier. It requires a supply voltage of 4-36 V and a current of less than 2.2 mA per channel. This op-amp features an ultra-low input offset voltage of 20 µV, an 8 MHz gain bandwidth product, and rail-to-rail output capability. It is designed with a high ESD tolerance of 4kV HBM. It is available in a surface-mount package that measures 5.15 x 3.20 x 1.10 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| RoHS-Compliant DC Filter Capacitors | |
Power Capacitor
from Kyocera AVX
|
| The FFLK Series from Kyocera AVX are Power Capacitors designed for DC filtering applications such as the DC link in power converters. They offer capacitances from 25-3020 µF and have a capacitive tolerance of ±10%. These capacitors have a rated DC voltage of 900-3800 V and can handle a rms current of up to 132 A. These RoHS-compliant capacitors operate from -40 to +95°C and are available in screw-mount packages. |
| |
Download Datasheet
Product Details | |
|
|
|
| 2300 V IGBT Module | |
IGBT
from Fuji Electric
|
| The 2MBI1200XZG230-50 from Fuji Electric is an IGBT Module. It has a collector-to-emitter voltage of up to 2300 V, a gate-emitter threshold voltage of 7 V, and a collector-to-emitter saturation voltage of 2.75 V. This IGBT has a collector current of 1200 A and a gate-emitter leakage current of less than 600 nA. It belongs to the X-series IGBT modules. It features low collector-emitter saturation voltage and a low inductance module structure. |
| |
Download Datasheet
Product Details | |
|
|
|
| 30 kW High Reliability TVS Diodes | |
Power Diode
from Littelfuse
|
| The SM30KPA-HR Series from Littelfuse are High Reliability TVS Diodes designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. They have a reverse stand-off voltage of up to 400 V and a clamping voltage of over 644 V. These JEDEC-qualified TVS diodes have a peak pulse current of up to 440.2 A and a reverse leakage current of over 2 A. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Data Centers & National Security Summit | | |
|
|
| 1200 V IGBT Module | |
IGBT
from Micro Commercial Components
|
| The MIF450R12C2TL from Micro Commercial Components is an IGBT that is suitable for an inverter for motor drive, AC and DC servo driver amplifier, UPS (Uninterruptible Power Supplies), and soft switching welding machine applications. This IGBT has a collector-emitter voltage of 1200 V and a gate-emitter threshold voltage of 5.8 V. It has a continuous current of 450 A and a pulsed collector current of 900 A. This IGBT dissipates a total power of 2307 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| Enhancement Mode N-Channel Si Power MOSFET | |
MOSFET
from Toshiba
|
| The TPHR6704RL from Toshiba is an Enhancement Mode N-Channel Silicon Power MOSFET designed for high-efficiency DC-DC converters, switching voltage regulators and motor drivers. It has a drain-source voltage of over 40 V, a gate threshold voltage of 2.0 V, and a drain-source on-resistance of less than 0.97 milli-ohms. This MOSFET has a power dissipation of 210 W and a drain current of up to 420 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 W DC/AC Sine Wave Inverter | |
DC to AC Inverter
from Premium PSU
|
| The ODS-750-7277-U from Premium PSU is a DC/AC Sine Wave Inverter that converts a DC input voltage of 154 V to an AC output voltage of 230 V. This DC-AC inverter has a nominal input voltage of 110 V and provides an output current of 13 A. It delivers a power of 750 W and has an efficiency of 89%. This EN45545-2 approved inverter offers high input-to-output isolation of 3000 V. It features true sine-wave output with less than 2% THD. |
| |
Download Datasheet
Product Details | |
|
|
|
| 24 V PCB Power Relay | |
Power Switch IC
from Omron Corporation
|
| The G6QG-1A DC24 from Omron Corporation is a PCB Power Relay. It has a rated coil voltage of 24 V (DC), a rated current of 58 mA and a coil resistance of 400 ohms. This compact power relay is capable of high-capacity switching with a contact rating of 480 V (AC) and 55 A. It can withstand high voltages up to 10 kV between the coil and contacts and has a contact gap of more than 2 mm for improved insulation. It has a power consumption of 1400 mW. |
| |
Download Datasheet
Product Details | |
|
|
|
| 689 µH Drum Core Pin Type Power Inductor | |
Power Inductor
from Coilmaster Electronics
|
| The RDR875-681K-LF from Coilmaster Electronics is a Drum Core Pin Type Power Inductor. It has an inductance of 689 µH and an inductance tolerance of ±10%. This unshielded power inductor has a saturation current of 0.33 A and a dynamic contact resistance (DCR) of less than 1960 milli-ohms. It has a special magnetic core structure and provides high Q and high SRF value. This power inductor has a low-cost design that requires small mounting space. |
| |
Download Datasheet
Product Details | |
|
