| Featured Products this Week |
|
|
| 70 F Hybrid Supercapacitor | |
Supercapacitor
from Eaton
|
| The HS/HSL1025-3R8706-R from Eaton is an Advanced Hybrid Supercapacitor designed for backup power, pulse power and hybrid power systems. It has a capacitance of 70 F and a capacitance tolerance of ±20%. This supercapacitor has a voltage rating of 3.8 V and a current rating of less than 0.35 A. It offers low ESR for high power density and has up to eight times energy density compared to standard supercapacitors. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V Half-Bridge GaN Driver for Data Centre Power Supplies | |
Gate Driver
from Analog Devices
|
| The LT8418ACBZ-R7 from Analog Devices is a Half-Bridge GaN Driver that is ideal for half-bridge, full-bridge, push-pull converters, data center power supplies, motor drivers, class-D audio amplifiers, and consumer, industrial, and automotive applications. It requires an input voltage of 3.85–5.5 V. This gate driver features a smart integrated bootstrap switch that simplifies circuit design, while the split-gate driver allows for fine-tuning of turn-on and turn-off strengths. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6500 V Rectifier Diode Module | |
Power Diode
from Hitachi Energy
|
| The 5SED0600T6540 from Hitachi Energy is a Rectifier Diode designed in an industrial standard package(60Pak). It has a repetitive peak reverse voltage of 6500 V and a peak reverse current of 30 mA. This rectifier diode can withstand an isolation voltage of 3600 V and safeguards against a forward surge current of 11000 A. It has a forward voltage rating of 1.86 V and an average forward current of 490 A. This diode is designed with an AIN ceramic insulated baseplate. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1.5 µH Automotive-Grade Inductor | |
Power Inductor
from Murata
|
| The LQW18FT1R5K0HL from Murata is an Automotive-Grade Inductor that is ideal for automotive powertrain/safety equipment, automotive infotainment/comfort equipment, and medical equipment applications. This AEC-Q200-qualified inductor has an inductance of 1.5 µH and an inductance tolerance of ±10%. It has a current rating of 400 mA and a dynamic contact resistance (DCR) of less than 0.42 ohms. This RoHS-compliant inductor is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 650 V Automotive-Grade IGBT | |
IGBT
from onsemi
|
| The AFGB30T65RQDN from onsemi is an Automotive-Grade IGBT that is designed to offer optimum performance for automotive applications. It has a collector-emitter voltage of up to 650 V, a gate threshold voltage of less than 5.3 V, and a saturated collector-emitter voltage of 1.58 V. This AEC-Q101-qualified IGBT has a collector current of 30 A and dissipates a power of less than 235.48 W. It has high current capability. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 54 V Synchronous Buck PWM Controller | |
PMIC
from Renesas
|
| The ISL8117FVEZ-T7A from Renesas is a Synchronous Buck PWM Controller. It requires an input voltage of 4.5-60 V, and provides an output voltage from 0.6-54 V. This PWM controller offers programmable switching frequencies between 100 kHz and 2 MHz and utilizes Diode Emulation Mode with pulse skipping at light loads to enhance standby efficiency. It includes soft-start programming, enable control (EN pin), and a Power-Good (PGOOD) indicator. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 W Off-Line High Voltage Converter | |
AC to DC Converter
from STMicroelectronics
|
| The VIPER11B from STMicroelectronics is an Energy-Saving Offline High-Voltage Converter. It integrates an 800 V avalanche-rugged power MOSFET, allowing ultra-wide VAC input range to be covered (85-265 V AC). This converter delivers an output power of up to 12 W in open-frame configurations and features ultra-low power consumption of less than 10 mW at 230 VAC in no-load conditions. It operates with a fixed switching frequency of 60 kHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 V N-Channel MOSFET | |
MOSFET
from VBsemi Electronics
|
| The VBGQA1202N from VBsemi Electronics is an N-Channel MOSFET. It has a drain-source breakdown voltage of over 200 V, a gate threshold voltage of up to 3 V, and a drain-source on-resistance of 18 milli-ohms. This MOSFET has a continuous drain current of up to 50 A and a power dissipation of less than 136 W. It is fabricated using SGT technology and can withstand a junction temperature of 175°C. This MOSFET is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V SiC Gate Driver Module | |
Gate Driver
from Wolfspeed
|
| The CCB032M12FM3 from Wolfspeed is a Six-Pack SiC Gate Driver Module that is ideal for high-efficiency converters/inverters, motor and traction drives, smart grid/grid-tied distributed generation, EV charging, and solar applications. It has a drain-source voltage of 1200 V and an on-state drain-source resistance of 32 milli-ohms. This six-pack module is normally off and ensures fail-safe operation. It has a pulsed drain current of 60 A and a power dissipation of 83 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 V Isolated DC-DC Converter | |
DC to DC Converter
from XP Power
|
| The RDF15072S12 from XP Power is an isolated DC-DC Converter that converts input voltage of 14-160 V to an output voltage of 12 V. It delivers an output power of 150 W and has an efficiency of up to 90%. This converter provides an input-to-output isolation voltage of 3 kV (AC) and follows ITE safety approvals and EN50155 compliance. It includes a remote on/off function with a low 15 mA standby current and is designed to suit the industry standard half-brick format. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 300 V Automotive-Qualified High Surge Current SIDAC | |
Sidac
from Littelfuse
|
| The P2600S3HLRP from Littelfuse is an Automotive-Qualified High Surge Current SIDAC that is designed to protect equipment located in hostile environments from overvoltage transients. It has a stand-off voltage of 300 V and a stand-off current of 800 mA. This SIDAC provides the best-in-class surge immunity of up to 2000 A (8/20 µs) while its component properties do not degrade after multiple surge events within its limits. |
| |
Download Datasheet
Product Details | |
|
