| Featured Products this Week |
|
|
| Radiation-Hardened Positive LDO Regulator | |
LDO Voltage Regulator
from Renesas Electronics
|
| The HS-117EH from Renesas is a Radiation-Hardened Positive Voltage Linear Regulator that is ideal for adjustable voltage regulators and adjustable current regulators in harsh radiation environments. It requires an input voltage of 4.25-40 V. This regulator provides an output voltage of 1.25-37 V. It is available in a surface-mount package that measures 35.94 x 10.67 x 5.08 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| DC EMC Filter with Active Surge Protection | |
EMI / EMC Filter
from XP Power
|
| The DSF500 from XP Power is a DC EMC filter with surge protection designed for defense and avionics applications to provide active surge protection and EMC filtering for the conducted emissions of DC-DC converters. This filter requires an input voltage of 10-33 V DC and delivers output currents of up to 28 A. It is available in a PCB-mount package measuring 24.4 × 14.7 × 10.8 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 35 V Aluminium Electrolytic Capacitors | |
Power Capacitor
from TDK Corporation
|
| The B41799 Series from TDK Corporation are Aluminium Electrolytic Capacitors that are designed for automotive applications. They have capacitance values ranging from 1800-13000 µF with capacitance tolerances of -10/+30%. These charge/discharge-proof, polar power capacitors have a voltage rating of up to 35 V. These ultra-compact capacitors have low ESR at high frequency. |
| |
Download Datasheet
Product Details | |
|
|
|
| 265 V NTC Thermistors | |
Inrush Current Limiter
from Vishay
|
| The SL22 Series from Vishay are NTC Thermistors that protect from inrush current when electrical equipment is turned on. They have a voltage rating of up to 265 V and a current rating of less than 20 A. These UL/CSA recognized thermistors are rugged and reliable and can withstand up to 5 A of continuous current and 200 J of input energy. They are available in through-hole packages. |
| |
Download Datasheet
Product Details | |
|
|
|
| Capacitively Isolated Single-Channel Gate Driver | |
Gate Driver
from Littelfuse
|
| The IX3407BTR from Littelfuse is a Capacitively Isolated Single-Channel Gate Driver designed for driving IGBTs, MOSFETs, and SiC MOSFETs in demanding industrial applications. It can operate with an output supply voltage of 13-35 V and provides peak output currents of 7 A for both sourcing and sinking. It is available in a surface-mount package that measures 10.3 x 6.3 x 2.65 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V E-Mode N-Channel Silicon Power MOSFET | |
MOSFET
from Toshiba
|
| The TPH2R70AR5 from Toshiba is an Enhancement Mode N-Channel Silicon Power MOSFET designed for high-efficiency DC-DC converters, switching voltage regulators, and motor drivers. It has a drain-source voltage of over 100 V, a gate threshold voltage of 4.3 V. This power MOSFET is available in a surface-mount package that measures 5.75 x 5.15 x 1 mm. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by North American Vehicle Glazing Innovation Summit 2025 | | North American Vehicle Glazing Innovation Summit 2025 | | The North American Vehicle Glazing Innovation Summit 2025 will be held in Detroit, USA, on November 18–19. The event brings together OEMs, suppliers, and technology leaders to explore advancements in smart glass, HUDs, lightweight materials, and system integration. It highlights the shift of automotive glass into a multifunctional interface, shaping the future of safety, comfort, and efficiency in electric and autonomous vehicles.Click here to learn more. | | | |
|
|
| Programmable 18-Channel Linear LED Driver | |
LED Driver IC
from Diodes Incorporated
|
| The AL58818QFRZW40-13 from Diodes Incorporated is a programmable 18-channel linear LED driver designed for up to six RGB LED lighting modules. It requires an input voltage of 2.7–5.5 V. This LED driver is comprised of 18 programmable LED current channels. This RoHS-compliant LED driver is available in a surface-mount package that measures 5 x 5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 800 A Phase Control Thyristor | |
Silicon Controlled Rectifier
from Proton-Electrotex JSC
|
| The T243-800-18 from Proton-Electrotex JSC is a Phase Control Thyristor that is used to control high loads with a low control signal applied to the control gate. It has a repetitive peak voltage of up to 1800 V and a mean on-state current of 800 A. This thyristor has a gate trigger voltage of up to 5 V and a gate trigger current of over 8 A. It is available in a disc package that measures 67 x 14 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 280 W Monocrystalline Cell | |
Solar Panels
from Solar Electric
|
| The STKM-60-280 from Solar Electric is a Monocrystalline Cell Module that consists of 60 cells. It provides an output voltage of 31.4 V and an output current of 8.6 A. This solar panel has a module efficiency of 18.2% and a rated maximum power of 280 W under standard test conditions. It is available as a module that measures 1673 x 991 x 5.4 mm and weighs about 20.5 kg. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6 W DC-DC Converters for Railway Applications | |
DC to DC Converter
from Traco Power
|
| The TMR 6WIR Series from Traco Power are DC-DC Converters that convert an input voltage of 9-160 VDC to an output voltage of 3.3-24 VDC. They deliver a regulated output power of 6 W and achieve an efficiency of up to 87%. These EN 50155-approved converters feature 3000 VDC input-output isolation voltage. These converters are available in through-hole packages that measure 21.8 x 15.3 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Power-Factor Corrected LED Driver IC | |
LED Driver IC
from onsemi
|
| The NCL30086BH from onsemi is a Power-Factor Corrected LED Driver IC that is designed to support flyback, buck−boost, and SEPIC topologies. It requires an input voltage of -0.3 V to 30 V. This LED driver has a Tight LED Constant Current Regulation of ±2%. This LED driver is available in a surface-mount package that measures 6.2 x 5 x 1.75 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 V Automotive-Grade SiC MOSFET | |
MOSFET
from Infineon Technologies
|
| The AIMDQ75R025M2H from Infineon Technologies is an Automotive-Grade Silicon Carbide MOSFET designed to enable cost-effective, highly efficient, and simplified designs to fulfill the ever-growing system and market needs. It has a drain-source breakdown voltage of over 750 V, a gate threshold voltage of 4.5 V, and a drain-source on-resistance of less than 25 milli-ohms. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by North American Vehicle Glazing Innovation Summit 2025 | | |
|
|
| 600 V Triac for AC Switching Applications | |
Triac
from STMicroelectronics
|
| The Z0107MA 1AA2 from STMicroelectronics is a Triac engineered for general-purpose AC switching. It has a breakover voltage of 600 V and a breakover current of 8.5 A. This thyristor has a gate trigger voltage of 1.3 V and a gate trigger current of 5 mA. It is a sensitive-gate device rated for an RMS on-state current of 1A. It is available in a through-hole package that measures 17.10 x 4.70 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 6 µH Automotive-Grade Common Mode Choke | |
Power Inductor
from Bourns
|
| The SRF1206A-501Y from Bourns is an Automotive-Grade Common Mode Choke designed for EMI suppression and power line noise filtering applications. This shielded ferrite-core inductor has an inductance of 6 µH and provides high impedance. This AEC-Q200 qualified choke has a current rating of up to 10 A. It is available in a surface-mount package that measures 12.0 × 11.0 × 6.0 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| MIL-STD-1553 Interface Transformer | |
Power Transformer
from iNRCORE
|
| The DFL1553-1 from iNRCORE is a MIL-STD-1553 Interface Transformer. It has a turn ratio of 1CT:1CT or 1CT:0.707CT and a DCR rating of 3 ohms. This ISO-9001 certified transformer offers a minimum impedance of 4000 ohms and can sustain a dielectric withstand voltage of 100 Vrms. It is available in a surface-mount package that measures 23.62 x 16.00 x 3.94 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Multi-Stage Constant Power LED Driver | |
LED Driver IC
from Mean Well
|
| The XLC-25-H-KN from Mean Well is a Multiple-Stage Constant Power LED Driver. It requires an input voltage of 100-305 V AC or 141-400 V DC. This LED driver provides an output current of up to 1.05 A, an output voltage of 60 V, and an output power of 25 W. It has an efficiency of up to 88%. It is available in a screw-mount package that measures 147 x 40 x 32 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 500 V Triac for Motor Control Applications | |
Triac
from Naina Semiconductor
|
| The Q5025P from Naina Semiconductor is a Triac. It has a breakdown voltage of 500 V, a breakdown current of 250 A, and an RMS current of 25 A. This triac has a gain trigger voltage of 2.5 V and a gain trigger current of 80 mA. It is constructed using glass passivated chips. This triac showcases high reliability and exceptional stability at high temperatures, with superior surge capabilities. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V IGBT Power Module | |
IGBT
from Microchip Technology
|
| The APTGX300A120TDP3EG from Microchip Technology is an IGBT Power Module. It has a collector-emitter voltage of up to 1200 V, a gate threshold voltage of 5.8 V, and a saturated collector-emitter voltage of up to 1.8 V. This low-profile IGBT has a continuous collector current of up to 300 A. This RoHS-compliant IGBT is available as a module that measures 152 x 62 x 20.4 mm. |
| |
Download Datasheet
Product Details | |
|
