| Featured Products this Week |
|
|
| 3.3 V AC-DC Power Supply | |
AC to DC Converter
from XP Power
|
| The VCE03US03 from XP Power is an AC-DC Power Supply that converts an AC input voltage of 85-305 V to a single DC output voltage of 3.3 V. This convection-cooled converter delivers an output power of over 3 W. This class A/class B-compliant converter features overvoltage, overload, and short-circuit protection. It is available in a PCB-mount single in-line (SIL) package that measures 40.6 x 19.10 x 19.10 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 0.3 W High-Voltage Thick-Film Resistor | |
Power Resistor
from Murata
|
| The MHR0307SA105M20 from Murata is a High-Voltage Thick-Film Resistor. It has a resistance of 1 mega-ohm, a resistance tolerance of ±20%, and a power rating of 0.3 W. This resistor has a maximum working voltage of 500 V to enable safe operation in mid-range voltage environments. It is available in a through-hole package that measures 7.6 x 5.0 mm and is ideal for copiers, printers, and high-voltage-handling equipment applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive-Qualified High Surge Current SIDACs | |
Sidac
from Littelfuse
|
| The Pxxx0S3H Series from Littelfuse are Automotive-Qualified High Surge Current SIDACs that are designed to protect equipment located in hostile environments from overvoltage transients. They have a stand-off voltage of 300 V and a stand-off current of 800 mA. These SIDACs provide the best-in-class surge immunity of up to 2000 A. They are available in surface-mount packages that measure 7.75 x 5.59 x 2.06 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Step-Down Control Transformer for Industrial Applications | |
Power Transformer
from Eaton
|
| The C5000K2A from Eaton is a Step-Down Industrial Control Transformer. This transformer requires a primary voltage of 220-240 V and provides a secondary voltage of 110-120 V. This RoHS-compliant transformer has an epoxy resin impregnated coil design with copper windings for operation at 50/60 Hz. It is available in a chassis-mount package that measures 7.756 x 7.559 x 9.016 inches. |
| |
Download Datasheet
Product Details | |
|
|
|
| 25 A Synchronous Step-Down Regulator | |
DC to DC Converter
from Analog Devices
|
| The LT7153SP from Analog Devices is a Synchronous Step-Down Regulator that converts an input voltage of 2.7-5 V to an output voltage of 0.5-0.9 V. It can deliver an output current of up to 25 A. This step-down regulator has an exposed back for attaching a heat sink, which can greatly enhance thermal performance. This RoHS-compliant regulator is available in a surface-mount package that measures 4 x 7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5 V High PSRR LDO Regulator | |
LDO Voltage Regulator
from Diodes Incorporated
|
| The AP7372-50CBA6-7 from Diodes Incorporated is a High PSRR LDO Regulator. It requires an input voltage of 2.7-20 V and delivers an output current of up to 200 mA. This regulator provides a fixed output voltage of 5 V and has a dropout voltage of 120 mV. It has a high PSRR at multiple frequency ranges and provides an ultra-low output noise of 8 µV rms. It is available in a surface-mount package that measures 1.17 x 0.96 x 0.49 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V SiC MOSFET | |
MOSFET
from Infineon Technologies
|
| The IMZA120R078M2H from Infineon Technologies is a Silicon Carbide (SiC) Power MOSFET made for efficient power conversion in tough situations. It has a drain-source breakdown voltage of 1200 V and a drain-source resistance of 78-185 milli-ohms. It has a gate-source voltage ranging from -7 to +23 V and has a gate threshold voltage of 4.2 V. It is available in a through-hole package that measures 41.2 x 15.9 x 5.10 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 200 V Industrial Fuse Link | |
Fuses
from Adler Elektrotechnik
|
| The AB12600100 from Adler Elektrotechnik is an Industrial Fuse Link designed for use in industrial ESS and power distribution protection. It has a voltage rating of 200 V (DC) and a current rating of 60 A. This UL-approved fuse has a power dissipation of less than 9 W. It has a breaking capacity of 20 kA. This RoHS/REACH-compliant fuse is manufactured under IATF 16949 quality system. It is available in a screw-mount package that measures 68.5 x 24 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 250 V Flex Cable Power Connector | |
Power Connector
from Bulgin
|
| The EXP-0911-10-S-1 from Bulgin is a Power Connector that is designed for applications in hazardous areas. It has a rated voltage of 250 V and a rated current of up to 10 A. This connector accommodates cables with diameters ranging from 7 mm to 9 mm. The connector has a polyester (PET) plastic body with a coupling ring diameter of 58 mm and meets UL94V-0 flammability standards. This IP68-rated connector measures 127 x 58 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 133 A High-Power High-Ripple Chokes | |
Power Inductor
from Bourns
|
| The 15322x Series from Bourns are High-Ripple Chokes. These ferrite-core inductors have an inductance of 19-250 µH and an inductance tolerance of ±20%. They have a current rating of up to 133 A. These high-power RoHS-compliant inductors feature low-winding capacity and a single-layer helical winding design to enhance cooling efficiency. They are available in through-hole packages that measure 425 x 105 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 47 µF Aluminium Electrolytic Supercapacitor | |
Supercapacitor
from Panasonic Corporation
|
| The ECA2DM470B from Panasonic Corporation is an Aluminium Electrolytic Supercapacitor that is ideal for industrial applications. It has a capacitance of 47 µF and a capacitance tolerance of ±20%. This capacitor has a voltage rating of 200 V. It is relatively smaller in size compared to the SU series of capacitors. This RoHS-compliant electrolytic capacitor is available in a radial-leaded package that measures 37 x 12.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1000 V Phase Control Thyristor | |
Silicon Controlled Rectifier
from Proton-Electrotex JSC
|
| The T143-1000-10 from Proton-Electrotex JSC is a Phase Control Thyristor that is suitable for use in AC/DC circuits operating as per industry standards or at higher frequencies. It has a breakover voltage of up to 1000 V and a breakover current of 1408 A. This thyristor has a gate trigger voltage of up to 3 V. It can control high loads with a low control signal applied to the control gate. It is available in a disc package that measures 60 x 20 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 120 V Enhancement Mode GaN Power Transistor | |
GaN Power Transistor
from Efficient Power Conversion
|
| The EPC2110 from Efficient Power Conversion is an Enhancement Mode GaN Power Transistor. It has a continuous drain-to-source voltage of 120 V, a continuous current of 8.2 A, and a pulsed current of 74 A. This GaN transistor has a drain-source ON resistance of 13.5 ohms and source-drain forward voltage of 2 V. This RoHS-compliant power transistor is available as a passivated die that measures 1.5 x 1.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8 A Inrush Current Limiter | |
Inrush Current Limiter
from Semitec
|
| The 3D2-22LCTR from Semitec is an Inrush Current Limiter. It has a rated zero-power resistance of 3 ohms and a resistance tolerance of ± 15%. This inrush current limiter has a rated current of 8 A and a power dissipation of 48 mW. It has a thermal time constant of 130 s and an energy surge capacity of 63 J. It features reduced power loss and high energy savings. This thermistor is available in a through-hole package that measures 23.0 x 8.5 x 26.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 545 Wp Bifacial Solar Panel | |
Solar Panels
from Astorios
|
| The ASTR 144HCD/10 545Wp from Astorios is a Bifacial Solar Panel. It has an open circuit voltage of 49.52 V and a short circuit current of 13.94 A. This double glass solar panel delivers an output power of up to 545 Wp. This solar panel has good light absorption and better partial-shade tolerance due to separated half-panel string wiring. It is available as a module that weighs 32 kg and measures 2278 × 1134 × 30 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 30 V Software-Based MCU-less Wireless Power Solution | |
Wireless Charging Coil
from Powermat Technologies
|
| The PMT 100 from Powermat Technologies is a Software-Based, MCU-less Wireless Power Solution designed for small device charging. It supports up to 40 W wireless power transfer and has an efficiency of over 90%. This wireless charging coil features up to 15 mm coil-to-coil distance and tolerates up to 15 mm lateral misalignment. This coil can supply a maximum battery charge current of 2 A. It is available as a module that measures 15 x 15 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q100-Qualified Dual High Side Switch | |
Power Switch IC
from onsemi
|
| The NCV47822 from onsemi is an Automotive-Grade Dual High Side Switch that has been designed for use in harsh automotive environments. It requires an input voltage of 4.4-40 V and provides an output current of over 10-350 mA. This dual-channel power switch has an adjustable current limit up to 350 V. This RoHS-compliant power switch is available in a surface-mount package that measures 4.90 x 6.40 mm. |
| |
Download Datasheet
Product Details | |
|
