| Featured Products this Week |
|
|
| 6.6 kW Load Dump Transient Voltage Suppressor | |
Power Diode
from Panjit Semiconductor
|
| The SM8H14CAS-AU from Panjit Semiconductor is a Load Dump Transient Voltage Suppressor designed for high surge capability and low leakage current. It has a reverse standoff voltage of 14 V and a reverse leakage current of less than 1 µA. It is available in a surface-mount package that measures 16 x 10.5 x 5 mm and is ideal for automotive load dump protection and other high-power transient suppression applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1200 V Planar E-Mode SiC MOSFET | |
MOSFET
from Navitas Semiconductor
|
| The G3F65MT12K from Navitas Semiconductor is a Trench-Assisted Planar Enhancement Mode Silicon Carbide MOSFET. It has a drain-source breakdown voltage of 1200 V, a gate threshold voltage of up to 4.3 V, and a drain-source on-resistance of less than 86 milli-ohms. This MOSFET has a power dissipation of 153 W. This MOSFET is available in a through-hole package that measures 16.13 x 41.42 x 5.21 mm and is ideal for xEV on-board chargers and DC-DC converters. |
| |
Download Datasheet
Product Details | |
|
|
|
| 100 V N-Channel Rad-Hard MOSFET | |
MOSFET
from Microchip Technology
|
| The JANSF2N7587U3 from Microchip Technology is an N-Channel Radiation-Hardened MOSFET that is ideal for DC–DC converters, switch mode power supplies and motor control applications. It has a drain-source breakdown voltage of over 100 V, a gate-source voltage of up to ±20 V, and a drain-source on-resistance of 0.042 ohms. This power MOSFET has a continuous drain current of up to 22 A, a pulsed drain current of 88 A and a power dissipation of less than 75 W. |
| |
Download Datasheet
Product Details | |
|
|
|
| Automotive Grade BMS Dual Port Transformer | |
Power Transformer
from iNRCORE
|
| The RA2055NL from iNRCORE is an Automotive Grade BMS Dual Port Transformer designed for use with ADI LTC6804/681X series, NXP MC33771/33772 and TI BQ79616. This AEC-Q200-compliant center-tapped transformer has a turns ratio of 1:1. It has an inductance of up to 450 µH, with an insertion loss of 0.3 dB and return loss of 20 dB. This transformer is available in a surface-mount package that measures 15.5 x 12 x 5.3 mm and is ideal for automotive applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1100 V 3-Phase DC-AC Inverter | |
DC to AC Inverter
from Delta Electronics
|
| The M50A_260 from Delta Electronics is a 3-Phase DC-AC Inverter that converts a DC input voltage of up to 1100 V to an AC output voltage of 400 V. It delivers an output power of 55 kVA and has an efficiency of up to 98.7%. It consists of in-built DC switches, SPD and string monitoring. This inverter is available as a module that measures 699 x 629 x 264 mm and is ideal for residential, commercial building and industrial applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 12 V Low-Power Regulated DC-DC Converter | |
DC to DC Converter
from Vicor
|
| The DCM2322T50T1360T60 from Vicor is a Low-Power Regulated DC-DC Converter that converts an input voltage of 9-50 V to an output voltage of 12 V. It delivers an output power of over 60 W and has an efficiency of up to 89.7%. This isolated converter operates from an unregulated, wide-range input to generate an isolated 12 V DC output. It features a Safety Extra Low Voltage (SELV) 12 V nominal output and provides a 3000 V DC isolation. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by London EV Show 2025 | | |
|
|
| 4.7 V Linear Charger for Low Voltage Battery | |
Battery Management IC
from ROHM Semiconductor
|
| The BD7090NUV-E2 from ROHM Semiconductor is a Linear Charger for low charge voltage battery. It has an input voltage of 2.9-5.5 V and an adjustable battery voltage of 1.2-4.7 V. This BMIC exhibits virtually zero quiescent battery current and has an adjustable charge current of up to 100 mA. It is available in a surface-mount package that measures 3 x 3 x 1 mm and is suitable for low-voltage battery products and Li-ion single-cell battery products. |
| |
Download Datasheet
Product Details | |
|
|
|
| Power Management IC for Brushless DC Motor Applications | |
PMIC
from Toshiba
|
| The TPD4163K,F from Toshiba is a Power Management IC that is ideal for DC Brushless Motor Driver IC applications. It requires an input voltage of 50 - 450 V. This PMIC is fabricated using a high-voltage SOI process. It features a three-shunt resistor circuit for precise current sensing. It simplifies DC brushless motor control by accepting logic inputs from an MCU or motor controller. This RoHS-compliant PMIC is available in a surface-mount package that measures 32.8 x 11.4 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1240 V Disk Varistor | |
Varistor
from Wurth Elektronik
|
| The 820544611 from Wurth Elektronik is a Disk Varistor. It has an AC voltage rating of 460 V, a DC voltage rating of 615 V, and a clamping voltage of 1240 V. This varistor can withstand a peak pulse current of 4500 A and has a low power dissipation of 0.6 W. This REACH/RoHS-compliant varistor is available in a through-hole package that measures 45.5 x 16.5 mm and is ideal for 12-48 VDC distribution, 110-400 V power supplies, surge protection, and leakage of voltage peaks. |
| |
Download Datasheet
Product Details | |
|
|
|
| 150 W Isolated DC-DC Converters | |
DC to DC Converter
from XP Power
|
| The RDF150 series from XP Power are Isolated DC-DC Converters that convert input voltages of 14–160 V to output voltages of 5–48 V. They deliver an output power of 150 W and have an efficiency of up to 90%. These converters provide input-to-output isolation voltages of 3 kV (AC). These converters are available as modules that measure 61.0 × 57.9 × 12.7 mm and are ideal for factory automation, industrial electronics, and railway applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 160 A Dual Phase DC-DC Converter | |
DC to DC Converter
from Infineon Technologies
|
| The TDM22544DXUMA1 from Infineon Technologies is a Dual Phase DC-DC Converter that steps down an input voltage of 4.25-16 V to an output voltage of 0.225-3 V. It provides a switching frequency of 600 kHz-1.2 MHz and has an output peak current capability of 160 A. This converter consists of two smart power stages, two inductors, and decoupling capacitors. This RoHS-compliant converter is available in a surface-mount package that measures 10 x 9 x 8 mm. |
| |
Download Datasheet
Product Details | |
|
