| Featured Products this Week |
|
|
| 18 V Automotive-Grade GaN Power IC | |
GaN Power Transistor
from Navitas Semiconductor
|
| The NV6522 from Navitas Semiconductor is an Automotive-Qualified GaN Power IC that is ideal for AC/DC, DC-DC, CCM/CrM topologies, data center CRPS, on-board chargers, solar inverters, and motor drive applications. It requires an input voltage of 11-18 V and an input current of 3.3 mA. This AEC-Q100 Grade 1-qualified power IC is based on Navitas’ GaNFast technology, optimizing the switching speed of the transistor IC up to 2 MHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| Rad-Hard Isolated Buck DC-DC Converter | |
DC to DC Converter
from Microchip Technology
|
| The SA15-28 Triple Series from Microchip Technology are Radiation-Hardened Buck DC-DC converters that convert input voltages of 22-40 V to output voltages of 5.1-6.1 V. They deliver output power ranging from 1.5-15 W and offer efficiencies between 69-72% (at rated load). These isolated converters provide radiation-tolerant solutions with top-class Total Ionizing Dose (TID) and Single-Event Effects (SEE) performance for space and military applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V SiC MOSFET | |
MOSFET
from Infineon Technologies
|
| The IMZA120R078M2H from Infineon Technologies is a Silicon Carbide (SiC) Power MOSFET made for efficient power conversion in tough situations. It has a drain-source breakdown voltage of 1200 V and a drain-source resistance of 78-185 milli-ohms. This MOSFET supports a continuous drain current of 20 A and has a maximum power dissipation of 143 W. It has a gate-source voltage ranging from -7 to +23 V and has a gate threshold voltage of 4.2 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| 11 kW On-Board Charging Module | |
On-Board Charger
from Delta Electronics
|
| The 400 V On-Board Charger from Delta Electronics is an On-Board Charging Module that is designed to convert an AC voltage of 85-265 V to a high-voltage DC output of 240-450 V. This liquid-cooled on-board charger (OBC) offers a rated output power of 11 kW and achieves an efficiency greater than 94%. It is equipped with CAN communication for seamless integration with vehicle systems and weighs 17.8 kg. |
| |
Download Datasheet
Product Details | |
|
|
| Featured Interview | | Interview with Cathal Sheehan from Bourns | | everything PE recently interviewed Cathal Sheehan, Applications Director, at Bourns. Bourns is a global electronics manufacturer specializing in a wide array of high-quality electronic components, circuit protection solutions, sensors, resistive and magnetic products, as well as potentiometers and controls. Click here to learn more. | | | |
|
|
| 200 W Half-Brick Isolated DC-DC Converter | |
DC to DC Converter
from Flex Power Modules
|
| The PKJ8216HPI from Flex Power Modules is a Half-Brick Isolated DC-DC Converter that converts an input voltage of 9-75 V to an output voltage of 54 V. It delivers an output power of 200 W and has an efficiency of up to 91.7%. This converter is an analog-based solution that is housed in an industry-standard half-brick enclosure. It provides an input-to-output isolation voltage of 2250 V. This isolated converter operates over a temperature range from -40°C to +110°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q200 Qualified Power Molded Flatwire Inductor | |
Power Inductor
from Wurth Elektronik
|
| The 74479320165147 from Wurth Elektronik is an AEC-Q200 Qualified Power Molded Flatwire Inductor. It has an inductance of 0.47 µH with an inductive tolerance of ±20%. This inductor operates at 48 V DC and has a rated current of 6.2 A. It has a DC resistance of up to 22 milliohms and a self-resonant frequency of up to 100 MHz. This RoHS-compliant inductor utilizes Flat wire technology and has very low losses, improving its efficiency. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1000 W Non-Isolated DC-DC Converter | |
DC to DC Converter
from Vicor
|
| The DCM3717S60D13K0TN1 from Vicor is a Non-Isolated DC-DC Converter that steps down a DC input voltage of 40-60 V to a DC output voltage of 10-12.5 V. This buck converter delivers an output power of 1000 W and has an efficiency of 96.5%. It utilizes Vicor’s patented zero-voltage switching buck-boost regulator stage and sine amplitude converter for superior performance. This converter offers PMBus-compatible telemetry. |
| |
Download Datasheet
Product Details | |
|
|
|
| Integrated Gate Driver Photocoupler for Gate Drivers | |
Gate Driver
from Toshiba
|
| The TLP5794H from Toshiba is an Integrated Gate Driver Photocoupler. This gate driver requires a supply voltage of 15-30 V and a supply current of up to 3 mA. It has an output peak current of -6/+4 A with rail-to-rail output enabling stable operation and better switching performance. This gate driver has a threshold input current of 5 mA and a propagation delay time of 200 ns. It has a common mode transient immunity of more than ±50 kV/µs. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by London EV Show 2025 | | |
|
|
| 30 V N-Channel Power MOSFET | |
MOSFET
from ROHM Semiconductor
|
| The AW2K21 from ROHM Semiconductor is an N-Channel Power MOSFET. It has a drain-drain breakdown voltage of more than 30 V, a gate threshold voltage of up to 2 V, and a drain-source on-resistance of less than 1.86 milliohms. This RoHS-compliant MOSFET has a continuous drain current of ±20 A, a pulsed drain current of ±40 A, and a power dissipation of 1.6 W. It is available in a surface-mount package that measures 2.05 x 2.05 x 0.58 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 800 V Ultra Low Forward Voltage Bridge Rectifier | |
Power Diode
from Panjit Semiconductor
|
| The GBU1508HULV from Panjit Semiconductor is an Ultra Low Forward Voltage Bridge Rectifier that is ideal for server/AI/IND, PC power (80+ platinum titanium), and gaming applications. It has a forward voltage of 0.72 V and a forward current of up to 15 A. This rectifier has a repetitive peak reverse voltage of less than 800 V, a reverse current of 1 µA, and a non-repetitive peak forward current of less than 220 A. |
| |
Download Datasheet
Product Details | |
|
