| Featured Products this Week |
|
|
| 1.8 V Dual-Phase Integrated Power Stage | |
DC to DC Converter
from Flex Power Modules
|
| The BMR510x044/002 from Flex Power Modules is a Dual-Phase Integrated Power Stage that converts an input voltage of 4.5-15 V to an output voltage of 0.5-1.8 V. It can deliver an output current of up to 160 A. This DC-DC converter achieves 93% efficiency at light load. This RoHS-compliant converter is available in a surface-mount package and measures 10 x 9 x 7.63 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Zero-Drift Dual-Channel Operational Amplifier | |
Power Operational Amplifier
from Analog Devices
|
| The MAX74810 from Analog Devices is a Zero-Drift Dual-Channel Operational Amplifier that has been optimized for total accuracy over time, temperature, and voltage conditions. It requires a supply voltage of 4.5-50V. This op-amp has a gain-bandwidth product of 2.7 MHz and an input bias current of 50 pA. It is available in a surface-mount package that measures 3.20 x 5.15 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 0.8 W Hot Swap Controller IC | |
eFuse IC
from Infineon Technologies
|
| The XDP710002XUMA1 from Infineon Technologies is a Hot Swap Controller IC. It has a wide input voltage range of 5.5-80 V and can withstand a transient voltage of up to 100 V for 500 ms. This efuse IC provides an output power of 0.8 W. It has a dedicated 12-bit current. This efuse IC is available in a surface-mount package that measures 6 x 6 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 435 W Bifacial Solar Module | |
Solar Panels
from Astorios
|
| The ASTR 108HCND/10 TOPCON 435Wp from Astorios is a Bifacial Solar Module. It has an open circuit voltage of 38.68 V and a short circuit current of 14.31 A. This double glass solar panel delivers an output power of up to 435 Wp and has an efficiency of over 22.30%. It is available as a module that weighs 25.8 kg and measures 1722 x 1134 x 30 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q200 Compliant BMS Transformer | |
Power Transformer
from iNRCORE
|
| The RA1059NL from iNRCORE is an AEC-Q200-Compliant BMS Transformer. It has an inductance of up to 450 µH with a tolerance of ±5% and offers a turns ratio of 1CT:1CT. This transformer has low insertion loss and strong return loss, offering reliable signal transmission. This RoHS-compliant transformer is available in a surface-mount package that measures 14 x 8.5 x 6 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 48-Channel Matrix LED Driver IC | |
LED Driver IC
from Lumissil Microsystems
|
| The IS31FL3758-QFLS4-TR from Lumissil Microsystems is a 48-Channel Matrix LED Driver IC. It requires an input voltage of 2.7-5.5 V and provides an output current of 60 mA, adjustable via three 8-bit global current control registers. It offers PWM dimming precision up to 8-bit or 6+2-bit. It is available in a surface-mount package that measures 7 × 7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 24 Port IEEE-Compliant Power-Over-Ethernet | |
Power Over Ethernet IC
from Microchip Technology
|
| The PD-6524GC from Microchip Technology is a 24 Port IEEE 802.3af-Compliant Power-Over-Ethernet (PoE) IC that is designed to support IP telephones, wireless LAN access points and security network cameras. It delivers an output power of 15.4 W over two pairs and features a data rate of 10/100/1000 Mbps. It is available in a rack-mount package that measures 435 x 271 x 44 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by European Vehicle Glazing Innovation Summit 2025 | | European Vehicle Glazing Innovation Summit 2025 | | The European Vehicle Glazing Innovation Summit 2025 is designed to foster cross-industry collaborations, ignite innovation, and create new business opportunities. It will bring together key industry leaders, innovators, and experts from across Europe and beyond to explore the transformative developments in vehicle glazing, driving forward a sustainable, safe, and smart vehicle landscape.Click here to learn more. | | | |
|
|
| 1200 V IGBT Module | |
IGBT
from Micro Commercial Components
|
| The MIUZ100R12GJTL-BP from Micro Commercial Components is an IGBT module. It has a collector-to-emitter voltage of up to 1200 V, a gate-emitter threshold voltage of 6.5 V, and a collector-to-emitter saturation voltage of 2.2 V. This IGBT has a continuous collector current of 100 A. This RoHS-compliant IGBT is available as a module that measures 38 x 28 x 12.8 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Half-Bridge SiC MOSFET Module | |
MOSFET
from Navitas Semiconductor
|
| The G3F09MT12FB2 from Navitas Semiconductor is a Half-Bridge SiC MOSFET Module. It has a drain-source voltage of 1200 V and a drain-source on-state resistance of 9.25 milliohm. This SiC module has a continuous drain current of 109 A and dissipates an output power of 238 W. This MOSFET is available as a module that measures 65 x 34 x 16.4 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 160 A DC-DC Step-Down Power Converter | |
DC to DC Converter
from Ferric Corporation
|
| The Fe1766 from Ferric Corporation is a 16-Phase DC-DC Step-Down Power Converter that converts an input voltage of 1.2-2.0 V to an output voltage of 0.25-1.5 V. This converter achieves a peak efficiency of 90% for 1.8 V to 0.75 V conversion at 96 A output current. This high-performance converter is available as a module that measures 4.44 x 8.05 x 0.994 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| -40 V P-Channel Enhancement Mode Power MOSFET | |
MOSFET
from Panjit Semiconductor
|
| The PJQ4441P from Panjit Semiconductor is a P-Channel Enhancement Mode Power MOSFET. It has a drain-source breakdown voltage of -40 V, a gate threshold voltage of -1.6 V, and a drain-source on-resistance of less than 25 milli-ohms. This MOSFET utilizes Advanced Trench Process Technology and offers high-density cell design for ultralow on-resistance. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4.7 V Linear Charger for Low Voltage Battery | |
Battery Management IC
from ROHM Semiconductor
|
| The BD7090NUV-E2 from ROHM Semiconductor is a Linear Charger for a low charge voltage battery. It has an input voltage of 2.9-5.5 V and an adjustable battery voltage of 1.2-4.7 V. This BMIC exhibits virtually zero quiescent battery current and has an adjustable charge current of up to 100 mA. It is available in a surface-mount package that measures 3 x 3 x 1 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 31 V Automotive Qualified Multilayer Varistor | |
Varistor
from Eaton
|
| The AMLV04V05C033 from Eaton is an Automotive Qualified Multilayer Varistor. It has an AC voltage rating of 4 V, a DC voltage rating of 5.5 V, and a clamping voltage of up to 31 V. This AEC-Q200-qualified varistor offers bidirectional protection with V-jump and load protection capabilities. This RoHS-compliant varistor is available in a surface-mount package that measures 1.00 x 0.50 x 0.20 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 V PWM Chopper-Type Motor Driver IC | |
Motor Driver IC
from Toshiba
|
| The TB67S559FTG from Toshiba is a PWM (Pulse Width Modulation) Chopper-Type Motor Driver IC that is designed for 2-phase bipolar stepping motors. It requires an input voltage of -0.5 to 5.5 V. This motor driver uses the BiCD process to achieve an output withstand voltage of 50 V and a maximum current of 3.0 A. This IC is available in a surface-mount package that measures 5 x 5 x 1 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by European Vehicle Glazing Innovation Summit 2025 | | |
|
|
| 60 W Isolated Fixed-Ratio DC-DC Converter | |
DC to DC Converter
from Vicor
|
| The DCM2322T50T1360M60 from Vicor is an Isolated Fixed-Ratio DC-DC Converter that converts an input voltage of 9–50 V to a nominal output voltage of 12 V. It has an output power of up to 60 W and a continuous output current of 5 A. It has a peak efficiency of 89.7% and provides a power density of 241 W/in³. It is available in a through-hole package that measures 24.84 x 22.80 x 7.21 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive-Grade Two-Line ESD Protection Diodes | |
Power Diode
from Vishay
|
| The VGSOTxxC Series from Vishay are Automotive-Grade Two-Line ESD Protection Diodes. They have a reverse breakdown voltage of 4-47 V and a reverse current of 100 µA. These AEC-Q101-qualified diodes have a reverse stand-off voltage of 3.3 V and have a power dissipation of 44 W. These RoHS-compliant diodes are available in surface-mount packages that measure 2.9 x 1.3 x 1.01 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1120 V Disk Varistor | |
Varistor
from Wurth Elektronik
|
| The 820574211 from Wurth Elektronik is a Disk Varistor. It has an AC voltage rating of 420 V, a DC voltage rating of 560 V, and a clamping voltage of 1120 V. This varistor can withstand a peak pulse current of 1200 A and has a low power dissipation of 0.25 W. It has a reverse breakdown voltage of 690 V. This REACH/RoHS-compliant varistor is available in a through-hole package that measures 34 x 9 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V SiC Gate Driver Module | |
Gate Driver
from Wolfspeed
|
| The CCB032M12FM3 from Wolfspeed is a Six-Pack SiC Gate Driver Module. It has a drain-source voltage of 1200 V and an on-state drain-source resistance of 32 milli-ohms. This six-pack module is normally off and ensures fail-safe operation. It has a pulsed drain current of 60 A and a power dissipation of 83 W. This SiC module is available as a module that measures 33.5 x 62.8 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 V Isolated DC-DC Converter | |
DC to DC Converter
from XP Power
|
| The RDF15072S12 from XP Power is an isolated DC-DC Converter that converts input voltage of 14-160 V to an output voltage of 12 V. It delivers an output power of 150 W and has an efficiency of up to 90%. This converter provides an input-to-output isolation voltage of 3 kV (AC). These converters are available in a module that measures 61.0 x 57.9 x 12.7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1.5 µH Automotive-Grade Inductor | |
Power Inductor
from Murata
|
| The LQW18FT1R5K0HL from Murata is an Automotive-Grade Inductor that is ideal for automotive powertrain/safety equipment, automotive infotainment/comfort equipment, and medical equipment applications. This AEC-Q200-qualified inductor has an inductance of 1.5 µH and an inductance tolerance of ±10%. It is available in a surface-mount package that measures 1.60 x 0.94 x 1.15 mm. |
| |
Download Datasheet
Product Details | |
|
