| Featured Products this Week |
|
|
| 240 W Isolated AC-DC Power Supplies | |
AC to DC Converter
from Recom Power
|
| The RACPRO1-S240 Series from Recom Power are Isolated AC-DC Power Supplies that step down an AC input voltage of 85-277 V (3-phase) to a DC output voltage of 24 V. They also accept a DC input voltage of 88-370 V. These converters deliver an output power of 240 W and have an efficiency of up to 95%. They have an adjustable output voltage of 24-29 VDC and an output current of 10 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| Self-Powered Isolated Gate SiC Driver IC | |
Gate Driver
from Allegro MicroSystems
|
| The AHV85311KNHBU from Allegro MicroSystems is a Self-Powered Isolated Gate SiC Driver IC with a power-thru integrated isolated bias supply that has been optimized for discrete SiC. It has a low I/O capacitance of less than 3 pF and a working voltage of 1500 V. It combines the benefits of high common-mode transient immunity (CMTI) and is capable of delivering up to 130 nC gate charge at 25 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| Magnetically Shielded Automotive Power Inductors | |
Power Inductor
from Vishay
|
| The IHLP1210ABEZ-5A Series from Vishay are Automotive Power Inductors. They have an inductance of 0.47-4.7 µH and a tolerance of ±20%. These AEC-Q200-qualified power inductors have a saturation current of 8.2 A and a DC resistance of up to 180 milli-ohms. These power inductors feature side and bottom plated terminals for improved shock and vibration performance and solder inspection. |
| |
Download Datasheet
Product Details | |
|
|
|
| AC-DC Grid-Tied Bidirectional Energy Conversion Power Supplies | |
AC to DC Converter
from Mean Well
|
| The BIC-5K Series from Mean Well are AC-DC Grid-Tied Bidirectional Energy Conversion Power Supplies designed for bidirectional energy conversion. They convert AC input voltage in the range of 180–305 V to selectable DC output voltages of 24 V, 48 V, 96 V, and 380 V. These power supplies are available in chassis-mount packages that measure 460 × 211 × 83.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Step-Down Monolithic Switching Regulator | |
LED Driver IC
from STMicroelectronics
|
| The LED6000 from STMicroelectronics is a Step-Down Monolithic Switching Regulator designed for driving high-brightness LEDs in a wide range of industrial and lighting applications. It requires an input voltage of 4.5-61 V. This LED driver integrates an internal power MOSFET with a typical RDS(ON) of 250 milli-ohms. It supports up to 3 A of DC output current. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by DigiKey | | SCM Series Communication Modules | | SolaHD's communication modules are designed for SDN-D series high-performance DIN rail power supplies. Enable predictive maintenance and efficiency with SCM modules—monitor SDN-D power supplies via Ethernet/IP or HART for critical industrial systems. Click here to learn more. | | | |
|
|
| AEC-Q200-Qualified Sintered Metal Shunt Resistors | |
Power Resistor
from ROHM Semiconductor
|
| The UCR10CEVPFS from ROHM Semiconductor is a High-Power Sintered Metal Shunt Resistor. It has a resistance value ranging from 43-100 milli-ohms and a resistance tolerance of ±1%. This AEC-Q200-qualified resistor has a power rating of up to 1.25 W. It has a temperature coefficient of up to 60 ppm/°C and can operate over a temperature range from 25°C to +155°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Half-Bridge IGBT Power Module | |
IGBT
from Cissoid
|
| The CMT-PLA1BL12300MA from Cissoid is a Half-Bridge IGBT Power Module that is ideal for high-frequency switching, medical applications, motion/servo control, UPS systems, and power supplies. It has a collector-emitter breakdown voltage of 1200 V, a gate threshold voltage of 6.5 V, and a saturated collector-emitter voltage of 2.2 V. It has a continuous DC collector current of 450 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| Programmable DC Power Supplies | |
AC to DC Converter
from Magna-Power Electronics
|
| The SLx Series from Magna-Power Electronics are Programmable DC Power Supplies that feature a rugged current-fed power processing architecture. These power supplies convert an input voltage of 208-240 V (single-phase) and 208-480 V (three-phase) to a DC voltage of 5-3000 V. They feature current levels of up to 600 A and power levels from 1.5-10 kW. |
| |
Download Datasheet
Product Details | |
|
|
|
| 10 W DC-DC Converters | |
DC to DC Converter
from XP Power
|
| The JMR10 Series from XP Power are Regulated DC-DC Converters that convert input voltages of 4.5-75 V to single and dual output voltages of up to +/-15 V DC. These ultra-compact converters deliver an output current of up to 2000 mA, an output power of 10 W, and have efficiencies of up to 89%. They offer continuous short circuit protection and offer remote on/off controls. |
| |
Download Datasheet
Product Details | |
|
|
|
| USB 2.0 Hi-Speed Peripheral Controller | |
PMIC
from Infineon Technologies
|
| The CYUSB2315-BF104AXIT from Infineon Technologies is a USB 2.0 Hi-Speed Peripheral Controller designed for applications in biometrics, scanners, cameras, video, and imaging markets. It requires an input voltage of 1.7-3.6 V. This controller supports USB 2.0 operation at 480 Mbps with up to 32 endpoints. It is available as a surface-mount package that measures 8 x 8 mm |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 1700 V Silicon N-Channel IGBT | |
IGBT
from Minebea Power Semiconductor Device
|
| The MBN3600E17F from Minebea Power Semiconductor Device is a Silicon N-channel IGBT. It has a collector emitter voltage of 1700 V with a forward current of 7200 A. This IGBT operates at a wide range of temperatures from -50°C to +150°C. It has a peak forward voltage drop of up to 2.7 V and a reverse recovery time of 1.6 µs. This IGBT has a gate emitter threshold voltage of up to 7.1 V. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V N-Channel MOSFET | |
MOSFET
from Micro Commercial Components
|
| The SL100N10L-TP from Micro Commercial Components is an N-Channel MOSFET. It has a drain-source voltage of 100 V, a gate threshold voltage of 1.3-2.3 V, and a drain-source on-resistance of up to 110 milli-ohms. This MOSFET has a continuous drain current of up to 20 A, a pulsed drain current of 8 A, and a power dissipation of 0.92 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| Air Coil Inductors | |
Power Inductor
from Bourns
|
| The AC3028SQ Series from Bourns are Air Coil Inductors. They have an inductance in the range of 27-47 nH and have inductance tolerances of ±2 and ±5. These power inductors have current ratings of up to 5.5 A and a DC resistance in the range of 8.1-11.3 milli-ohms, featuring a high Q value. They are designed to operate across a wide temperature range of -25°C to +125°C. |
| |
Download Datasheet
Product Details | |
|
|
|
| AC-DC Converters with PFC Function | |
AC to DC Converter
from Cincon Electronics
|
| The CFM600S Series from Cincon Electronics are AC-DC Converters that step down AC input voltages of 85-264 V to DC output voltages of 12-48 V. They deliver output currents of up to 50 A and achieve efficiencies of up to 94.5%. These converters have high power densities of 25.97 W/inch³ while incorporating active power factor correction (PFC). |
| |
Download Datasheet
Product Details | |
|
|
|
| 30 V N-Channel MOSFET | |
MOSFET
from Good Ark Semiconductor
|
| The GSGP0R703 from GoodArk Semiconductor is an N-Channel MOSFET designed for high-efficiency power switching applications. It has a drain-source voltage of 30 V and a gate threshold voltage of up to 2.3 V. This MOSFET has a drain-source on-resistance as low as 0.55 milli-ohms (typical), enabling low conduction losses. It supports a continuous drain current of up to 282 A. |
| |
Download Datasheet
Product Details | |
|
