The B25696H0128K901 from TDK Electronics is a High Frequency Film Capacitor. It has a capacitance of 1280 µF with a capacitance tolerance of ±10%. This capacitor has a voltage rating of 900 Vdc and can withstand a surge current of up to 6900 A. It has an ESR rating of 1.26 milli-ohms and offers an inductance of 29 nH. This IP00-rated film capacitor uses metallised polypropylene film in an aluminium case with a resin top, and is a dry-type capacitor filled with non-PCB hard polyurethane resin. It offers ultra-low ESR and ESL, self-healing behaviour, and high-frequency performance that is fully compatible with SiC semiconductors. This RoHS-compliant capacitor operates up to +85 °C, supports naturally air-cooled or forced-air-cooled systems and provides over-voltage capability. It is available in a screw-mount package that measures 226 x 232 x 100 mm and is suitable for DC link for renewable energy converters (solar, wind), DC link for traction applications (train, subway, tramway, light train inverters), and DC link for industrial motor drives.
