| Featured Products this Week |
|
|
| 25 V Automotive-Grade N-Channel JFET | |
Junction Field Effect Transistor (JFET)
from onsemi
|
| The NSVJ6904DSB6T1G from onsemi is an Automotive-Grade N-Channel Junction Field-Effect Transistor. It has a drain-source voltage of up to 25 V and a gate-drain voltage of -25 V. This AEC−Q101 qualified junction field effect transistor (JFET) has a power dissipation of less than 700 mW. It benefits from an ultralow noise figure and has a large forward transfer admittance. This JFET is available in a surface-mount package that measures 2.9 x 2.8 x 1.05 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 W Isolated DC-DC Converter Module | |
DC to DC Converter
from Murata
|
| The MYBSP00502ABFS from Murata is an Isolated DC-DC Converter Module with PWM control for IEEE 802.3af Class 0 PoE PD applications. It converts an input voltage of 37-57 V to an output voltage of 5 V. It can deliver an output power of 10 W at an output current of 2 A. This buck regulator has an isolation voltage of 2250 Vdc between the input and output and provides an efficiency of up to 83.4%. It is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1000 V Solar Fuse | |
Solar Fuse
from Littelfuse
|
| The SPFI010 from Littelfuse is a Solar Fuse designed to integrate into an in-line assembly within a wire harness. It has a voltage rating of 1000 V (DC) and a current rating of 10 A. This UL 248-19-certified solar fuse has a current interrupting rating of 20 kA (DC). The SPFI010 features a one-piece cap design for easier crimping, requires no fuse holder, and supports integration through overmolding or heat-shrink insulation. This fuse has a cold resistance of 0.0125 ohms. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6500 V Rectifier Diode Module | |
Power Diode
from Hitachi Energy
|
| The 5SED0600T6540 from Hitachi Energy is a Rectifier Diode designed in an industrial standard package (60Pak). It has a repetitive peak reverse voltage of 6500 V and a peak reverse current of 30 mA. This rectifier diode can withstand an isolation voltage of 3600 V and safeguards against a forward surge current of 11000 A. It has a forward voltage rating of 1.86 V and an average forward current of 490 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 70 F Hybrid Supercapacitor | |
Supercapacitor
from Eaton
|
| The HS/HSL1025-3R8706-R from Eaton is an Advanced Hybrid Supercapacitor designed for backup power, pulse power and hybrid power systems. It has a capacitance of 70 F and a capacitance tolerance of ±20%. This supercapacitor has a voltage rating of 3.8 V and a current rating of less than 0.35 A. It offers low ESR for high power density and has up to eight times energy density compared to standard supercapacitors. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by Microgrids & Energy Resilience Summit | | |
|
|
| 1.5 V CMOS LDO Voltage Regulator | |
LDO Voltage Regulator
from Analog Devices
|
| The ADPL42005ACPZ-1.5-R7 from Analog Devices is a CMOS-Based Low Dropout Voltage Regulator that is ideal for the regulation of noise-sensitive applications such as ADC, DAC, precision amplifiers, clocks, and PLLs, communications and infrastructure, medical, healthcare, instrumentation, and industrial applications. It requires an input voltage of 4-20 V. This regulator provides an output voltage of 1.5 V and has a dropout voltage of 400 mV (at 200 mA). |
| |
Download Datasheet
Product Details | |
|
|
|
| SiC Half-Bridge Gate Driver | |
Gate Driver
from Wolfspeed
|
| The CAS480M12HM3 from Wolfspeed is a High-Performance SiC Half-Bridge Gate Driver Module that is ideal for solar, EV chargers, industrial automation and testing, railway, and traction applications. It requires an input voltage of 8-19 V. This gate driver module is implemented using switching-optimized third-generation SiC MOSFET technology and integrates robust diodes with zero reverse recovery charge. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 V N-Channel MOSFET | |
MOSFET
from VBsemi Electronics
|
| The VBGQA1202N from VBsemi Electronics is an N-Channel MOSFET. It has a drain-source breakdown voltage of over 200 V, a gate threshold voltage of up to 3 V, and a drain-source on-resistance of 18 milli-ohms. This MOSFET has a continuous drain current of up to 50 A and a power dissipation of less than 136 W. It is fabricated using SGT technology and can withstand a junction temperature of 175°C. This MOSFET is available in a surface-mount package. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 W Off-Line High Voltage Converter | |
AC to DC Converter
from STMicroelectronics
|
| The VIPER11B from STMicroelectronics is an Energy-Saving Offline High-Voltage Converter. It integrates an 800 V avalanche-rugged power MOSFET, allowing ultra-wide VAC input range to be covered (85-265 V AC). This converter delivers an output power of up to 12 W in open-frame configurations and features ultra-low power consumption of less than 10 mW at 230 VAC in no-load conditions. It operates with a fixed switching frequency of 60 kHz. |
| |
Download Datasheet
Product Details | |
|
|
|
| 54 V Synchronous Buck PWM Controller | |
PMIC
from Renesas
|
| The ISL8117FVEZ-T7A from Renesas is a Synchronous Buck PWM Controller. It requires an input voltage of 4.5-60 V, and provides an output voltage from 0.6-54 V. This PWM controller offers programmable switching frequencies between 100 kHz and 2 MHz and utilizes Diode Emulation Mode with pulse skipping at light loads to enhance standby efficiency. It includes soft-start programming, enable control (EN pin), and a Power-Good (PGOOD) indicator. |
| |
Download Datasheet
Product Details | |
|
