| Featured Products this Week |
|
|
| 1200 V N-Channel E-Mode SiC MOSFET | |
MOSFET
from Navitas Semiconductor
|
| The G3R160MT12J from Navitas Semiconductor is an N-Channel Enhancement Mode SiC MOSFET. This MOSFET has a drain-source voltage of 1200 V and a gate threshold voltage of up to 2.7 V. It supports a continuous drain current of up to 19 A and a pulsed drain current of up to 35 A. It is available in a surface-mount package that measures 16.4 x 10.1 x 4.43 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5.5 V Power Management IC for IoT Applications | |
PMIC
from NXP Semiconductors
|
| The PCA9451AHNY from NXP Semiconductors is a Power Management IC that has been designed to support i.MX 93x family of processors in both single-cell Li-ion/Li-polymer portable and 5 V adapter non-portable applications. It requires an input voltage of 2.7-5.5 V and provides an output current of 2 A. It is available in a surface-mount package that measures 7 x 7 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V IGBT Power Module | |
IGBT
from Microchip Technology
|
| The APTGX300A120TDP3EG from Microchip Technology is an IGBT Power Module. It has a collector-emitter voltage of up to 1200 V, a gate threshold voltage of 5.8 V, and a saturated collector-emitter voltage of up to 1.8 V. This low-profile IGBT has a continuous collector current of up to 300 A. It is available as a module that measures 152 x 62 x 20.4 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 370 µH Automotive Grade BMS Transformer | |
Power Transformer
from iNRCORE
|
| The RA1062NL from iNRCORE is an Automotive Grade BMS Transformer designed for use with ADI LTC6804/681X series, NXP MC33771/33772, and TI BQ79616. This AEC-Q200-compliant center-tapped transformer has a turns ratio of 1CT:1CT. It has an inductance of up to 370 µH. It is available in a surface-mount package that measures 8.90 x 7.87 x 5.72 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 15 W Wireless Charging Transmitter IC for Portable Applications | |
Wireless Charging IC
from Infineon Technologies
|
| The WLC1115-68LQXQ from Infineon Technologies is a 15 W Wireless Charging Transmitter IC that supports WPC Qi and other proprietary specifications. It is designed using a 32-bit ARM Cortex-M0 processor. It has an input voltage from 4.5 V to 24 V. This RoHS-compliant wireless transmitter is available in a surface-mount package that measures 8 x 8 x 0.65 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 370 mV InSb Hall Elements | |
Current Transducer
from Diodes Incorporated
|
| The AHE300 Series from Diodes Incorporated are InSb Ultra-High Sensitivity Hall Elements. These current transducers require an input current of 20 mA and an input voltage of up to 2 V. They deliver a maximum output Hall voltage of 370 mV. These RoHS-compliant current transducers are available in compact surface-mount packages that measure 18.25 x 2.90 x 0.90 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by CAS 2025 | | CAS 2025 | | The IEEE Electron Devices Society (EDS) conference, CAS 2025, is one of Europe's oldest, bringing together academic scientists, researchers, industry specialists, and students to exchange research in nanoscience, micro- and nanotechnologies, and semiconductor devices physics and technology. Click here to learn more. | | | |
|
|
| 5000 W Photovoltaic Inverter | |
DC to AC Inverter
from Delta Electronics
|
| The H5A_222 from Delta Electronics is a Photovoltaic Inverter that converts a DC input voltage of up to 600 V to an AC output voltage of 180-280 V (single-phase). It delivers an output power of 5000 W and has an efficiency of up to 98.3% (peak). It includes two maximum power point trackers (MPPT). It is available in an IP65-rated enclosure that measures 380 x 318 x 130 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 15 V Regulated DC-DC Converter | |
DC to DC Converter
from Vicor
|
| The DCM2322T50T1760M60 from Vicor is a Low-Power Regulated DC-DC Converter that converts an input voltage of 9-50 V to an output voltage of 15 V. It delivers an output power of over 60 W and has an efficiency of up to 88.6%. It features a Safety Extra Low Voltage (SELV) 15 V nominal output. It is available in a through-hole package that measures 24.84 x 22.80 x 7.21 mm |
| |
Download Datasheet
Product Details | |
|
|
|
| 340 V Disk Varistor | |
Varistor
from Wurth Elektronik
|
| The 820411311 from Wurth Elektronik is a Disk Varistor. It has an AC voltage rating of 130 V, a DC voltage rating of 170 V, and a clamping voltage of 340 V. This varistor can withstand a peak pulse current of 3500 A and has a low power dissipation of 0.4 W. It has a reverse breakdown voltage of 200 V. This varistor is available in a through-hole package that measures 40.5 x 12.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Power Management IC for Brushless DC Motor Applications | |
PMIC
from Toshiba
|
| The TPD4163K,F from Toshiba is a Power Management IC that is ideal for DC Brushless Motor Driver IC applications. It requires an input voltage of 50 - 450 V. This PMIC is fabricated using a high-voltage SOI process. It features a three-shunt resistor circuit for precise current sensing. This RoHS-compliant PMIC is available in a surface-mount package that measures 32.8 x 11.4 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 800 V Planar Bridge Rectifier | |
Power Diode
from Panjit Semiconductor
|
| The GBJ1508HULV from Panjit Semiconductor is a Bridge Rectifier that is ideal for server/AI/IND, PC power (80+ platinum titanium), and gaming applications. It has a forward voltage of 0.88 V and a forward current of up to 15 A. This rectifier has a repetitive peak reverse voltage of less than 800 V. This RoHS-compliant rectifier is available in a through-hole package that measures 29.70 x 4.40 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 4.7 V Linear Charger for Low Voltage Battery | |
Battery Management IC
from ROHM Semiconductor
|
| The BD7090NUV-E2 from ROHM Semiconductor is a Linear Charger for a low charge voltage battery. It has an input voltage of 2.9-5.5 V and an adjustable battery voltage of 1.2-4.7 V. This BMIC exhibits virtually zero quiescent battery current and has an adjustable charge current of up to 100 mA. It is available in a surface-mount package that measures 3 x 3 x 1 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 1200 V Stud Screw Fit Thyristor | |
Silicon Controlled Rectifier
from Semikron Danfoss
|
| The SKT 160/12E from Semikron Danfoss is a Stud Screw-fit Thyristor. It has a blocking voltage of 1200 V. This thyristor has a continuous current rating of 160 A and a high surge current capability of up to 3750 A. It features a hermetic metal case with a glass insulator for enhanced reliability and durability, along with a threaded stud design for secure mounting. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V Automotive-Qualified N-channel MOSFET | |
MOSFET
from Nexperia
|
| The BUK7A1R0-100L from Nexperia is an Automotive-Qualified N-channel MOSFET that is suitable for thermally demanding automotive environments. This MOSFET has a drain-source voltage of 100 V and a gate threshold voltage of up to 3 V. It supports a continuous drain current of up to 460 A. It is available in a surface-mount package that measures 12 x 12 x 2.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 W Isolated DC-DC Converter Module | |
DC to DC Converter
from Murata
|
| The MYBSP00502ABFS from Murata is an Isolated DC-DC Converter Module with PWM control for IEEE 802.3af Class 0 PoE PD applications. It converts an input voltage of 37-57 V to an output voltage of 5 V. It can deliver an output power of 10 W at an output current of 2 A. It has an isolation voltage of 2250 Vdc. It is available in a surface-mount package that measures 26 x 14.8 x 6.2 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| AEC-Q200 Qualified LLC Half-Bridge Transformers | |
Power Transformer
from Coilcraft
|
| The HTX8045C Series from Coilcraft are AEC-Q200 Qualified LLC Half-Bridge Transformers designed for use in isolated Silicon Carbide and GaN gate. They offer inductance values from 75-120 µH and have a DCR rating of less than 0.450 ohms. These transformers are built using ferrite core material. They are available in surface-mount packages that measure 8.20 x 5.30 x 4.85 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Common Mode Chokes for Power Line Applications | |
Power Inductor
from Bourns
|
| The SRF1206A Series from Bourns are Automotive-Grade Common Mode Chokes designed for EMI suppression and power line noise filtering applications. These ferrite-core inductors provide high impedance and high current handling with values ranging from 500 µH to 1700 µH. They are available in surface-mount packages that measure 12.0 × 11.0 × 6.0 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Multi-Stage Constant Power LED Driver | |
LED Driver IC
from Mean Well
|
| The XLC-25-H-KN from Mean Well is a Multiple-Stage Constant Power LED Driver. It requires an input voltage of 100-305 V AC or 141-400 V DC. This LED driver provides an output current of up to 1.05 A, an output voltage of 60 V, and an output power of 25 W. It has an efficiency of up to 88%. It is available in a screw-mount package that measures 147 x 40 x 32 mm. |
| |
Download Datasheet
Product Details | |
|
