| Featured Products this Week |
|
|
| 13.56 MHz Wireless Charging Receiver LSI | |
Wireless Charging IC
from ROHM Semiconductor
|
| The ML7670-61XHB from ROHM Semiconductor is a 13.56 MHz Wireless Charging Receiver LSI designed for NFC Forum WLC 2.0 compliant systems. It requires an input voltage of 1.8-5.5 V and delivers an output power of up to 250 mW when paired with the ML7671 transmitter. This wireless charging IC includes a 10-bit SAR-ADC for power status monitoring, NFC Type 3 Tag functionality for applications like Bluetooth pairing, and an I2C Target host interface for external MCU configuration. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1.8 V Low Dropout Voltage Linear Regulator | |
LDO Voltage Regulator
from Sgmicro
|
| The SGM2239-1.8XTDI6G/TR from Sgmicro is a Low Dropout Voltage Linear Regulator. It requires an input voltage of 2.5-40 V. This LDO voltage regulator provides a fixed output voltage of 1.8 V and delivers an output current of 300 mA. It has a dropout voltage of 900 mV and has a low quiescent current of 3.2 μA. This LDO regulator features current limit and thermal shutdown protection. It can be made stable with small case size ceramic capacitors and has an output automatic discharge function. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4 A Inrush Current Limiter | |
Inrush Current Limiter
from Semitec
|
| The 15D2-15LDTR from Semitec is an Inrush Current Limiter. It has a rated current of 4 A and a power dissipation of 41 mW. This inrush current limiter has a rated zero-power resistance of 15 ohms and a resistance tolerance of ±15%. It has a thermal time constant of 70 s and an energy surge capacity of 28 J. This inrush current limiter utilises the self-heating characteristic of NTC thermistors, which results in a significant decrease in resistance over a short period. It features reduced power loss and high energy savings. |
| |
Download Datasheet
Product Details | |
|
|
|
| Quasi-Resonant Converter with E-Mode GaN HEMT | |
AC to DC Converter
from STMicroelectronics
|
| The VIPERGAN100WBTR from STMicroelectronics is a Quasi-Resonant AC-DC Converter that is integrated with an enhancement-mode GaN HEMT. It converts an AC input voltage of 85-265 V to a DC output power of 75-100 W. This AC-DC converter provides dynamic blanking time and adjustable valley synchronization delay functions to maximise efficiency at any input line and load condition. It consists of a GaN transistor that has a drain-source voltage of 700 V. This converter is available in a surface-mount package that measures 5 x 6 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 62 V Silicon Epitaxial Planar Zener Diode | |
Power Diode
from Toshiba
|
| The CUHZ62V from Toshiba is a Silicon Epitaxial Planar Zener Diode. It has a zener voltage of 62 V at a test current of 2 mA. This power diode has a dynamic resistance of 1.6 ohms and provides a peak pulse power of 1250 W. It has an electrostatic discharge voltage of ±24 kV and a peak pulse current of 10 A. It has a clamp voltage of 84 V, a reverse current of 0.1 µA and a total capacitance of 55 pF. It is available in a surface-mount package that measures 2.50 x 1.40 x 0.60 mm and is ideal for overvoltage protection of electronic systems. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Advanced Energy Storage for Defense & Security | | Advanced Energy Storage for Defense & Security | | The 2026 Advanced Energy Storage for Defense & Security Summit will bring together decision-makers and innovators from the Department of War, federal government, commercial sector, and academia to discuss emerging technologies in energy storage, including intelligent battery cells and management systems. The summit will focus on the transition from lithium-ion batteries to alternatives like hydrogen fuel cells and solid-state technologies, which address higher energy demands and improve tactical platforms such as UAVs and EVs. Click here to learn more. | | | |
|
|
| Quarter-Brick DC-DC Converters | |
DC to DC Converter
from P-DUKE Power
|
| The QAE100U Series from P-DUKE Power are Quarter-Brick DC-DC Converters that convert an input voltage of 9-160 V to an output voltage of 5-53 V. They deliver an output current of up to 20 A and offer efficiency of up to 90%. These converters provide an isolated output power of up to 100 W and offer reinforced insulation of 3000 VAC and basic insulation of 2250 VDC. They have protection features such as over-current, over-voltage, over-temperature, short-circuit, and under-voltage protection. |
| |
Download Datasheet
Product Details | |
|
|
|
| Bifacial N-Type Double Glass Solar Panels | |
Solar Panels
from Leapton Energy
|
| The LP182*182-M-60-NB 490-520W Series from Leapton Energy are Bifacial N-Type Double Glass PV Modules. They deliver an output power of 490-520 W at STC and 369-391 W at NMOT, with a maximum module efficiency of up to 23.46%. These solar panels provide a maximum power voltage of 37.12 V and a maximum current of up to 14.01 A, with an open-circuit voltage of up to 44.57 V. These panels consist of 60 × 2 half-cut cells based on N-type MBB technology with bifacial double-glass construction. |
| |
Download Datasheet
Product Details | |
|
|
|
| Synchronous Buck Power Stage Module | |
DC to DC Converter
from Alpha & Omega Semiconductor
|
| The AOZ53228QI from Alpha & Omega Semiconductor is a Synchronous Buck Power Stage Module. It requires a power supply of 2.5-18 V and a driver supply of 4.5-5.5 V. This highly integrated converter combines two asymmetrical MOSFETs with an integrated high-speed gate driver, delivering a continuous output current of up to 60 A, with pulse current capability reaching 80 A for 10 ms and 120 A for 1 ms. This DC-DC converter supports switching frequencies up to 2 MHz and is compatible with both 3 V and 5 V PWM logic inputs. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6 V Isolated Power Bridge Rectifier | |
Power Diode
from Recom Power
|
| The RVS002-FB-R from Recom Power is a Power Bridge Rectifier specifically designed for micro-power isolated power supply applications in space-constrained environments. This power diode integrates two N-channel MOSFETs, two Schottky diodes, and an intelligent voltage limiter to simplify isolated power supply design while reducing external component count. It supports output voltage from 2-6 V with an output power ranging from 1-3 W and delivers up to 300 mA output current. It has an on-state resistance of up to 160 milli-ohms. |
| |
Download Datasheet
Product Details | |
|
|
|
| 16-Channel Multicell Battery Monitor | |
Battery Management IC
from Analog Devices
|
| The ADBMS6830B from Analog Devices is a Multicell Battery Monitor. This battery management IC requires an input voltage of −2 V to +5.5 V and allows the measurement of voltages across bus bars. It measures up to 16 series-connected battery cells with a lifetime total measurement error of less than 2 mV over the full temperature range. This BMIC enables simultaneous and continuous cell voltage measurements with configurable integrated low-pass filtering. It is available in a surface-mount package that measures 12.25 x 12.25 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Advanced Energy Storage for Defense & Security | | |
|
|
| Automotive-Grade Linear Vertical Hall-Effect Sensor | |
Current Transducer
from Allegro MicroSystems
|
| The ACS37630LOLTR-004B5 from Allegro MicroSystems is an Automotive-Grade Linear Vertical Hall-Effect Sensor IC designed for applications where current flows through a busbar or PCB. This current transducer requires a supply voltage of 5 V. It has a factory-programmed sensitivity of 4 mV/A and has a magnetic field range of ±500 G. This AEC-Q100 Grade 0-qualified current transducer performs contactless, non-invasive current sensing and eliminates the need for C-cores for easy assembly. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 kV SiC MOSFET for Mid- and High-Voltage Applications | |
MOSFET
from Wolfspeed
|
| The CPM3-10000-0300A from Wolfspeed is a Silicon Carbide MOSFET developed to maximise the performance and simplify the design architecture of mid and high-voltage applications. It has a drain-source breakdown voltage of 10000 V, a gate threshold voltage of 2.8 V, and a drain-source on-resistance of less than 380 milli-ohms. This MOSFET has a total charge of 268 nC and a reverse transfer capacitance of 3.4 pF. It features low on-resistance and temperature-independent high-speed switching. |
| |
Download Datasheet
Product Details | |
|
|
|
| 960 W Switch-Mode Power Supply | |
AC to DC Converter
from Weidmuller
|
| The PRO ECO 960W 48V 20A II from Weidmuller is a Switch-Mode Power Supply that converts an AC input voltage of 85-264 V to a DC output voltage of 48 V. It also accepts a DC input voltage of 120-340 V. This converter delivers an output power of 960 W and has an efficiency of up to 94.1%. It has a power factor of 0.95 and has an output current rating of 20 A. This RoHS-compliant AC-DC converter is available in a DIN rail-mount package that measures 150 x 130 x 112 mm and weighs 3110 g. |
| |
Download Datasheet
Product Details | |
|
|
|
| 3.3 V AC-DC On-Board Converter | |
AC to DC Converter
from Mornsun
|
| The LS03-13B03R3 from Mornsun is a Green Power AC-DC On-Board Converter that converts an AC input voltage of 85-305 V to a DC output voltage of 3.3 V. It also accepts an input DC voltage of 70-370 V. This highly efficient converter delivers an output power of 1.98 W and has an efficiency of up to 67%. It can withstand an input-output isolation voltage of up to 3000 VAC and operates over a temperature range of -40°C to +85°C. It is available in a through-hole package that measures 26.40 x 15.40 x 11.00 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 470 µH Drum Core Pin Type Power Inductor | |
Power Inductor
from Coilmaster Electronics
|
| The RDR875-471K-LF from Coilmaster Electronics is a Drum Core Pin Type Power Inductor. It has an inductance of 470 µH and an inductance tolerance of ±10%. This unshielded power inductor has a saturation current of 0.41 A and a dynamic contact resistance (DCR) of less than 1340 milli-ohms. It has a special magnetic core structure and provides high Q and high SRF value. This power inductor has a low-cost design that requires small mounting space. This power inductor is available in a through-hole package that measures 8.3 x 7.5 mm. |
| |
Download Datasheet
Product Details | |
|
