HCT80101EAL-E

Power Transformer by Bourns (22 more products)

Note : Your request will be directed to Bourns.

HCT80101EAL-E Image

The HCT8010EAL-E from Bourns is an Automotive-Qualified Power Transformer that has been designed to offer full automation capabilities in a compact size. It requires a primary voltage of 3.3 - 5 V. This transformer provides a secondary voltage of 3.3 - 15 V and a secondary current of up to 0.35 A. It supports high voltage isolation between the primary and secondary sides and has reinforced insulation of 800 V. This AEC-Q200-qualified transformer is rated to over-voltage category II (OVC-II) and pollution degree 2 standards. It is available in a surface-mount package that measures 14.2 x 10.6 x 8.0 mm.

Product Specifications

Product Details

  • Part Number
    HCT80101EAL-E
  • Manufacturer
    Bourns
  • Description
    15 V Automotive-Qualified Power Transformer

General

  • Types of Transformer
    Isolation Transformer
  • Industry
    Automotive
  • Primary Voltage
    3.3 to 5 V
  • Secondary Voltage
    3.3 to 15 V
  • Current Rating
    0.35 A
  • Inductance
    160 µ H
  • Turns Ratio
    1: 1
  • Qualification
    AEC-Q200
  • RoHS Compliant
    Yes
  • Temperature Operating Range
    -40 to 125 Degree C
  • Dimension
    14.2 x 10.6 x 8.0 mm
  • Package Type
    Through Hole
